SERVICE MANUAL

No. 86660

December 2001

This service manual is printed on 100% recycled paper.

(The specifications shown pertain specifically to the model GR-SXM745U)

COMPACT VHS CAMCORDER

SPECIFICATIONS

Regarding service information other than these sections, refer to the GR-SXM340U and GR-SXM740U service manual (No. 86656).

Also, be sure to note important safety precautions provided in the service manual.

GR-AXM236U,AXM240U,SXM240U

SXM245U,SXM248U

AXM341U,SXM540U,SXM745U

Camcorder

General

Format : S-VHS/VHS NTSC standard

Power source : DC 11 V (Using AC Adapter)

DC 6 V (Using battery pack)

Power consumption

Viewfinder on : 4.0 W

LCD monitor on : 4.5 W

Video light : 3.0 W

Signal system : NTSC-type

Video recording system

Luminance : FM recording

Color : Converted sub-carrier direct recording

Conforms to VHS standard

Cassette : / cassette

Tape speed

SP : 33.35 mm/sec. (1-5/16 ips)

EP : 11.12 mm/sec. (7/16 ips)

Recording time (max.)

SP : 40 minutes

EP : 120 minutes

(with TC-40 cassette)

Operating temperature

: 0°C to 40°C (32°F to 104°F)

Operating humidity : 35% to 80%

Storage temperature

: –20°C to 50°C (–4°F to 122°F)

Weight : Approx. 930 g (2.1 lbs)

Dimensions : 200 mm x 112 mm x 118 mm (7-7/8" x 4-7/16" x 4-11/16")

(W x H x D) (with the LCD monitor closed and with the viewfinder fully

tilted downward)

Pickup : 1/4" format CCD

Lens : F1.6, f = 3.9 mm to 62.4 mm,

16:1 power zoom lens with auto iris and macro control, filter

diameter 40.5 mm

Viewfinder : Electronic viewfinder with 0.5" black/white CRT

White balance

adjustment : Auto/Manual adjustment

Some accessories are not available in some areas. Please consult your

nearest JVC dealer for details on accessories and their availability.

Specifications shown are for SP mode unless otherwise indicated.

E & O.E. Design and specifications subject to change without notice.

LCD monitor : 3.5" diagonally measured, LCD panel/TFT active

matrix system

Speaker : Monaural

Connectors

Video : 1 V (p-p), 75 Ωunbalanced, analog output (via Video

output connector)

Audio : 300 mV (rms), 1 kΩanalog output

(via Audio output connector)

Digital :ø3.5 mm, 4-pole, mini-head jack

S-Video :Y: 1 V (p-p), 75 Ω, analog output

C: 0.29 V (p-p), 75 Ω, analog output

AC Adapter

Power requirement

U.S.A. and Canada : AC 120 V`, 60 Hz

Other countries : AC 110 V to 240 V`, 50 Hz/60 Hz

Output : DC 11 V , 1 A

Optional Accessories

• Battery Packs BN-V12U, BN-V20U, BN-V400U

• A/V (Audio/Video) Cable

• Compact S-VHS ( ) Cassettes

ST-C-40/30/20

• Compact VHS ( ) Cassettes TC-40/30/20

• Active Carrying Bag CB-V7U

TABLE OF CONTENTS

DIFFERENT TABLE ........................................................................................................................................................... 1 to 4

5. PARTS LIST (5-1 to 5-6)

5.1 PACKING AND ACCESSORY ASSEMBLY <M1> ........................................................................................................ 5-1

5.2 FINAL ASSEMBLY <M2> .............................................................................................................................................. 5-3

5.3 MONITOR ASSEMBLY <M5> [GR-AXM341U, SXM540UC] ........................................................................................ 5-6

The following table indicate main different points between models GR-SXM340U, GR-AXM236UC, GR-AXM240UC,

GR-SXM240U, GR-SXM245U, GR-SXM245UC and GR-SXM248UC.

