Ken-A-Vision®
MICROSCOPES
Ken-A-Vision®
MICROSCOPES
Ken-A-Vision was founded with the foresight of
creating a company which would invent, design,
and manufacture high quality visual equipment
for demonstration, presentation, and education
applications. Our name is known and respected
world-wide. “KEN” is taken from an Anglo-Saxon
word meaning
knowledge
, and “A” comes from
the Latin word meaning
through
. Our mission, like
our name, is to create
knowledge through vision.
Contact us today
1-800-334-8407
www.ken-a-vision.com
Ken-A-Vision®has
manufactured high quality
products for over 50 years!
Ken-A-Vision®
Microscope Table of Contents
PrepScope............................................................................3
CoreScope ...........................................................................4
Comprehensive Scope...........................................................5
VisionScope .........................................................................7
Professor by Ken-A-Vision®...................................................9
Cordless PrepScope ............................................................10
Cordless CoreScope............................................................11
Cordless Comprehensive Scope ...........................................12
Cordless VisionScope..........................................................13
Multicharger ......................................................................15
Comparison Scope .............................................................16
Research Scope..................................................................17
Digital PrepScope...............................................................18
Digital Comprehensive Scope ..............................................19
Megapixel Digital Comprehensive Scope .............................20
Applied Vision™ Software ..................................................21
Memory Scope...................................................................22
Microprojector....................................................................23
MP2 ..................................................................................24
Microscope Accessories ......................................................25
2
1-800-334-8407
www.ken-a-vision.com
3
PrepScope
PrepScope
The PrepScope series was
specifically designed for
student use in primary and
middle schools. It offers high
quality glass optics for clear,
crisp images. The PrepScope
series is offered with a
monocular or dual opposing
head. The dual opposing
head can be used by two
students or a teacher and
a student to view the same
microscopic image.
Features
• 45° Angle, 360° Rotating Prism Head
• 3 Hole Reversed Nose Piece
• Retractable 40x Lens to Protect Slides
• Spring-loaded Stage Clips
• Low Position Focusing
• High Density Plastic Covered Metal Base
SPECIFICATIONS
Catalog # T-1201 T-1202
Head Type Monocular Dual Opposing
10x Widefield Eyepiece with Pointer Yes Yes
Objective Lens 4x, 10x, 40xR DIN 4x, 10x, 40xR DIN
Disc Diaphragm with Six Apertures Yes Yes
Coarse/Fine Focusing in One Knob Yes Yes
Built-in 10 Watt Illuminator Yes Yes
Warranty 10 Years 10 Years
Specifications subject to change without notice
1-800-334-8407
www.ken-a-vision.com
4
CoreScope
Ken-A-Vision®re-introduces
the CoreScope with some
new and improved features.
This compactly designed
microscope now comes with
a multi-directional round
floating stage which eliminates
the need for a mechanical
stage. Separate coarse and
fine focusing knobs which
makes it easier for the student
to use. The CoreScope is
offered with a monocular and
dual opposing head options.
CoreScope
Features
• Multi-directional Round Floating Stage
• 45° Angle, 360° Rotating Prism Head
• 3 Hole Reversed Nose Piece
• Retractable 40x Lens to Protect Slides
• Spring-loaded Stage Clips
• High Density Plastic Covered Metal Base
SPECIFICATIONS
Catalog # T-1701 T-1702
Head Type Monocular Dual Opposing
10x Widefield Eyepiece with Pointer Yes Yes
Objective Lens 4x, 10x, 40xR DIN 4x, 10x, 40xR DIN
Spring-loaded Stage Clips Yes Yes
Multi-directional Round Floating Stage Yes Yes
Coarse & Fine Coaxial Focal Adjustment Yes Yes
Built-in 10 Watt Illuminator Yes Yes
Warranty 10 Years 10 Years
Specifications subject to change without notice
SPECIFICATIONS
Catalog # T-1901 T-1902
Head Type Monocular Dual Opposing
10x Widefield Eyepiece with Pointer Yes Yes
Objective Lens 4x, 10x, 4x, 10x,
40xR DIN 40xR DIN
Mechanical Stage, Abbe Condenser & 100xR Lens Optional Optional
Disc Diaphragm with Six Apertures Yes Yes
Coarse & Fine Coaxial Focal Adjustment Yes Yes
Lighting Tungsten Tungsten
Warranty 10 Years 10 Years
Specifications subject to change without notice
1-800-334-8407
www.ken-a-vision.com
5
Comprehensive Scope
Comprehensive Scope
The Comprehensive Scope
is a professionally equipped
instrument priced within the
educational budget. The series
provides quality DIN optics.
