Kärcher B 40 C Bp Manual de usuario

QUICKSTART

5.965-085.0 07/13

Warning

These are only brief instructions! Please read and comply with these instructions prior to using or servicing your

appliance.

The non-compliance of the operating and safety instructions may lead to damage of the appliance and to risks for

the operator and other persons.

Start up

1A B A Unplug the charger from the mains.

B Coil the battery charging cable around the ca-

ble hooks.

2ABA Open the lock of the fresh water reservoir.

Fill fresh water (maximum 60 °C) until the

lower edge of the filling nozzle.

Close the lock of the fresh water reservoir.

B Connect the hose to the automatic filling sys-

tem and open the water supply (max. 60 °C,

max. 5 bars).

Monitor the appliance - the automatic filling

system will interrupt the water supply when

the tank is full.

Shut off the water supply and disconnect the

hose from the appliance.

몇Warning

Risk of damage. Only use the recommended de-

tergents. With respect to different detergents the

operator bears the increased risk regarding the

operational safety and danger of accident.

Only use detergents that are free from solvents,

hydrochloric acid and hydrofluoric acid.

Follow the safety instructions for using deter-

gents.

Note

Do not use highly foaming detergents.

C Add the detergent to the fresh water reser-

voir.

B 40 C Bp

QUICKSTART

5.965-085.0 07/13

Operation

1ASetting the water quantity

A Adjust the water quantity using the regulating

button according to the dirt on the floor cover-

ing.

2ALower the cleaning head

A Press the pedal for lowering the cleaning

head downwards slightly and then move it to

the left. This unlocks the pedal. Release the

pedal slowly upwards.

The cleaning head is lowered.

3ALower the vacuum bar

A Pull the lever out and press it down; the vac-

uum bar is lowered.

4FCleaning Programs

AEco mode

Wet clean the floor and vacuum up dirt water.

BNormal mode

Wet clean the floor and vacuum up dirt water.

CIntense mode

Wet clean the floor and allow the detergent to

react.

DVacuum mode

Vacuum the wastewater.

EPolishing mode

Polishing the floor without the application of

liquid.

F Turn the program selection switch to the de-

sired cleaning program.

5ACleaning

Caution

Risk of damage to the floor covering. Do not op-

erate the appliance on the spot.

A Operate the safety switch.

The brushes rotate; water is dispensed to the

brushesdependingonthesetting.Depending

on the selected programme, the suction tur-

bine is running.

Ride along the surface to be cleaned with a

suitable, even speed.

QUICKSTART

5.965-085.0 07/13

Finish operation

Shutting Down the Appliance

A Close the regulatory button forsettingthewa-

ter quantity.

B Settheprogramselectionswitchtosuctionor

vacuuming.

Drivetheapplianceforward for another 1-2 m

to draw off residual water.

C Lift the cleaning head.

D Release the safety switch.

E Raise the vacuum bar.

F Set the programme selector switch to "OFF".

2A B

Emptying the Dirt Water Reservoir

몇Warning

Pleaseobservethelocalprovisionsregardingthe

wastewater treatment.

A Take the water discharge hose from the sup-

port and lower above a suited collection de-

vice.

Squeeze or kink the suction hose coupling

sleeve.

Open wastewater hose cover.

Drain off the dirt water - regulate the water

quantity by pressing or bending.

B Rinse the wastewater reservoir with clean

water or with the rinsing system for the

wastewater reservoir (option).

C Leave the cover open to let it dry.

Press the lock of the wastewater reservoir in

and close the cover of the wastewater reser-

voir so that a gap remains open to facilitate

drying.

3A B Emptying the Fresh Water Tank

몇Warning

Pleaseobservethelocalprovisionsregardingthe

wastewater treatment.

A Loosen the lid for emptying the fresh

water - do not remove it fully. Drain water.

B Torinsethefreshwaterreservoir,removethe

cover completely and remove the fresh water

filter.

Check fresh water filter; clean if required.

QUICKSTART

5.965-085.0 07/13

4AEmpty waste container (only with R

cleaning head)

A Remove bulk waste container and empty it.

5ACharging battery

A Charge the battery if required.

Maintenance and care

daily

monthly

Kärcher Customer Service

1A B 몇Warning

Riskofdamage.Donot wash downthe

appliance with water and do not use

aggressive detergents.

A Remove the coarse dirt sieve from

thewastewaterreservoir and clean

it.

B Check the fluff filter, clean if re-

quired.

2AA Remove the water distribution bar

on the cleaning head and clean the

water channel.

Finish operation

QUICKSTART

5.965-085.0 07/13

3ABA Clean the vacuum lips and the wip-

inglips,checkforwearand replace

if required.

B Clean the suction channel.

4AA Clean brush.

Check the brushes for wear, re-

place if required.

B Clean the outside of the appliance

with a damp cloth which has been

soaked in mild detergent.

5AA Clean the seals between dirt water

reservoir and cover and check for

tightness, replace if required.

B Clean the brush tunnel (only BR

model).

6Have annual customer service work

performed.

Maintenance and care

daily

monthly

Kärcher Customer Service