The following table indicate different parts number between models GR-SXM340U,GR-AXM236UC,GR-AXM240UC,

GR-SXM240U,GR-SXM245U,GR-SXM245UC and GR-SXM248UC.

PACKING AND ACCESSORY ASSEMBLY <M1> Note: As for IB (INSTRUCTIONS), refer to sec.5.

REF.

MODEL

GR-SXM340U GR-AXM236UC GR-AXM240UC GR-SXM240U GR-SXM245U GR-SXM245UC GR-SXM248UC

No. ITEM

1 PACKING CASE LY32545-001B LY32545-003A LY32545-002A

6 REGIST.CARD BT-51028-1 — — BT-51028-1 ——

7 WARRANTY INF. BT-51005-5 — — BT-51005-5 ——

9 SHEET(AGREMENT) LYT0934-001A — — — — — —

17 WARRANTY CARD — BT-52004-2 — — BT-52004-2

18 SER.NET CARD — BT-20071B — — BT-20071B

PC CONNECTION CABLE

QAM0384-001 — — — — — —

33 CORE FILTER QQR1266-001 — — — — — —

34 CD ROM ASSY LY32210-020B — — — — — —

36 SHEET(ATT.) LYT0974-001A — — — — — —

FINAL ASSEMBLY <M2>

REF.

MODEL

GR-SXM340U GR-AXM236UC GR-AXM240UC GR-SXM240U GR-SXM245U GR-SXM245UC GR-SXM248UC

No. ITEM

101

CASSETTE COVER(M)ASSY

LY20694-012A LY20694-010A LY20694-012A LY20694-011A

103 UPPER CASE(M) LY10257-054A LY10257-062A LY10257-051A LY10257-069A LY10257-063A LY10257-072A

110 LOWER CASE ASSY LY20684-023A LY20684-005A LY20684-022A

125 TOP OPE UNIT LY20614-012C LY20614-004C LY20614-010C LY20614-020B LY20614-001C

130 REAR UNIT LY20615-007B LY20615-005E

135 FRONT COVER ASSY LY20683-036A LY20683-038A LY20683-034A LY20683-039A LY20683-054A

135F

DC LIGHT/COVER(LIGHT)

LY32040-001A LY30934-017A LY32040-001A

135G STICKER(A) LY32058-002A LY32058-001A LY32058-002A

135H STICKER(C) LY32060-003A LY32060-005A

135J SPACER(A) LY30029-0B4A — LY30029-0B4A

135K CAUTION LABEL YQ44341-6 — YQ44341-6

139 SCREW — *

QYSPSTU1725M

* * * * *

140 FRAME ASSY LY20832-001B LY20832-002B LY20832-001B

140E CONTACT(LIGHT),X2 YQ43810-1-1 — YQ43810-1-1

140F E-SI C WIRE C-F

WJM0259-001A

—

WJM0259-001A

142 SCREW

QYSPSPU1720Z(,X2)

QYSPSPU1720Z(,X1)

* * * * *

Notes : Mark is same as left.

Mark — is not used.

Mark * reference model was also changed.

MODEL

GR-SXM340U GR-AXM236UC GR-AXM240UC GR-SXM240U GR-SXM245U GR-SXM245UC GR-SXM248UC

ITEM

BODY COLOR

METALLIC GRAY MOLD BLACK METALLIC GRAY

SILVER

DC LIGHT Used Not Used Used

DIGITAL TERMINAL Used Not Used

The following table indicate main different points between models GR-SXM740U, GR-AXM341U, GR-SXM540UC

and GR-SXM745U.

MODEL

GR-SXM740U GR-AXM341U GR-SXM540UC GR-SXM745U

ITEM

LCD MONITOR 3.5” 3” 3.5”

BODY COLOR SILVER MOLD BLACK SILVER

DIGITAL TERMINAL Used Not Used Used

REMOTE CONTROL UNIT Not Used RM-V715U

MECHANISM ASSEMBLY <M3>

REF.

