JVC GR-SX19EF Manual de usuario
No. 86713
2003/03
COPYRIGHT © 2003 VICTOR COMPANY OF JAPAN, LTD.
COMPACT VHS CAMCORDER
Regarding service information other than these sections, refer to the service manual No. 86712 (GR-SX25EX,GR-SXM49EX).
Also, be sure to note important safety precautions provided in the service manual.
GR-SX19EF,GR-SXM29EF
SERVICE MANUAL
CARACTÉRISTIQUES TECHNIQUES
VHS
PA L
625
GR-SX19EF,GR-SXM29EF M3C6B2,M3C622
Réglage de la balance des blancs
:Automatique/manuel
Écran LCD :2,5" mesuré en diagonale, écran
(modèles LCD/matrice active TFT
applicables uniquement)
Haut-parleur :Monaural
(modèles applicables uniquement)
Connecteurs
Vidéo :1Vcc,75 Ωasymétrique,sortie analogique (via la prise de
sortie vidéo)
Audio :300 mV (rms), 1 kΩ, sortie analogique
(via la prise de sortie audio)
S-Vidéo :Y:1 Vcc,75 Ω, sortie analogique
C:0,30 Vcc,75 Ω, sortie analogique
Adaptateur secteur
Alimentation :CA 110 V à 240 V `, 50 Hz/60 Hz
Sortie :CC 11 V },1 A
Accessoires en option
• Batterie BN-V12U, BN-V20U, BN-V400U
• Cassettes compactes S-VHS ( ) SE-C45/30
• Cassettes compactes VHS ( ) EC-60/45/30
• Sac de transport CB-V7U
• Adaptateur de cassette C-P7U
Certains accessoires ne sont pas disponibles dans certaines r é gions.Veuillez consulter
votre revendeur JVC le plus proche avant d ’acheter des accessoires en option.
Les caractéristiques indiquées sont pour le mode SP sauf indication contraire.
Erreurs et omissions possibles.
Présentation et caractéristiques modifiables sans préavis.
Camescope
Général
Format :Standard S-VHS/VHS PAL
Alimentation :11 V CC }(En utilisant l’adaptateur secteur)
6 V CC }(En utilisant la batterie)
Consommation
Viseur allumé :4,2 W (GR-SXM29 uniquement)
4,0 W (GR-SX19 uniquement)
Écran LCD* allumé :4,7 W (GR-SXM29 uniquement)
*Mod è les applicables uniquement.
Système de signal :Type PAL
Système d’enregistrement vidéo
Luminance :Enregistrement FM
Couleur :Enregistrement direct de sous-porteuse convertie
Conforme au standard VHS
Cassette :Cassette /
Vitesse de bande
SP :23,39 mm/s
LP :11,70 mm/s
Durée maximale d’enregistrement
SP :60 mn
LP :120 mn (avec une cassette EC-60)
Température de fonctionnement :0°C à 40°C
Humidité de fonctionnement :35% à 80%
Température de stockage :–20°C à 50°C
Poids :Environ. 840 g (GR-SXM29 uniquement)
Environ. 750 g (GR-SX19 uniquement)
Dimensions :113 mm x 117 mm x 199 mm (GR-SXM29 uniquement)
(L x H x P) 108 mm x 117 mm x 199 mm (GR-SX19 uniquement)
(avec l’é cran LCD* ferm é et le viseur compl è tement inclin é
vers le bas)
*Mod è les applicables uniquement.
