TM-923U

9-Inch B&W Video Monitor

FEATURES

9" B&W Video Monitor

High Resolution Pictures

With 700 lines of horizontal resolution, the

monitor provides sharp reproduction of

every detail.

Looped-through Output

Convenient looped-through connection is

available.

Flexible Mounting

Two TM-923Us can be mounted together in

a standard EIA 19" rack using the optional

UC-P1016U Rack Mount Adapter.

ARCHITECTS’ AND ENGINEERS’ BID SPECIFICATION

The black-and-white video monitor shall be a JVC Model TM-923U or equivalent. It shall

have a 9" diagonal screen with horizontal resolution of 700 lines center, with an actual

visual size of 9-13/16" H x 8-11/16" W. The monitor shall feature manual controls for

on/off, brightness, contrast, vertical hold, horizontal hold, audio level, height, vertical

linearity, scan size (underscanning or normal), and loopthrough type (75 ohm termination

switch or Hi-Z). Terminals on the monitor shall be 1 video input and 1 video output, each

1.0Vp-p 75 ohm composite via BNC connector. The monitor shall be UL listed. The

dimensions shall be 9-13/16" H x 8-11/16" W x 11-1/16" D and it shall weigh 13.7 lbs.

R

TM-923U

Specifications

CRT 9", 90° deflection

Scanning frequency H: 15.75 kHz

V: 60 Hz

Horizontal resolution More than 700 TV lines ( at center)

Input Video x 1: VS, 1 V(p-p), 75 ohms (BNC)

Output (looped-through) Video x 1: VS, 1 V(p-p), 75 ohms (BNC)

S/N ratio More than 55 dB

Video frequency response 15 kHz to 9 MHz

Sweep lineanty Less than 7%

Power requirement 120 V AC

Power consumption Approx. 25 W

Operating temperature range 14°F to 122°F (-10°C to 50°C)

Weight Approx. 13.7 lbs (6.2 kg)

Dimensions

11-1/168-11/16

9-13/16

(Unit: inches)

TM-923 VIDEO MONITOR

POWER

PUON
