Kambrook ARCTIC KFA815 Manual de usuario
Instruction Booklet
Arctic
Tower Fan
KFA815
Important
Please retain your instruction
book for future use.
In the event that you need some assistance with your
Kambrook appliance, please contact our Customer Service
Department on 1300 139 798 (Australia) or 09 271 3980 (New
Zealand). Alternatively, visit us on our website at
www.kambrook.com.au
Contents
Kambrook Recommends p4
Safety First
Your Kambrook Arctic p6
Tower Fan
Using Your Kambrook p7
Arctic Tower Fan
Care and Maintenance p9
Warranty p12
4
Kambrook Recommends Safety First
IMPORTANT: Please retain your
instruction book for future use.
At Kambrook, we believe that safe performance is the first priority in any
consumer product, so that you, our valued customer can confidently
use and trust our products. We ask that any electrical appliance that
you use be operated in a sensible fashion with due care and attention
placed on the following important operating instructions.
Important Safeguards For Your Kambrook
Arctic Tower Fan
• Carefully read all instructions before
operating the Kambrook Arctic Tower
Fan for the first time and save for
future reference.
• To protect against electric shock, do no
immerse the fan, cord or plug in water
or any other liquid
• This fan is intended for household
use only and not for commercial or
industrial use.
• Disconnect the power plug before
dismantling, assembling or before
cleaning and when the fan is not in use.
• Avoid touching mobile parts of the fan.
• Ensure the fan is on a dry and
even surface.
• Never insert fingers, pencils or any other
objects through the guards whenever
the power plug is connected, in
particular while the fan is switched on.
• The fan must not be used if the guards
are not fastened correctly, according
to these instructions.
• Never leave the fan unattended when
in use.
• Do not operate in the presence of
explosives and/or flammable fumes
or liquids.
• Do not unplug the fan by pulling on
the cord.
• Never carry the fan by the cord or yank
to disconnect from an outlet; instead,
grasp the cord and pull to disconnect.
Do not pull the cord around sharp
edges or corners.
5
Important Safeguards For All
Electrical Appliances
• Fully unwind the power cord before use.
• Do not let the power cord hang over
the edge of a bench or table, touch
hot surfaces or become knotted.
• To protect against electric shock do not
immerse the power cord, power plug or
housing in water or any other liquid.
• The appliance is not intended for use
by persons (including children) with
reduced physical, sensory or mental
capabilities, or lack of experience
and knowledge, unless they have
been given supervision or instruction
concerning use of the appliance by a
person responsible for their safety.
• Children should be supervised
to ensure that they do not play with
the appliance.
• It is recommended to regularly inspect
the appliance. To avoid a hazard do
not use the appliance if power cord,
power plug or appliance becomes
damaged in any way. Return the
entire appliance to the nearest
authorised Kambrook Service Centre
for examination and/or repair.
• Any maintenance other than cleaning
should be performed at an authorised
Kambrook Service Centre.
• This appliance is for household use only.
Do not use this appliance for anything
other than its intended use. Do not use
in moving vehicles or boats. Do not use
outdoors. Misuse may cause injury.
• The installation of a residual current
device (safety switch) is recommended
to provide additional safety protection
when using electrical appliances. It
is advisable that a safety switch with
a rated residual operating current
not exceeding 30mA be installed in
the electrical circuit supplying the
appliance. See your electrician for
professional advice.
6
Your Kambrook Arctic Tower Fan
1. 75cm tower fan
2. Choice of 3 speed settings
3. 60° oscillation to disperse the air
throughout the room
4. Two hour auto-off timer
5. Convenient carry handle for
easy portability
6. Small footprint
Parts List (Not Shown)
• Tower body
• 2 piece base
• 5 assembly screws
7
Using Your Kambrook Arctic Tower Fan
Before First Use
Remove any promotional material
from the fan.
IMPORTANT: When
unpacking the fan, check
to see you have received
all the items listed in the
Parts List, before discarding
the packaging.
Assembling Your Arctic
Tower Fan
Base Assembly
1. Align half base (a) together with
half base (b). There are four
support posts on base (a), so
ensure all 4 are covered by base
(b). Firmly snap together the two
halves until the bases are locked in
place and flush. (Fig. 2).
Fig. 1
(a)(b)
Fig. 2
2. Turn the Tower Body upside
down. Place the assembled base
onto the underside of the Tower
Body, ensuring the cord clip is
positioned over the cord. Secure
all five screws.
NOTE: There are 2 different types
of screws. The 2 self tapping
screws are to be used along the
centre of the assembled base. The
3 machine type screws are to be
used in the 3 allocated holes.
3. Tuck the power cord under the
cord clip of the fan base.
4. Flip the tower into the upright
position, and it is ready to use.
8
Using Your Kambrook Arctic Tower Fan continued
To Operate the Arctic
Tower Fan
Plug the cord into a 230V or 240V
power point and switch on.
NOTE: To avoid an electrical circuit
overload, it is recommended that
no other appliances are plugged
into the same circuit as your fan,
when it is in use.
Select the desired air flow setting by
pressing down a speed button:
OFF
LOW
MED
HIGH
Fig. 3
Setting the Oscillation
The oscillation function works in all air
flow settings.
Press down the Swing button to
activate. The fan will begin to
oscillate from side to side.
Press the Swing button again to stop
the fan from oscillating.
Setting the Timer
The Arctic Tower Fan incorporates a
two hour, count down timer, which
will turn off the fan after the selected
preset time has elapsed.
Turn the Timer dial clockwise to the
desired position to operate the timer
(up to 120 minutes).
9
Always switch the Arctic Tower Fan
off, prior to cleaning the housing.
To clean the outside of the fan, wipe
the exterior with a soft, damp cloth.
Never use an abrasive cleaner.
When not in use, store the fan
(preferably in its original box) in a
cool, clean and dry location.
Care and Maintenance
10
Notes
