JVC 2012 Everio Manual de usuario

2012 Wi-Fi Reference

Index:

p. 2 Wi-Fi Feature Overview

p. 3-4 Direct Monitoring (Phone)

p. 5 Recording Location Data

p.6 Direct Monitoring (PC)

p. 7 Setting Up an Access Point

p. 8 Outside Monitoring (Phone)

p. 9 Outside Monitoring (Browser)

p. 10-11 Outside Monitoring (Internet)

p. 12-13 Setting Up E-Mail

p. 14 Home Detection Monitoring

p. 15 Video E-Mail

p. 16 Setup via Web Browser

p. 17 Additional Notes

EVERIO,

NOW WITH

Wi-Fi

Everio Wi-Fi Overview

Video E-Mail

•Record & send 15 second videos to

registered e-mail addresses

Live

Monitoring

•via PC or Smartphone

Home Detection

Monitoring

•Automatically e-mail digital

stills using motion detection

Smart Phone

Linking

•Record GPS location data from

smart phone

•Access Everio with iOS & Android

Smartphone Apps

•Upload to YouTube™ or Facebook

for easy sharing

Please download

the free Everio sync.

app from the Apple

iTunes Store (iOS) or

from Google Play

(Android)

2012 Everio Wi-Fi Reference-2

EVERIO,

NOW WITH

Wi-Fi

Direct Monitoring

(w/ iPhone)

1. Insert SD Card (Built-In memory on GZ-EX250).

2. Download the JVC Everio sync. app.

3. From LCD screen select “MENU” and the

“DIRECT MONITORING” icon under “Wi-Fi”

4. The Everio LCD Screen displays

SSID: DIRECT-38EVERIO & PASS: 46364133.

This is the Wi-Fi Network name for the Everio

and the password needed to connect to it.

Everio Wi-Fi Operation

5. On the iPhone, go to Settings > Wi-Fi. Under

“Choose a Network”, you should see the Everio

SSID. Select it and enter the PASS code from

the camcorder LCD screen. (Step #4).

• This is necessary only for initial setup.

Afterward, simply choose the Everio

from the list of available Wi-Fi networks.

6. Launch the JVC Everio Synch App. At the

bottom, there are three tabs. The “Monitor Tab”

lets you view/monitor, record video, snap digital

stills and control the zoom.

2012 Everio Wi-Fi Reference-3

7. The Video Index & Digital Still Index tabs make it

possible to view recordings. Select an icon to

transfer a video or digital still to a smartphone.

8. It is also possible to edit the length of a video

clip before transferring to the smartphone.

Everio Wi-Fi Operation Recording to the Camera

while using

Direct Monitoring

(w/ iPhone)

1. Recording to the camcorder can be controlled

during “Direct Monitoring” by pushing the

“CAMERA OPERATION” button.

2. A control screen is displayed that allows

recording in the “Full Auto” mode. Manual

recording is not available in this mode.

Please note:

While the phone is connected

directly via Wi-Fi to the Everio, Wi-Fi functions such

as e-mail & web browsing are not available.

2012 Everio Wi-Fi Reference-4

Recording Videos

with Location Data

(Example w/ iPhone)

1. Insert SD Card (Built-In memory on GZ-EX250).

2. Launch the JVC Everio sync. app and follow the

steps to start Direct Monitoring.

3. Select “SET” (the gear icon)

4. Set “LOC INFO TRANS INT” to “1 SEC”.

5. At the prompt “Everio sync. Would Like to Use

Your Current Location”, select “OK”.

6. Select “CAMERA OPERATION” which allows

videos to be recorded in the “Full Auto” mode.

A GPS antenna icon confirms that the GPS data

is being recorded. Manual recording is not

available in this mode.

Playing Back Videos with Location Data

(Example w/Windows PC)

1. Download and install the Google Earth program.

2. Launch Everio Media Browser.

3. Go to “Settings”, then “Geolocation Settings”

and make sure that the “Geolocation Function”

is enabled.

4. Select the videos to play. Videos with location

data will have a red GPS logo in the bottom left

hand corner. Google Earth launches and

displays the location of the video.

Everio Wi-Fi Operation

2012 Everio Wi-Fi Reference-5

4. The URL to access the Everio from your

computer is displayed (PC & Mac).

5. Type the URL into the web browser to launch the

web browser application. It is now possible to

monitor, record, zoom and transfer files from the

Everio. It is not necessary to download any

additional software to use this browser.

6. The browser offers full control and the widest

range of streaming options, including Full HD.