MODEL

GR-SXM340U GR-AXM236UC GR-AXM240UC GR-SXM240U GR-SXM245U GR-SXM245UC GR-SXM248UC

No. ITEM

400 MECHA(B)ASSY YMA0034A-E YMA0033A-E YMA0034A-E

406

CASSETTE GUIDE ASSY(RIGHT)

YQ44339A-7 ——YQ44339A-7

406A SW.LEVER(RIGHT) YQ32162-1-3 ——YQ32162-1-3

406B TORSION SPRING YQ44340-1-4 ——YQ44340-1-4

407 SCREW LY42819-001A ——LY42819-001A

466 ROTARY ENCODER QSW0888-002 QSW0888-001 QSW0888-002

MONITOR ASSEMBLY <M5>

REF.

MODEL

GR-SXM340U GR-AXM236UC GR-AXM240UC GR-SXM240U GR-SXM245U GR-SXM245UC GR-SXM248UC

No. ITEM

!500 MONITOR ASSY LY20836-005A LY20836-006A LY20836-016A LY20836-005A LY20836-021A

!501

MONITOR COVER ASSY

LY20834-004A LY20834-005A LY20834-009A LY20834-004A LY20834-007A

501A PLATE(WINDOW) LY32329-002A LY32329-001A LY32329-002A

501B STICKER(B) LY32554-003A LY32554-004A LY32554-003A

505

HINGE COVER(UPPER)

LY31939-004A LY31939-003A LY31939-004A LY31939-001A

MAIN BOARD ASSEMBLY <01>

REF.

