KAR-TECH MNTA1 MINI REMOTE Manual de usuario

MNTA1 MINI REMOTETM

MINI REMOTE CONTROL SYSTEM

PRELIMINARY

USER MANUAL

March 07, 2006

MINI REMOTE

INDEX

Description ................................................................... 1

Installation ................................................................... 2

Before applying power ..................................................... 2

Routine Maintenance ....................................................... 3

Maintenance precautions .................................................. 3

Troubleshooting ............................................................. 3

Troubleshooting chart ................................................. 4

Specifications ................................................................ 5

Instructions to the User .................................................... 6

MINI REMOTE

DESCRIPTION:

KAR-TECH's MINI REMOTE is a state

of the art microprocessor based

Radio Frequency (RF) remote

control system designed to

provide the machine operator

with the ability to remotely

operate equipment. The machine

operator is still required to follow

OSHA and other applicable

standards when operating the

equipment.

This system is designed with

Frequency Hopping Spread

Spectrum (FHSS) Technology to

eliminate the RF interference

problem in Radio remote

products.

The control system consists of two

major modules: the remote

station (this unit), and a separate

remote receiver (Digital

Controller) sold separately.

Each transmitter is

preprogrammed with a special

radio ID code. The receiver is

programmed to respond only to

the transmitter with the ID code

for which it is set. This feature

allows the equipment to work in

wireless mode in close vicinity of

each other without interfering

with each other. In the event that

a transmitter becomes damaged

and a new one is needed, the

receiver can be reprogrammed to

respond to the new transmitter.

MINI REMOTE

INSTALLATION:

1.Refer to the wiring chart for

wiring connections.

3.When installing the unit, the

main power should run from the

battery, through a 20 amps fast

blow fuse, to a power switch or

relay; then into the receiver unit.

For best results connect the

receiver main power connections

to the auxiliary terminal of the

ignition switch, PTO switch, or

ignition relay. Use 18 gauge or

heavier wire.

4.All connections must be

properly insulated to protect

against shorts.

FCC REQUIREMENT: Any device

in which this module is installed

must include a label that is

clearly visible containing the

following:

“Contains Module FCC ID:P4U-

MNTA1”

This is a requirement for any

unit that contains this module

and must be done. No

exceptions can be made.

BEFORE APPLYING POWER:

1.Check power and ground

polarity.

2.Check wiring harness for

possible shorts before connecting

remote control to output devices

(i.e., valves, relays) by checking

each mating pin terminal.

3.Read the rest of this manual.

MINI REMOTE

ROUTINE MAINTENANCE:

1. Clean transmitter and

receiver regularly with a damp

cloth and mild detergent.

2. Periodically check receiver

antenna for tightness.

3. Inspect electrical wiring for

wear points or other damage.

Repair as required.

4. Inspect all connections for

looseness or corrosion. Tighten

and/or "seal" as necessary.

MAINTENANCE PRECAUTIONS:

When performing any inspection

or maintenance work on the

MINI REMOTE system, always

exercise care to prevent injury

to yourself and others or

damage to the equipment. The

following are general

precautions that should be

closely followed in carrying out

any maintenance work.

1. Do not have hydraulic power

available to the valves when

performing electrical tests or

downloading programs.

2. Never operate or test any

function if any person is in an

area where they could be hurt

by being hit or squeezed by the

hydraulic equipment.

3. Turn power off before

connecting or disconnecting

valve coils or other electrical

loads.

TROUBLESHOOTING:

This section provides basic

operator level troubleshooting

for the MINI REMOTE system. If,

after following these

instructions, the system still

does not function, check the

hydraulic system then contact

your KAR-TECH representative

for further instructions or

servicing.

MINI REMOTE

TROUBLE SHOOTING CHART

PROBLEM

SOLUTION

1. No operation of all functions when a

function switch is activated.

1. Check to see if a selector switch is in the

proper position.

2. Check that unit power is on.

3. Check that receiver power is on.

4. Check vehicle wiring for power into the

receiver.

5. Check LED status display for system

status.

6. Check for proper grounding of vehicle's

electrical circuit.

7. Check vehicle's hydraulic system

2. Certain functions do not work

1. Check the wiring connection from the

receiver to the valve coil or the output

function that does not work.

2. Check LED status display for system

status.

3. Check vehicle's hydraulic system

4. Check vehicle's electrical system

3. Function operates intermittently.

1. Check for loose connections.

2. Check LED status display for system

status.

3. Check receiver antenna for any damage

and proper connection.

4. Check vehicle's hydraulic system

MINI REMOTE

SPECIFICATIONS

TRANSMITTER

Power supply ........................................... +12V nominal, 9V to 35V transient

Operating temperature - Radio ............................................ -40˚C to +85˚C

Storage temperature........................................................ -40˚C to +100˚C

Frequency ......................................................................... 902-928 MHz

Transmit power (ERIP)................................................................... 10 mW

Vibration ............................................................................ 3G to 200Hz

Shock ...........................................................................................50G

There are no user-serviceable parts inside the Transmitter or the

Receiver. Return the units to the KAR-TECH for service.

Note: For operation with negative ground vehicles only.

WARNING:

The KAR-TECH MINI REMOTE must be operated in compliance with all

applicable safety regulations, rules, and practices. Failure to follow

required safety practices may result in death or serious injury.

The information, specifications, and illustrations in this manual are those in effect at

the time of printing. KAR-TECH reserves the right to change specifications or design at

any time without notice.

MINI REMOTE

INSTRUCTION TO THE USER:

This unit has been tested and found to comply with part 15 of the FCC Rules. Any

changes or modifications not expressly approved by the party responsible for

compliance could void the user's authority to operate the equipment.

NOTE: This equipment has been tested and found to comply with the limits for

a Class A digital device, pursuant to Part 15 of the FCC Rules. These limits are designed

to provide reasonable protection against harmful interference when the equipment is

operated in a commercial environment. This equipment generates, uses, and can

radiate radio frequency energy and, if not installed and used in accordance with the

instruction manual, may cause harmful interference to radio communications.

Operation of this equipment in a residential area is likely to cause harmful interference

in which case the user will be required to correct the interference at his own expense.

The term "IC:" before the certification/registration number only signifies that the

Industry Canada technical specifications were met.

Operation is subject to the following two conditions: (1) this device may not cause

interference, and (2) this device must accept any interference, including interference

that may cause undesired operation of the device.

IMPORTANT NOTICE: To comply with the FCC RF Exposure compliance requirements,

the following antenna installation and device operating configurations must be

satisfied:

The antenna(s) used for this transmitter must be installed to provide a separation

distance of at least 20 cm from all persons and must not be co-located or operate in

conjunction with any other antenna or transmitter.