All models have many
optional features (see chart
below). It’s an educational
bargain with both flexibility
and real value! Excellent for
high schools, colleges and
universities.
Features
• 45° Angle, 360° Rotating Prism Head
• 4 Hole Reversed Nose Piece
• Retractable 40x & 100x Lens to Protect Slides
• High Density Plastic Covered Metal Base
T-1901
T-1903 T-1901F T-1902F T-1903F
Binocular Monocular Dual Opposing Binocular
Yes Yes Yes Yes
4x, 10x, 40xR, 4x, 10x, 4x, 10x, 4x, 10x, 40xR,
100xR DIN 40xR DIN 40xR DIN 100xR DIN
Yes Optional Optional Yes
No Yes Yes No
Yes Yes Yes Yes
Tungsten Fluorescent Fluorescent Fluorescent
10 Years 10 Years 10 Years 10 Years
1-800-334-8407
www.ken-a-vision.com
6
T-1901 features a monocular head and stage clips.
T-1902 features a dual opposing head and stage clips.
T-1903 features a binocular head, Abbe Condenser, 100xR
objective lens, and mechanical stage.
T-1902 T-1903
SPECIFICATIONS
Catalog # T-2200 T-2202
Head Type 45° Angle Binocular 45° Angle Binocular
Widefield Eyepiece 10x 20x
Objectives 1x & 3x 1x & 3x
Coarse/Fine Focusing in One Knob Yes Yes
Lower Transmitted Flourescent & Upper Yes Yes
Incident Halogen Lighting
Light Rheostat Yes Yes
Stage Plate Frosted Frosted
Warranty 10 Years 10 Years
Specifications subject to change without notice
7
VisionScope
Our uniquely designed
stereo microscopes have a
rubber base for stability
and protection. The series
contains many magnification
variations to provide bright,
clear stereoscopic (3-D)
images. These VisionScopes
are value-priced to meet
most budgets.
VisionScope
Features
• Interchangeable Heads with
all Models Except T-2400
• High Quality Optics
• Dual Rocker Switches with Separate
ON/OFF Switch for Transmitted &
Incident Lighting (T-2200 & T-2600 Series)
• Lighting is Incident, Transmitted or Both
(T-2200 & T-2600 Series)
• Oversized Focus Knob making it
easier to focus T-2400
T-2202
T-2204 T-2206 T-2600 T-2400
45° Angle Binocular 45° Angle Binocular 45° Angle Binocular Vertical Binocular
10x 20x 10x 10x
2x & 4x 2x & 4x Zoom 1x – 4x 2x
Yes Yes Yes Yes
Yes Yes Yes No
Yes Yes Yes No
Frosted Frosted Frosted Frosted
10 Years 10 Years 10 Years 10 Years
1-800-334-8407
www.ken-a-vision.com
8
Interchangeable Heads
Zoom Head Turret Head
Base
9
Professor Microscope
by Ken-A-Vision
®
Professor Microscope
by Ken-A-Vision
®
Ken-A-Vision®designed this
line with the younger students
in mind. Constructed with
high impact plastic, non-
removable parts, one knob
focusing and glass optics the
Professor Microscopes are a
cost-effective way for students
to learn microscopy.
ESH100
Compound Microscope
ESH200
Stereo Microscope
ESHCADDY
The Professor Caddy is
a great addition to your
purchase of either Professor
10-packs. All 10 of the
Professors fit inside this
bag making them easy
to transport or store.
SPECIFICATIONS
Catalog # ESH100 ESH200
(Available March 2006)
Microscope Type Compound Stereo
Eyepiece 10x
Head 45° angle fixed
Objective 4x, 10x, 40x
Power Source 3 AA Batteries
High Impact Plastic Body Yes
10-Pack Option ESH110
Organizational Animal Yes
Stickers Available
Warranty 1 Year
Specifications subject to change without notice
1-800-334-8407
www.ken-a-vision.com