Capteur :CCD de 1/6"
Objectif :F1,6, f = 2,7 mm à 43,2 mm, zoom électrique 16:1 avec commande
de diaphragme automatique et commande macro, diamètre du filtre
40,5 mm
Viseur :Viseur é lectronique avec tube à rayons cathodiques noir et blanc de
0,5"
ITEM MODEL GR-SX25EX GR-SX19EF
BATTERY PACK BN-V11U-E BN-V11U-F
DC LIGHT Used Not Used
!REF. MODEL GR-SX25EX GR-SX19EF
NO ITEM
!5INST BOOK(GERMAN) LYT1060-002C —
!5INST BOOK(FRENCH) LYT1060-003C LYT1062-001B
!5INST BOOK(DUTCH) LYT1060-004C —
!5INST BOOK(SPANISH) LYT1060-005C —
!5INST BOOK(ITALIAN) LYT1060-006C —
8WARRANTY CARD BT-54013-5 BT-54008-4
!10 BATTERY PACK ASSY YQ10629E YQ10629F
TABLE OF CONTENTS
DIFFERENT TABLE .................................................................................................................................................................................... 1 to 5
CHARTS AND DIAGRAMS (2-1 to 2-6)
1. MAIN CIRCUIT BOARD ............................................................................................................................................................................. 2-1
PARTS LIST
1. PACKING AND ACCESSORY ASSEMBLY <M1> ..................................................................................................................................... 3-1
The following table indicate main different points between models GR-SX25EX and GR-SX19EF.
PACKING AND ACCESSORY ASSEMBLY <M1>
The following table indicate main different points between models GR-SXM49EX and GR-SXM29EF.
ITEM MODEL GR-SXM49EX GR-SXM29EF
BATTERY PACK BN-V11U-E BN-V11U-F
DC LIGHT Used Not Used
The following table indicate different parts number between models GR-SX25EX and GR-SX19EF.
Notes : Mark — is not used.
1
!REF. MODEL GR-SX25EX GR-SX19EF
NO ITEM
101 C.COVER(S)ASSY LY20928-001D LY20928-004E
101F STICKER(C) LY44007-001A —
101H STICKER(B) LY43982-001A LY43982-002A
121 LOWER CASE ASSY LY20925-002C LY20925-004E
!135 F.COVER ASSY LY20926-001C LY20926-003D
135D STICKER(A) LY43983-001A LY43983-002A
!135E CAUTION LABEL LY44141-001A —
135G COVER(LIGHT) — LY32965-001A
137 DC LIGHT LY33067-001A —
145 FRAME ASSY LY20949-001B *LY20949-001E
146 S.CASE(MAIN) LY32966-001A LY32966-001B
154 FRONT FRAME SA. LY31790-001A *—
154A TAPE GUIDE YQ44144-1-1 *—
157 TOP OPE UNIT LY10392-001C LY10392-002D
158 REAR BOARD ASSY LY20952-001C *LY20952-001D
251 OP BLOCK ASSY LY33085-001A *LY33085-001C
251C SCREW PTY31727-216(,X5) *PTY33085-001(,X7)
251D SCREW PTY33085-001(,X4) *PTY31727-116(,X2)
255 CCD BASE ASSY LYH30437-001 *LYH30437-001A
261 FRONT FRAME SA. LY44193-001B *LY44193-001C
FINAL ASSEMBLY <M2>
2
Notes : Mark — is not used.
Mark * reference model was also changed.
135
135C
135B
135A
135F
135F
135D
135F
136
g
m
f
139
a
135G
As for the difference in a “FINAL ASSEMBLY
<M2>” drawing, 135G is added.
As for the difference in a “FINAL ASSEMBLY <M2>”
drawing, 251C and 251D is changed.