Full HD requires Windows 7 OS, and is not

available with a Mac.

Please note:

It is possible to stream to only one

device at a time.

Direct Monitoring

(via Computer)

A PC or Mac with Wi-Fi is required.

1. Follow the same steps 1-4 (page 3) as for

connection with a phone.

2. On the computer, go to “Connect to a Network”

and look for the Everio SSID. Connect to it as

you would to any other wireless network using

the PASS code from the camcorder LCD screen

(step #4, page 3).

Please note:

Do not worry if computer indicates

connection is unsuccessful. The computer may

indicate “Connected with Limited Access”, or that

the computer is not connected to the internet.

That’s OK. Proceed to the next step.

3. Once the connection is established, the Everio

will indicate that it is being controlled by remote.

Next, select “CAMERA NETWORK INFO.”

Everio Wi-Fi Operation

2012 Everio Wi-Fi Reference-6

Everio Wi-Fi Operation

Setting Up an Access Point

Before you can use “OUTSIDE MONITORING”, or

any of the camcorder’s e-mail functions, you need to

set up an access point. This is typically your home

Wi-Fi network.

1. From the camcorder LCD screen, select “MENU”,

then “Wi-Fi”, then “NETWORK SETTINGS”

(scroll to second page) and select “ACCESS

POINTS”.

2. Choose to “ADD” an access point.

3. Then, choose to “SEARCH” for an access point.

4. The camcorder will search for available access

points. Select the appropriate choice from the

search results list.

5. Enter the security password and then choose

“SET”. The Everio will connect to the access

point.

Please note:

It is possible to enter up to eight

access points and then select the one you wish to

use from a list.

2012 Everio Wi-Fi Reference-7

Everio Wi-Fi Operation

Outside Monitoring via Access

Point at Home (w/ iPhone)

1. Insert SD Card (Built-In memory on GZ-EX250).

2. Download the JVC Everio sync. app.

3. Select an access point (see page 7).

4. On the camcorder LCD screen select “MENU”

and then “Wi-Fi”.

5. Next, select “OUTSIDE MONITORING”.

6. Select “CAMCORDER NETWORK INFO”.

7. The URL needed to access the Everio from a

phone or tablet is displayed.

8. Launch the Everio sync. app and choose

“NETWORK SETTINGS”.

9. Enter the URL from the camcorder.

10. Enter the User Name and Password. The user

name is always “everio”. The default password

is “0000”.

2012 Everio Wi-Fi Reference-8

Everio Wi-Fi Operation

Outside Monitoring via Access Point

at Home (w/ Browser)

A PC or Mac with Wi-Fi is required.

1. Insert SD Card (Built-In memory on GZ-EX250).

2. Select an access point (see page 7).

3. From the camcorder LCD screen select “MENU”

and then “Wi-Fi”.

4. Select “OUTSIDE MONITORING”.

5. Select “CAMCORDER NETWORK INFO”.

6. The URL (LAN) needed to access the Everio

from a web browser is displayed.

7. From the web browser, enter the URL (LAN) as

displayed.

8. At the prompt for password, note that the user

name is always “everio”. The default password

is “0000”. A personal password can also be

created.

9. It is now possible to monitor, record, zoom and

transfer files from the Everio. It is not necessary

to download any additional software to use this

browser.

10. The browser offers full control and the widest

range of streaming options, including Full HD.

Full HD requires Windows 7 OS, and is not

available with a Mac.

Please note:

It is only possible to stream to one

device at a time.

2012 Everio Wi-Fi Reference-9

Everio Wi-Fi Operation

Outside Monitoring via Access Point

using Internet (w/ Browser)

It is necessary to obtain a “JVC Dynamic DNS”

account to use “OUTSIDE MONITORING” via the

internet. The “JVC Dynamic DNS” account is a free

service which is available from this URL:

https://dd3.jvckenwood.com/user/

1. Insert SD Card (Built-In memory on GZ-EX250).

2. Select an access point (see page 7).

3. The camcorder is registered by entering the

serial number and then creating a user name

and password.

4. A WAN URL is generated which is used to

uniquely identify the Everio and allow it to be

viewed via the internet.

5. On the camcorder LCD screen select “MENU”

and then “Wi-Fi”.

6. Scroll to “OUT MONITORING SET”.

7. Make sure UPnP (Universal Plug and Play) is set

to “ON”.

8. Select “DDNS SETTING”. Make sure it is on and

enter the same user name and password used to

create the JVC Dynamic DNS account on-line.

2012 Everio Wi-Fi Reference-10