MODEL

GR-SXM340U GR-AXM236UC GR-AXM240UC GR-SXM240U GR-SXM245U GR-SXM245UC GR-SXM248UC

No. ITEM

PW1 MAIN BOARD ASSY YB10356UB1-01 YB10356UI1-01 YB10356UA1-01 YB10356U01-01

IC105 IC(DIGITAL) TC7S66FU-X ——————

IC4002 IC Z4C2973-32-X ——————

IC4701 IC —MM1512XN-X ————

IC4702 IC BA7665FS ——BA7665FS

IC8001 IC MAX3221CAE ——————

Q3505 TRANSISTOR DTC144EE ——DTC144EE

Q4001 TRANSISTOR DTC144EE ——DTC144EE

Q6306 MOS FET SSM3K02F —SSM3K02F

D4001 DIODE DAN222 ——DAN222

D8001 ZENER DIODE EMZ6.8N ——————

D8002 ZENER DIODE EMZ6.8N ——————

R182 MG RESISTOR NRSA63J-105X ——————

R4013 MG RESISTOR NRSA63J-102X ——————

R4014 MG RESISTOR NRSA63J-103X ——NRSA63J-103X

R4712 MG RESISTOR NRSA63D-680X ——NRSA63D-680X

R4713 MG RESISTOR NRSA63D-680X ——NRSA63D-680X

R6306 MG RESISTOR NRS12BK-R47W —NRS12BK-R47W NRS12BK-R47W

R6307 MG RESISTOR NRSA63J-104X —NRSA63J-104X NRSA63J-104X

R8001 MG RESISTOR NRSA63J-331X ——————

R8002 MG RESISTOR NRSA63J-0R0X ——————

R8003 MG RESISTOR NRSA63J-0R0X ——————

C144 CAPACITOR —NDC31HJ-101X

C4006 CAPACITOR —NDC31HJ-100X

C4024 CAPACITOR NCF31EZ-104X ——————

C4025 CAPACITOR NCB31CK-104X ——NCB31CK-104X

C4044 CAPACITOR NCB30JK-105X ——————

C4713 E CAPACITOR NEA70JM-226X ——NEA70JM-226X

C4714 E CAPACITOR NEA70GM-107X ——NEA70GM-107X

C4715 CAPACITOR NCB31EK-103X ——NCB31EK-103X

C6307 E CAPACITOR NEA71CM-106X —NEA71CM-106X

C8001 CAPACITOR NCF31EZ-104X ——————

C8002 CAPACITOR NCF31EZ-104X ——————

C8003 CAPACITOR NCF31EZ-104X ——————

C8004 CAPACITOR NCF31EZ-104X ——————

C8005 CAPACITOR NBE20JM-106X ——————

C8006 CAPACITOR NCF31EZ-104X ——————

L501 MG RESISTOR NRSA63J-0R0X ——————

L2001 COIL NQL144K-470X NQL144K-101X NQL144K-470X

L8001 COIL NQL365K-220X ——————

J505 S JACK QND0068-001 ——QND0068-001

CN6 CONNECTOR

QGA1201C2-02X

—QGA1201C2-02X

Notes : Mark is same as left.

Mark —is not used.

PACKING AND ACCESSORY ASSEMBLY <M1> Note: As for IB (INSTRUCTIONS), refer to sec.5.

REF.

MODEL

GR-SXM740U GR-AXM341U GR-SXM540UC GR-SXM745U

No. ITEM

1 PACKING CASE LY32545-006B LY32545-003A LY32545-001B LY32545-006B

6 REGIST CARD BT-51028-1 —BT-51028-1

7 WARRANTY INF. BT-51005-5 —BT-51005-5

9 SHEET(AGREMENT) LYT0934-001A —LYT0934-001A

17 WARRANTY CARD ——BT-52004-2 —

18 SER.NET CARD ——BT-20071B —

REMOTE CONTROL UNIT

—— —LY42129-001A

20 BATTERY,X2 —— —AAA(R03)

PC CONNECTION CABLE

QAM0384-001 —QAM0384-001

33 CORE FILTER QQR1266-001 —QQR1266-001

34 CD ROM ASSY LY32210-020B —LY32210-020B

36 SHEET(ATT.) LYT0974-001A —LYT0974-001A

The following table indicate different parts number between models GR-SXM740U, GR-AXM341U, GR-SXM540UC and GR-SXM745U.

FINAL ASSEMBLY <M2>

REF.

MODEL

GR-SXM740U GR-AXM341U GR-SXM540UC GR-SXM745U

No. ITEM

101

CASSETTE COVER(M)ASSY

LY20815-001A LY20694-010A LY20694-011A LY20815-001B

103 UPPER CASE(M) LY10257-056A LY10257-050A LY10257-052A LY10257-070A

110 LOWER CASE ASSY LY20684-023A LY20684-005A LY20684-023A

125 TOP OPE UNIT LY20614-009C LY20614-010C LY20614-009C

130 REAR UNIT LY20764-010A LY20615-005E LY20615-007B LY20764-010A

135 FRONT COVER ASSY LY20683-035A LY20683-034A LY20683-035A

135G STICKER(A) LY32058-003A LY32058-002A LY32058-003A

135H STICKER(C) LY32060-003A LY32060-005A LY32060-003A

139 SCREW

QYSPSPU1720Z(,X2)

QYSPSPU1720Z(,X1)

* *

142 SCREW —*

QYSPSTU1725M

* *

Notes : Mark is same as left.

Mark —is not used.

Mark * reference model was also changed.

MECHANISM ASSEMBLY <M3>

REF.

MODEL

GR-SXM740U GR-AXM341U GR-SXM540UC GR-SXM745U

No. ITEM

400 MECHA(B)ASSY YMA0034A-E YMA0033A-E YMA0034A-E

406

CASSETTE GUIDE ASSY(RIGHT)

YQ44339A-7 —YQ44339A-7

406A SW.LEVER(RIGHT) YQ32162-1-3 —YQ32162-1-3

406B TORSION SPRING YQ44340-1-4 —YQ44340-1-4

407 SCREW LY42819-001A —LY42819-001A

466 ROTARY ENCODER QSW0888-002 QSW0888-001 QSW0888-002

MONITOR ASSEMBLY <M5>

REF.