F9
F10
251C
251C
252
253 254
255
256
256
251B
OP BLOCK
SECTION
251C
251C
251E
251D
251D
CCD BOARD
ASSEMBLY
<02>
251C
251
251C 251C
251A
n
3
!REF. MODEL GR-SX25EX GR-SX19EF
NO ITEM
PW1 MAIN BOARD ASSY YB10400EB1-02 YB10400EG1-03
IC4002 IC(DIGITAL) MSM548331TA —
Q108 DIGI TRANSISTOR DTC114EE-X —
Q109 DIGI TRANSISTOR DTC114EE-X —
Q110 TRANSISTOR — *2SC4617/QR/-X
Q111 TRANSISTOR — *2SC4617/QR/-X
Q112 TRANSISTOR — *2SC4617/QR/-X
Q113 TRANSISTOR — *2SC4617/QR/-X
Q114 TRANSISTOR — *2SC4617/QR/-X
Q115 TRANSISTOR — *2SC4617/QR/-X
Q116 TRANSISTOR — *2SC4617/QR/-X
Q117 TRANSISTOR — *2SC4617/QR/-X
Q6306 MOS FET 2SK3577-X —
Q9101 TRANSISTOR — *2SC4617/QR/-X
Q9102 TRANSISTOR — *2SC4617/QR/-X
Q9103 TRANSISTOR — *2SC4617/QR/-X
Q9104 TRANSISTOR — *2SC4617/QR/-X
C1623 C CAPACITOR NCB31CK-104X *NCB31CK-224X
C4024 C CAPACITOR NCF31EZ-104X —
C4044 C CAPACITOR NCB30JK-105X —
C6307 E CAPACITOR NEA71CM-106X —
R115 MG RESISTOR NRSA63J-101X *NRSA63J-0R0X
R164 MG RESISTOR NRSA63J-221X *NRSA63J-121X
R165 MG RESISTOR NRSA63J-151X *NRSA63J-560X
R172 MG RESISTOR NRSA63J-0R0X *NRSA63J-101X
R181 MG RESISTOR — *NRSA63J-474X
R182 MG RESISTOR — *NRSA63J-474X
R183 MG RESISTOR — *NRSA63J-474X
R184 MG RESISTOR — *NRSA63J-474X
R187 MG RESISTOR — *NRSA63J-474X
R188 MG RESISTOR — *NRSA63J-474X
R190 MG RESISTOR — *NRSA63J-221X
R4013 MG RESISTOR NRSA63J-102X —
R4036 MG RESISTOR NRSA63J-101X —
R5220 MG RESISTOR — *NRSA63J-220X
R5221 MG RESISTOR — *NRSA63J-220X
R6306 MG RESISTOR NRSA63J-0R0X —
R6307 MG RESISTOR NRSA63J-104X —
R6314 MG RESISTOR NRS12BK-R47W —
R9102 MG RESISTOR — *NRSA63J-154X
R9104 MG RESISTOR — *NRSA63J-154X
RA9101
NET RESISTOR — *NRZ0038-474X
CN6 CONNECTOR QGA1201C2-02X —
OT1SPACER-A LY30016-049A(,X1) *LY30016-049A(,X2)
SD1 SHIELD PLATE LY43421-001A *LY43421-001B
MAIN BOARD ASSEMBLY <01>
!REF. MODEL GR-SXM49EX GR-SXM29EF
NO ITEM
CCD BOARD ASSEMBLY <02>
PW1 CCD BOARD ASSY YB10400A2-02 *YB10400A2-03
Notes : Mark — is not used.
Mark * reference model was also changed.
4
!REF. MODEL GR-SXM49EX GR-SXM29EF
NO ITEM
PACKING AND ACCESSORY ASSEMBLY <M1>
!5INST BOOK(GERMAN) LYT1060-002C —
!5INST BOOK(FRENCH) LYT1060-003C LYT1062-001B
!5INST BOOK(DUTCH) LYT1060-004C —
!5INST BOOK(SPANISH) LYT1060-005C —
!5INST BOOK(ITALIAN) LYT1060-006C —
8WARRANTY CARD BT-54013-5 BT-54008-4
!10 BATTERY PACK ASSY YQ10629E YQ10629F
The following table indicate different parts number between models GR-SXM49EX and GR-SXM29EF.
