-7-
Installation of Ceramic Stand
・Press the button to lower the table.
・Place the provided ceramic stand at the center of the firing table.
Altitude Setting
・When using the unit, please set the altitude according to your geographic location.
・For users using at high altitude, storms approaching may cause vacuum trouble.
Please follow the process listed below.
①When it goes into standby mode, move the “Default” button to move to default set mode.
②Press the button to move to the “Altitude” and set value according to the altitude of the
location. There are 4 set values：500m, 1000m, 1500m, 2000m, Default is 500m.
The suggested value setting is as follows：Less than 500m = 500m, 500 ～1000m = 1000m,
1000～1500m = 1500m, above 1500m = 2000m.
The unit installment process is completed now. When using the unit for the first time, please follow
the "Unloaded Muffle Firing" process.
Unloaded Muffle Firing
We recommend using Dry type vacuum pump, as water puts in a pump.
In case of using an oil-sealed vacuum pump, change its oil after unloaded
muffle firing.
・When first purchasing the unit or when the unit has not been in use for a long period of time, there
may be some moisture in the muffle that may cause bad effects during firing.
Please follow the unloaded muffle firing process listed below.
①Power on the unit, when it goes into standby mode, press the “Default” button to go to default
set mode.
②When it goes into default set mode, press the F1(Function) button to change the function of
F2 to F4 button, and press F4(Maintenance) button to go into maintenance mode.
③When it goes into maintenance mode, press the "Muffle Firing" button and the firing will begin.
④During firing, the screen below will appear indicating time remaining of firing. This firing process
will take about 200 minutes. If you would like to cancel the firing process, press the "Cancel" button.
Caution) When firing, please have the vacuum pump set-up. If the vacuum pump is not set-up, there may be
situations when the moisture is not fully pulled out.
