Kärcher BR 40/25 EP Bp Manual de usuario

QUICKSTART

5.964-030.0 08/11

Warning

These are only brief instructions! Please read and comply with these instructions prior to using or servicing your

appliance.

The non-compliance of the operating and safety instructions may lead to damages of the appliance and to dangers

for the operator and other persons.

Start up

A b

Ep model

A Establish mains contact.

Bp model

A Unplug the charger from the mains.

B Place the mains cable into the storage com-

partment.

A Open the cover.

B Fill in the water up to the MAX marking of the

filling level display. Maximum temperature of

the liquid 60°C.

C Pour in detergent.

D Close the lid.

BR/BD 40/25 EP, Bp

QUICKSTART

5.964-030.0 08/11

Operation

1A b Starting the machine

A Turn the programme selector switch to a

cleaning programme

B Press control switch.

2Cleaning Programs

ANormal mode

Wet clean the floor and vacuum up dirt water.

BIntense mode

Wet clean the floor and allow the detergent to

react.

CVacuum mode

Vacuum the wastewater.

DPolishing mode

Polishing the floor without the application of

liquid.

3ASetting the water quantity

A Adjust the water quantity using the regulating

button according to the dirt on the floor cover-

ing.

4ASwivel in the transport roller.

A Swivel the transport roller in via the foot ped-

al.

5ALower the vacuum bar

A Lower the lever for lowering the vacuum bar

downwards; the vacuum bar is lowered.

6ASetting the Advance Speed (BD clean-

ing head only)

A Set the advance speed.

Increase the advance drive:

Turn the button in "+" direction.

Decrease the advance drive:

Turn the button in "–" direction.

QUICKSTART

5.964-030.0 08/11

Finish operation

Turn off the appliance

A Close the regulatory button for setting the wa-

ter quantity.

B Release the control handle.

C Pull suction bar lowering lever upwards.

D Turn the program selection switch to "OFF".

E Swivel the transport roller out via the foot

pedal.

Ep model

F Disconnect the mains connection cable.

2A b CEmptying the Dirt Water Reservoir

몇Warning

Please observe the local provisions regarding the

wastewater treatment.

A Take the water discharge hose from the sup-

port and lower above a suited collection de-

vice.

B Rinse the dirt water tank with clear water.

Take the water discharge hose from the sup-

port and lower above a suited collection de-

vice.

C Leave the cover open to let it dry.

3AEmptying the Fresh Water Tank

몇Warning

Please observe the local provisions regarding the

wastewater treatment.

A Remove the suction hose coupling for drain-

ing off the fresh water and hold it over a suit-

able container.

4ACharging battery

Bp model

A Charge battery, if required.

Insert the plug of the connecting cable into

the socket.

QUICKSTART

5.964-030.0 08/11

Maintenance and care

daily

monthly

Kärcher Customer Service

b몇Warning

Please observe the local provisions re-

garding the wastewater treatment.

A Take the water discharge hose

from the support and lower above a

suited collection device.

B Rinse the dirt water tank with clear

water.

Take the water discharge hose

from the support and lower above a

suited collection device.

Leave the cover open to let it dry.

C Remove the suction hose coupling

for draining off the fresh water and

hold it over a suitable container.

Rinse the fresh water tank with

clear water.

2AA Check the fluff filter, clean if re-

quired

5A b A Clean the vacuum lips on the vacu-

um bar, turn or replace if required

B Clean the suction channel.

6AA Clean the seals between dirt water

reservoir and cover and check for

tightness, replace if required.

7AEvery 200 operating hours

Every 600 operating hours

Every 800 operating hours

QUICKSTART

5.964-030.0 08/11

Troubleshooting

Appliance cannot be started

Ep model

A Establish mains contact.

Bp model

A Please watch battery indicator.

Charge the battery if required.

b C

Insufficient vacuum performance

A Clean the seals between dirt water reservoir

and cover and check for tightness, replace if

required.

B Clean the vacuum lips on the vacuum bar,

turn or replace if required

C Check suction hose for blockages; clean if re-

quired.

Check connection between suction hose and

suction bar and suction hose and wastewater

tank.

D Check the fluff filter, clean if required

E Check the setting of the vacuum bar.

F Check if the cover on the dirt water discharge

hose is closed

3A b Insufficient cleaning result

A Check brush for wear and tear and clean it.

Check the brushes for wear (bristle length at

least 10 mm), replace if required.

4A b Insufficient water quantity

A Check fresh water level, refill tank if neces-

sary.

B Adjust the water quantity using the regulating

button according to the dirt on the floor cover-

ing.

5Brushes do not turn

Check the brushes for blockage due to foreign

particles, remove them if found.