!REF. MODEL GR-SXM49EX GR-SXM29EF
NO ITEM
FINAL ASSEMBLY <M2>
101 C.COVER(M)ASSY LY20927-002C LY20927-001C
101F STICKER(C) LY44007-001A —
121 LOWER CASE ASSY LY20925-001D LY20925-003F
!135 F.COVER ASSY LY20926-001C LY20926-003D
135D STICKER(A) LY43983-001A LY43983-002A
!135E CAUTION LABEL LY44141-001A —
135G COVER(LIGHT) — LY32965-001A
137 DC LIGHT LY33067-001A —
145 FRAME ASSY LY20949-001B *LY20949-001E
146 S.CASE(MAIN) LY32966-001A LY32966-001B
154 FRONT FRAME SA. LY31790-001A *—
154A TAPE GUIDE YQ44144-1-1 *—
157 TOP OPE UNIT LY10392-001C LY10392-002D
158 REAR BOARD ASSY LY20952-001C *LY20952-001D
161 SPACER(A) LY30030-072A *—
251 OP BLOCK ASSY LY33085-001A *LY33085-001C
251C SCREW PTY31727-216(,X5) *PTY33085-001(,X7)
251D SCREW PTY33085-001(,X4) *PTY31727-116(,X2)
255 CCD BASE ASSY LYH30437-001 *LYH30437-001A
261 FRONT FRAME SA. LY44193-001B *LY44193-001C
135
135C
135B
135A
135F
135F
135D
135F
136
g
m
f
139
a
135G
As for the difference in a “FINAL ASSEMBLY
<M2>” drawing, 135G is added.
As for the difference in a “FINAL ASSEMBLY <M2>”
drawing, 251C and 251D is changed.
F9
F10
251C
251C
252
253 254
255
256
256
251B
OP BLOCK
SECTION
251C
251C
251E
251D
251D
CCD BOARD
ASSEMBLY
<02>
251C
251
251C 251C
251A
n
Notes : Mark — is not used.
Mark * reference model was also changed.
5
!REF. MODEL GR-SXM49EX GR-SXM29EF
NO ITEM
MONITOR ASSEMBLY <M5>
!500 MONITOR ASSY LY20947-001A LY20947-003A
!501 M.COVER ASSY LY33066-001A LY33066-003A
501A STICKER(B) LY43982-001A LY43982-002A
502 M.CASE ASSY LY33077-001B LY33077-001C
503 MON.HINGE ASSY LY33005-001B *LY33005-001C
519 SPACER(A) LY30030-092A *—
!REF. MODEL GR-SXM49EX GR-SXM29EF
NO ITEM
PW1 MAIN BOARD ASSY YB10400EA1-02 YB10400ED1-03
IC4002 IC(DIGITAL) MSM548331TA —
Q108 DIGI TRANSISTOR DTC114EE-X —
Q109 DIGI TRANSISTOR DTC114EE-X —
Q110 TRANSISTOR — *2SC4617/QR/-X
Q111 TRANSISTOR — *2SC4617/QR/-X
Q112 TRANSISTOR — *2SC4617/QR/-X
Q113 TRANSISTOR — *2SC4617/QR/-X
Q114 TRANSISTOR — *2SC4617/QR/-X
Q115 TRANSISTOR — *2SC4617/QR/-X
Q116 TRANSISTOR — *2SC4617/QR/-X
Q117 TRANSISTOR — *2SC4617/QR/-X
Q6306 MOS FET 2SK3577-X —
Q9101 TRANSISTOR — *2SC4617/QR/-X
Q9102 TRANSISTOR — *2SC4617/QR/-X
Q9103 TRANSISTOR — *2SC4617/QR/-X
Q9104 TRANSISTOR — *2SC4617/QR/-X
C1623 C CAPACITOR NCB31CK-104X *NCB31CK-224X
C4024 C CAPACITOR NCF31EZ-104X —
C4044 C CAPACITOR NCB30JK-105X —
C6307 E CAPACITOR NEA71CM-106X —
R115 MG RESISTOR NRSA63J-101X *NRSA63J-0R0X
R164 MG RESISTOR NRSA63J-221X *NRSA63J-121X
R165 MG RESISTOR NRSA63J-151X *NRSA63J-560X
R172 MG RESISTOR NRSA63J-0R0X *NRSA63J-101X
