Ken-Tool Serpent T2001 Manual de usuario
768 E. North Street • P.O. Box 9320 • Akron, Ohio 44305 Phone: 330-535-7 77
Website: www.kentool.com E-mail: [email protected] Fax: 330-535- 345
T2001 #35449 Demount Tool
Instruction Manual
Copyright 6/00
Demount First Bead
Break and lube both beads.
Lay tire on floor with short side
of wheel up.
Hold curved part of large end,
with the tip facing up, behind
you.
Keeping fingers out of the area
between tool and tire/wheel,
fully insert small end, between
rim and tire bead nearest you,
in top bead of tire.
Fully insert large end into gap
between wheel and tire until
you feel bottom bead.
Lift small end, step through
the wheel and pull tool across
center of wheel.
ush tool down to opposite
side. Tire is now fully
demounted.
Demount Second Bead
Lift large end. (Improper lifting
will cause the tool to roll)
Step through the wheel and
pull tool across center of wheel.
ush tool down to opposite
side. First bead is now
demounted. Remove tool from
wheel. Do not pick up
tire/wheel.
768 E. North Street • P.O. Box 9320 • Akron, Ohio 44305 Phone: 330-535-7 77
Website: www.kentool.com E-mail: [email protected] Fax: 330-535- 345
T2002 #35450 Mount Tool
Instruction Manual
Copyright 2/0
Mount First Bead
Mounting: Insert valve stem. Lubricate both bead seats of
the rim and both tire beads. Push lower bead over flange and
into rim well. Using the wing shaped end of tire iron with stop
resting on rim flange, pry tire over flange, starting where tire
bead crosses rim flange. Repeat progressively around tire
working with small sections until the tire is completely over
the rim. By rocking the tool sideways onto the wing, the tip
will release itself from the rim and bead. (See figure #3 below)
Mount Second Bead
Stand on the tire to push a section of the bead over the flange and into the well. When
using this tool, a bead keeper (#3 7 0) is recommended to hold the bead in place
.
(See
figure #2
)
While standing on the tire, insert the wing shaped end of the tire iron between
the tire bead and rim flange. Push the tire bead over the rim flange opposite where the tire
is already in the well. Repeat this step taking small sections of the bead until the last
section is pried over the rim flange until tire is mounted.
The small end of the tool
easily gets under the
stretched bead for that last
pull.
Fig. #
Fig. #2
Fig. #3
Fig. #4
Fig. #5
Always wear eye protection when servicing tires
and wheels and whenever using hand tools.
Always use soft-faced hammers when driving tire
irons.
Never use one hammer to strike another hammer.
Never use a hammer with loose or cracked
handle.
Never use a dented, cracked, chipped,
mushroomed, or deformed tool.
Never use a tire tool for anything except
mounting/demounting tires.
!
WARNING
SAFETY WARNING: If you don’t know how to use tire ch nging tools - STOP! Tire ch nging should only be done by tr ined persons. If you do it
wrong, you could be hurt or killed. For complete tire servicing procedures, re d the tire nd rim m kers’ service m nu ls. You c n lso get free
w ll ch rts bout tire servicing by c lling OSHA t 1-202-523-9667.