MODEL

GR-SXM740U GR-AXM341U GR-SXM540UC GR-SXM745U

No. ITEM

!500 MONITOR ASSY LY20836-007A LY20836-012A LY20836-010A LY20836-007A

!501

MONITOR COVER ASSY

LY20816-001A LY20834-005A LY20834-007A LY20816-001A

501A PLATE(WINDOW) LY32329-002A LY32329-001A LY32329-002A

501B STICKER(B) LY32554-003A LY32554-004A LY32554-003A

501C SPACER(A) —LY30029-0R3A —

501D SPACER(A) —LY30029-0R4A —

502

MONITOR CASE ASSY

LY32544-001A LY32035-001A LY32544-001A

504 SHIELD CASE LY32334-001A LY32332-001A LY32334-001A

505

HINGE COVER(UPPER)

LY31939-001A LY31939-003A LY31939-001A

518 LCD MODULE QLD0212-001 QLD0213-001 QLD0212-001

519 LIGHT SCREEN —LY43391-001A —

520 LAMP —QLL0111-001 —

521 HOLDER,X2 —LY43394-001A —

522 SHEET —LY43395-001A —

523

DIFFUSION SHEET(3)

—LY43363-001A —

528 LCD FRAME LY32335-001A LY32333-001A LY32335-001A

530 BACK LIGHT QLL0113-001 ——QLL0113-001

MAIN BOARD ASSEMBLY <01>

REF.

MODEL

GR-SXM740U GR-AXM341U GR-SXM540UC GR-SXM745U

No. ITEM

PW1 MAIN BOARD ASSY

YB10356-UK1-01

YB10356-UJ1-01 YB10356-UK1-01 YB10356UC1-01

IC105 IC(DIGITAL) TC7S66FU-X —TC7S66FU-X

IC1801

IR DETECT UNIT —— —PIC-26043S

IC4002

IC Z4C2973-32-X —Z4C2973-32-X

IC4701

IC —MM1512XN-X ——

C4702

IC BA7665FS —BA7665FS

IC8001

IC MAX3221CAE —MAX3221CAE

Q3505 TRANSISTOR DTC144EE —DTC144EE

Q4001 TRANSISTOR DTC144EE —DTC144EE

D4001 DIODE DAN222 —DAN222

D8001 ZENER DIODE EMZ6.8N —EMZ6.8N

D8002 ZENER DIODE EMZ6.8N —EMZ6.8N

R182 MG RESISTOR NRSA63J-105X —NRSA63J-105X

R4013 MG RESISTOR NRSA63J-102X —NRSA63J-102X

R4014 MG RESISTOR NRSA63J-103X —NRSA63J-103X

R4712 MG RESISTOR NRSA63D-680X —NRSA63D-680X

R4713 MG RESISTOR NRSA63D-680X —NRSA63D-680X

R8001 MG RESISTOR NRSA63J-331X —NRSA63J-331X

R8002 MG RESISTOR NRSA63J-0R0X —NRSA63J-0R0X

R8003 MG RESISTOR NRSA63J-0R0X —NRSA63J-0R0X

C144 CAPACITOR —NDC31HJ-101X

C4006 CAPACITOR —NDC31HJ-100X ——

C4024 CAPACITOR NCF31EZ-104X —NCF31EZ-104X

C4025 CAPACITOR NCB31CK-104X —NCB31CK-104X

C4044 CAPACITOR NCB30JK-105X —NCB30JK-105X

C4713 E CAPACITOR NEA70JM-226X —NEA70JM-226X

C4714 E CAPACITOR NEA70GM-107X —NEA70GM-107X

C4715 CAPACITOR NCB31EK-103X —NCB31EK-103X

C8001 CAPACITOR NCF31EZ-104X —NCF31EZ-104X

C8002 CAPACITOR NCF31EZ-104X —NCF31EZ-104X

C8003 CAPACITOR NCF31EZ-104X —NCF31EZ-104X

C8004 CAPACITOR NCF31EZ-104X —NCF31EZ-104X

C8005 CAPACITOR NBE20JM-106X —NBE20JM-106X

C8006 CAPACITOR NCF31EZ-104X —NCF31EZ-104X

L501 MG RESISTOR NRSA63J-0R0X —NRSA63J-0R0X

L8001 COIL NQL365K-220X —NQL365K-220X

J505 S JACK QND0068-001 —QND0068-001

MONITOR BOARD ASSEMBLY <07>

REF.

