JVC DR-M100SEF Manual de usuario

DR-M100S

IS HERE TO HELP!

TOLL FREE: 1(800)252-5722

http://www.jvc.com

QUICK

START

GUIDE

QUICK

START

GUIDE

QUICK

START

GUIDE

Check Accessories

STANDBY/ON

RAM/RW

PUSH-OPEN

RF cable

Audio/Video cable

“AA“ battery x 2

(For remote control)

Remote control

LPT1013-004A

0305MNH-SW-SC

BASIC RECORDING

BASIC PLAYBACK

VHS/DV D

REC

VHS DVDDUBBING

DV IN

STANDBY/ON

RAM/RW

PUSH-OPEN

For more information, see the instruction manual. ( pg. 34, "Basic Recording")

NOTE:

DVD disc must be finalized to play

on most DVD players.

(pg.64,"Finalize A Disc")

NOTE:

When you use a DVD-RW disc, format it in "VR MODE" or "VIDEO MODE".

( pg. 63, "Format A Disc")

Select TV input/channel first.

Editing or Live

Memory Playback

is possible.

Can be rewritten

100,000 times.

Can be rewritten

1,000 times.

Playable on

other DVD players

or PCs

(after finalized).

Recordable Discs

DVD-RAM DVD-RW DVD-R

For more information, see the instruction manual. ( pg. 22, "Basic Playback")

1Insert a disc

Inserting Disc

Start Playback

Stop Playback

1Insert a disc

Select Channel/

Input

For cable box or DBS receiver users,

set the channel to the external input

("L-1" or "F-1").

Select Mode

For the recording mode, see page 34

on the instruction manual.

Stop Recording

While holding

REC, press PLAY

Start Recording

Connection Without Cable Box Or DBS Receiver

AC outlet

Antenna or cable

Connect

the aerial.

With antenna or cable (no cable box), wait for clock and

channels to be set automatically.( pg. 17, “Plug & Play Set”)

Connect

your TV.

For more information, see the instruction manual. ( pg. 16, "Basic Connection")

Video

Audio (L)

Audio (R)

Video

Aucio (L)

Audio (R)

OUT

ANTENNA

OUTPUT

INPUT

Plug to the

AC outlet.

Audio/Video cable

(supplied)

RF cable

(supplied)

RF cable

(not

supplied)

AC outlet

Connection With Cable Box Or DBS Receiver

(When your TV has only audio/video connectors)

With antenna or cable, wait for clock and channels to be

set automatically.( pg. 17, “Plug & Play Set”)

AC outlet

Antenna

or cable

Connect

the aerial.

Cable box or

DBS receiver

INPUT

Video

Audio (L)

Audio (R)

OUTPUT

Video

Audio (L)

Audio (R)

RF IN

ANTENNA OUT

ANTENNA IN

OUTPUT

RF IN TV

RF OUT

INPUT

Video

Audio (L)

Audio (R)

Video

Audio (L)

Audio (R)

Audio/Video

cable

(not supplied)

Audio/Video

cable

(supplied)

RF cable

(not supplied)

RF cable

(not

supplied)

RF cable

(supplied)

Connection With Cable Box Or DBS Receiver

(When your TV has component video connectors)

AC outlet

NOTE: When watching the images with this connection, set to the progressive scan mode.

( pg. 60, "Scan Mode Set")

With antenna or cable, wait for clock and channels to be

set automatically.( pg. 17, “Plug & Play Set”)

AC outlet

Antenna

or cable

Connect

the aerial.

Cable box or

DBS receiver

INPUT

Video

Audio (L)

Audio (R)

OUTPUT

Video

Audio (L)

Audio (R)

RF IN

ANTENNA OUT

ANTENNA IN

OUTPUT

RF IN TV

RF OUT

INPUT

Video

Audio (L)

Audio (R)

Video

Audio (L)

Audio (R)

Component video cable

(not supplied)

COMPONENT

VIDEO INPUT

OUTPUT

Audio/Video

cable

(supplied) Audio/Video

cable

(not supplied)

RF cable

(not supplied)

RF cable

(not

supplied)

RF cable

(supplied)