R181 MG RESISTOR — *NRSA63J-474X
R182 MG RESISTOR — *NRSA63J-474X
R183 MG RESISTOR — *NRSA63J-474X
R184 MG RESISTOR — *NRSA63J-474X
R187 MG RESISTOR — *NRSA63J-474X
R188 MG RESISTOR — *NRSA63J-474X
R190 MG RESISTOR — *NRSA63J-221X
R4013 MG RESISTOR NRSA63J-102X —
R4036 MG RESISTOR NRSA63J-101X —
R5220 MG RESISTOR — *NRSA63J-220X
R5221 MG RESISTOR — *NRSA63J-220X
R6306 MG RESISTOR NRSA63J-0R0X —
R6307 MG RESISTOR NRSA63J-104X —
R6314 MG RESISTOR NRS12BK-R47W —
R9102 MG RESISTOR — *NRSA63J-154X
R9104 MG RESISTOR — *NRSA63J-154X
RA9101 NET RESISTOR — *NRZ0038-474X
CN6 CONNECTOR QGA1201C2-02X —
OT1SPACER-A LY30016-049A(,X1) *LY30016-049A(,X2)
SD1 SHIELD PLATE LY43421-001A *LY43421-001B
MAIN BOARD ASSEMBLY <01>
!REF. MODEL GR-SXM49EX GR-SXM29EF
NO ITEM
CCD BOARD ASSEMBLY <02>
PW1 CCD BOARD ASSY YB10400A2-02 *YB10400A2-03
Notes : Mark — is not used.
Mark * reference model was also changed.
Printed in Japan
200303WPC
(No.86713)
AV & MULTIMEDIA COMPANY CAMCORDER CATEGORY 12, 3-chome, Moriya-cho, kanagawa-ku, Yokohama, kanagawa-prefecture, 221-8528, Japan
VICTOR COMPANY OF JAPAN, LIMITED
Este manual sirve para los siguientes modelos
1
Tabla de contenidos
Idiomas:
Otros manuales de Videocámara de JVC
JVC
JVC GYHD110U - Camcorder - 720p Manual de usuario
JVC
JVC LYT1037-001A Instrucciones de montaje
JVC
JVC GZ-F125 Manual de usuario
JVC
JVC GZ-MG67US Guía de inicio rápido
JVC
JVC GRD72US - MiniDV Digital Camcorder Manual de instrucciones
JVC
JVC GY-DV300U - 1/3" 3-ccd Dv Camcorder Instrucciones de instalación y funcionamiento
JVC
JVC GY-DV700W Manual de usuario
JVC
JVC GY-HD250CHU Manual de usuario
JVC
JVC TK-C1460B Manual de usuario
JVC
JVC Enverio GZ-MS250 BEK Manual de operación y mantenimiento
JVC
JVC Everio GZ-VX715BEK Manual de operación y mantenimiento
JVC
JVC GR-DVL500 Manual de usuario
JVC
JVC GR-AXM341 Manual de usuario
JVC
JVC GY-HD250 Manual de usuario
JVC
JVC GR-D750AH Manual de usuario
JVC
JVC GZ-N1 Manual de operación y mantenimiento
JVC
JVC GR-D750AS Manual de usuario
JVC
JVC GY-DV5000 Instrucciones de instalación y funcionamiento
JVC
JVC Connected Cam GY-HC550U Manual de usuario
JVC
JVC GZ-MG39U Manual de usuario
Manuales populares de Videocámara de otras marcas
Insignia
Insignia NS-DCC5HB09 - Camcorder - 720p Manual de usuario
MYDLINK
MYDLINK DCS-6100LH Manual de usuario
Sony
Sony video Hi8 Handycam CCD-TR555 Manual de usuario
SECURECOM
SECURECOM V-5014B Manual de usuario
Panasonic
Panasonic HDC-SD100 Manual de usuario
Sharper Image
Sharper Image U-VIDEO Manual de usuario