MODEL

GR-SXM740U GR-AXM341U GR-SXM540UC GR-SXM745U

No. ITEM

PW MONITOR BOARD ASSY YB20913F YB20913E YB20913F

Q7607 TRANSISTOR DTC144EE ——DTC144EE

R7622 MG RESISTOR NRSA63J-0R0X ——NRSA63J-0R0X

R7647 MG RESISTOR —NRSA63J-0R0X —

R7648 MG RESISTOR NRSA63J-103X ——NRSA63J-103X

R7649 MG RESISTOR —NRSA63J-333X —

R7650 MG RESISTOR NRSA63J-103X ——NRSA63J-103X

Notes : Mark is same as left.

Mark —is not used.

Printed in Japan

JVC SERVICE & ENGINEERING COMPANY OF AMERICA

DIVISION OF JVC AMERICAS CORP.

Head office

East Coast

Midwest

West Coast

Atlanta

Hawaii

1700 Valley Road Wayne, New Jersey 07470-9976

10 New Maple Avenue Pine Brook, New Jersey 07058-9641

705 Enterprise Street Aurora, Illinois 60504-8149

5665 Corporate Avenue Cypress, California 90630-0024

1500 Lakes Parkway Lawrenceville, Georgia 30043-5857

2969 Mapunapuna Place Honolulu, Hawaii 96819-2040

(973)317-5000

(973)396-1000

(630)851-7855

(714)229-8011

(770)339-2582

(808)833-5828

JVC CANADA INC.

Head office

Montreal

Vancouver

21 Finchdene Square Scarborough, Ontario M1X 1A7

16800 Rte Trans-Canadienne, Kirkland, Quebec H9H 5G7

13040 Worster Court Richmond, B.C. V6V 2B3

(416)293-1311

(514)871-1311

(604)270-1311

S40895-04

INSTRUCTIONS

ENGLISH LYT0899-001A

AUTOMATIC DEMONSTRATION

Automatic Demonstration takes place when “DEMO MODE” is set to “ON”

(factory-preset).

• Available when the Power Switch

is set to “ ” or “ ”.

• Performing any operation during the demonstration stops the demonstration temporarily. If no operation

is performed for more than 1 minute after that, the demonstration will resume.

• “DEMO MODE” remains “ON” even if the camcorder power is turned off.

• To cancel Automatic Demonstration, set the Power Switch

to “ ” and press the MENU Wheel

while the demo is in progress. This takes you directly to the demo mode’s Setting Menu (so you will not

have to go through the main Menu Screen). Rotate the MENU Wheel

to select “OFF” and press it.

NOTES:

• When a tape whose Erase Protection tab is in the position that allows recording is loaded in the

camcorder, demonstration is not available.

• If you do not detach the Lens Cap, you cannot see the actual changes of the Automatic Demonstration

activated on the LCD monitor or viewfinder.

UPrinted in Malaysia

1101MKV

COMPACT VHS CAMCORDER

GR-SXM745

For Customer Use:

Enter below the Model No. and Serial No. which is

located on the bottom of the camcorder. Retain this

information for future reference.

Model No.

Serial No.

Dear Customer,

Thank you for purchasing the JVC Compact VHS camcorder. Before use, please read

“PRECAUTIONS”(pg. 3, 4) to ensure safe use of this product.

PROVIDED ACCESSORIES

NOTE:

In order to maintain optimum performance of the camcorder, provided cables may be equipped with

one or more core filter. If a cable has only one core filter, the end that is closest to the filter should be

connected to the camcorder.

•AC Adapter

•Battery Pack

BN-V11U

• CD-ROM

• Lens Cap

• Remote Control Unit

RM-V715U

• AAA (R03) Battery x 2

(for Remote Control Unit)

•Cassette Adapter

C-P7U

• AA (R6) Battery

(for Cassette Adapter)

• PC Connection Cable•Shoulder Strap

AP-V12U, AP-V11U or AP-V10U

SAFETY PRECAUTIONS

PRECAUTIONS

Cassettes marked and can be used used with this camcorder.

CAUTION

RISK OF ELECTRIC SHOCK

DO NOT OPEN

CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK,

DO NOT REMOVE COVER (OR BACK).

NO USER-SERVICEABLE PARTS INSIDE.

REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.

The lightning flash with arrowhead symbol, within an

equilateral triangle, is intended to alert the user to the

presence of uninsulated "dangerous voltage" within the

product's enclosure that may be of sufficient magnitude

to constitute a risk of electric shock to persons.

The exclamation point within an equilateral triangle is

intended to alert the user to the presence of important

operating and maintenance (servicing) instructions in

the literature accompanying the appliance.

WARNING:

TO REDUCE THE RISK OF FIRE

OR ELECTRIC SHOCK, DO NOT

EXPOSE THIS APPARATUS TO

RAIN OR MOISTURE.

CAUTIONS

•This camcorder is designed to be used with

NTSC-type color television signals. It cannot be

used for playback with a television of a different

standard. However, live recording and LCD

monitor/viewfinder playback are possible

anywhere.

•Use the JVC BN-V11U/V12U/V20U/V400U

battery packs and, to recharge them or to supply

power to the camcorder from an AC outlet, use

the provided multi-voltage AC Adapter.

(An appropriate conversion adapter may be

necessary to accommodate different designs of

AC outlets in different countries.)

NOTES:

•The rating plate (serial number plate) and safety

caution are on the bottom and/or the back of the

main unit.

•The rating information and safety caution of the

AC Adapter are on its upper and lower sides.

ATTENTION:

The product that you have purchased is powered

by a rechargeable battery. The battery is recycla-

ble. At the end of its useful life, under various state

and local laws, it may be illegal to dispose of this

battery into the municipal waste stream. Check

with your local solid waste officials for details in

your area for recycling options or proper disposal.

The EPA certified RBRC®Battery Recycling Seal on the nickel-cadmium (Ni-Cd) battery indicates JVC

is voluntarily participating in an industry program to collect and recycle these batteries at the end of

their useful life, when taken out of service in the United States. The RBRC®program provides a

convenient alternative to placing used Ni-Cd batteries into the trash or the municipal waste stream,

which may be illegal in your area. Please call 1-800-8-BATTERY™for information on Ni-Cd battery

recycling and disposal bans/restrictions in your area. JVC’s involvement in this program is part of our

commitment to preserving our environment and conserving our natural resources.

When the equipment is installed in a cabinet or on a shelf, make sure that it has sufficient space on all

sides to allow for ventilation (10 cm (3-15/16") or more on both sides, on top and at the rear).

Do not block the ventilation holes.

(If the ventilation holes are blocked by a newspaper, or cloth etc. the heat may not be able to get out.)

No naked flame sources, such as lighted candles, should be placed on the apparatus.

When discarding batteries, environmental problems must be considered and the local rules or laws

governing the disposal of these batteries must be followed strictly.

The apparatus shall not be exposed to dripping or splashing.

Do not use this equipment in a bathroom or places with water.

Also do not place any containers filled with water or liquids (such as cosmetics or medicines, flower

vases, potted plants, cups etc.) on top of this unit.

(If water or liquid is allowed to enter this equipment, fire or electric shock may be caused.)

IMPORTANT SAFETY INSTRUCTIONS

(1) Read these instructions.

(2) Keep these instructions.

(3) Heed all warnings.

(4) Follow all instructions.

(5) Do not use this apparatus near water.

(6) Clean only with dry cloth.

(7) Do not block any ventilation openings. Install

in accordance with the

manufacturer’s instructions.

(8) Do not install near any heat sources such as

radiators, heat registers, stoves, or other

apparatus (including amplifiers) that produce

heat.

(9) Only use attachments/accessories specified

by the manufacturer.

(10) Use only with the cart, stand,

tripod, bracket, or table

specified by the manufac-

turer, or sold with the

apparatus. When a cart is

used, use caution when

moving the cart/apparatus combination to

avoid injury from tip-over.

(11) Unplug this apparatus during lightning

storms or when unused for long periods of

time.

(12) Refer all servicing to qualified service

personnel. Servicing is required when the

apparatus has been damaged in any way,

such as power-supply cord or plug is

damaged, liquid has been spilled or objects

have fallen into the apparatus, the

apparatus has been exposed to rain or

moisture, does not operate normally, or has

been dropped.

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de Videocámara de JVC

JVC

JVC GR-DVF20 Manual de usuario

JVC

JVC GZMC500US - Everio Camcorder - 1.33 MP Hoja de instrucciones

JVC

JVC JY-VS200U - Professional Dv 1-ccd Camcorder Manual de usuario

JVC

JVC JY-HD10US Manual de usuario

JVC

JVC LYT1994-001B-M Manual de usuario

JVC

JVC GR-DVL567 Manual de usuario

JVC

JVC Everio GZ-E100 Manual de operación y mantenimiento

JVC

JVC Everio GZ-RX610 Manual de operación y mantenimiento

JVC

JVC Everio GZ-MS130 Manual de usuario

JVC

JVC GR-AX860 Manual de usuario

JVC

JVC GR-FXM39EK Manual de usuario

JVC

JVC KAMERA Z TWARDYM DYSKIEM GZ-MG575E Manual de usuario

JVC

JVC GZ-HD10AA Manual de usuario

JVC

JVC GR-AX640U Manual de usuario

JVC

JVC EVERIO GS-TD1BEK Manual de operación y mantenimiento

JVC

JVC Everio GZ-R318 Manual de usuario

JVC

JVC GZ-EX210 Everio Manual de operación y mantenimiento

JVC

JVC GZ-HD10AG Manual de usuario

JVC

JVC Everio LYT2115-002A-M Instrucciones de uso

JVC

JVC EverioGZ-VX705U Manual de operación y mantenimiento

JVC

JVC TK-S250U - Ccd B/w Video Camera Manual de usuario

JVC

JVC GY-DV5100 Manual de usuario

JVC

JVC GZ-MG21AC Manual de usuario

JVC

JVC GR-DV3000 Manual de usuario

Manuales populares de Videocámara de otras marcas

Toshiba

Toshiba CAMILEO Z100 Manual de usuario

Panasonic

Panasonic NV-VS40B Manual de usuario

Canon

Canon RC 260 Manual de usuario

Sony

Sony Handycam DCR-DVD7E Manual de usuario

Brinno

Brinno TimeLapse TLC200 Manual de usuario

Panasonic

Panasonic AG-HMC152EN Manual de usuario

Insignia

Insignia NS-DCC5HB09 - Camcorder - 720p Manual de usuario

MYDLINK

MYDLINK DCS-6100LH Manual de usuario

Sony

Sony video Hi8 Handycam CCD-TR555 Manual de usuario

SECURECOM

SECURECOM V-5014B Manual de usuario

Panasonic

Panasonic HDC-SD100 Manual de usuario

Sharper Image

Sharper Image U-VIDEO Manual de usuario

Canon

Canon LEGRIA HV40 Manual de usuario

Sony

Sony Handycam DCR-VX2000 Manual de usuario

RCA

RCA CC616 Manual de usuario

Panasonic

Panasonic NVM40 Manual de usuario

ATIK Cameras

ATIK Cameras Horizon Manual de usuario

Sony

Sony Handycam HDR-CX580V Manual de usuario
