User ManUal
Page 2 © JVA Technologies www.jva-fence.com
1 Quick Start Guide
1.1 THE FULL USER MANUAL
The compete user manuals can be downloaded here:
www.jva-fence.com/z11
www.jva-fence.com/z13
www.jva-fence.com/z14
www.jva-fence.com/z18
1.2 LOW VOLTAGE WIRING
Label Type Descripon
IN1 2 Way Energizer control input 1 (dry contact) internally wired
in parallel with the key switch. Arm energizer when
closed
GATE 2 Way Energizer control input 2 (dry contact). Default func-
on is gate input, normally closed. When the unit is
armed and the gate is opened, it will trigger the gate
alarm.
KEYPAD 3 Way Supplies power and data line for an external keypad.
The +12 source on these terminals is protected with
1A self reseng fuse.
SIREN 2 Way Switched 12V output. 30W max, shared between Si-
ren and Strobe. Low side switched
STROBE 2 Way Switched 12V output. 30W max, shared between Si-
ren and Strobe. Low side switched
Page 3
© JVA Technologies www.jva-fence.com Z Series Quick Start Manual
Label Type Descripon
16Vac 3 Way 16Vac 1.5A power input plus earth. Connecon of
the earth is only required where local safety or wir-
ing codes demand it. This should be connected to the
cabinet or mains earth NOT the fence earth.
Ba Battery
leads
12V dc or baery connecon via F1
(4 Amp slow blow fuse).
Relay 3 3 Way “Form C” relay with dry contacts. Default operaon
Fence Alarm
Relay 4 3 Way “Form C” relay with dry contacts. Default operaon
Zone Armed
Relay 5 3 Way “Form C” relay with dry contacts. Default operaon
General Alarm
1.3 JUMPERS
Jumpers allow you to turn on and o dierent features, or reset the device
to defaults.
JUMPER FUNCTION
J3 Inhibit AC fail error.
J3(Z14R) Tamper disable.
J4 Factory default jumper - on for normal operaon.
O to return programmable opons to factory defaults on
power up.
J8 Disable on board beeper
J5, J6 & J7 Supplies +12V to the Common terminal of Relay 3, 4, 5.
Jumpers located on the top right hand side of the board
Page 4 © JVA Technologies www.jva-fence.com
1.4 QUICK TEST OF CONFIGURED UNIT
It is a good idea to test the energizer before connecng the it to a fence.
This will give you condence that the unit is operang as expected and it
also isolates potenal fence issues.
To do this, connect your energizer with a “test fence” as shown.
Power the energizer and then Arm it. The unit should begin pulsing and
not show any alarms. Disarm the energizer and remove the fence cable as
shown.
Arm the energizer once again, aer 3 pulses (unless you congured it oth-
erwise) the unit should go into alarm as the fence will appear to be cut.
Check that any sirens, strobes or relays acvate as expected.
Page 5
© JVA Technologies www.jva-fence.com Z Series Quick Start Manual
1.5 CONNECTING TO THE FENCE
A convenonal fence installaon including earth loop monitoring.
Page 6 © JVA Technologies.
Z-Series Quick Start Manual
1.6 CHANGING THE PROGRAMMING OPTIONS
Default Installer PIN 012345
Default User PIN 1234
First you have to enter Programming mode.
Command Key1 Key2 Key3 Key4 Key5 Key6 Key7 Key8 Key9
Enter Programming Mode Installer Pin * 0 #
When you have entered Programming mode you can begin to enter the following opons to congure your Security
Energizer. Default Values are highlighted in grey.
Command Key1 Key2 Keys 3 and 4 Key5
Change The Installer PIN
6 Digits
0 0 Enter the new 6 digit Installer PIN #
High Power Mode Power
Level
0 1 0 0 0 1 0 2 0 3 0 4 0 5 0 6 0 7 0 8 0 9 #
Output Voltage (kV) Conventional
5.0 5.5 6.0 6.5 7. 0 7. 5 8.0 8.5 9.0 9.5
Output Voltage (kV) Bi-Polar
2.5 2.8 3.0 3.3 3.5 3.8 4.0 4.3 4.5 4.5
Z-Series Quick Start Manual Page 7
Command Key1 Key2 Keys 3 and 4 Key5
Low Power Mode Power
Level
0 2 00 01 02 03 04 05 06 07 08 09 #
Percentage of High Power Mode Power Level
0.5% 1.0% 1.5% 2.0% 2.5% 3.0% 3.5% 4.0% 4.5% 5.0%
Return Fence Alarm
Voltage For High Power
Mode
0 3 00 01 02 03 04 05 06 07 08 09 #
Fence Alarm Voltage (kV) Conventional
1.5 2.0 2.5 3.0 3.5 4.0 4.5 5.0 5.5 6.0
Fence Alarm Voltage (kV) Bi-Polar
1.5 1.8 2.1 2.4 2.7 3.0 3.3 3.6 3.9 4.2
Return Fence Alarm Volt-
age For Low Power Mode
0 5 00 01 02 03 04 #
300 Volts 500 Volts 700 Volts 900 Volts 110 0 Vo lt s
Bad/Missed Pulse Count
Before Alarm Triggers
0 6 00 01 02 03 04 05 06 07 08 09 #
0123456789
Battery Alarm
Voltage(volts). Alarm
Value Shown, Reduced
Power is 1V less
0 7 00 01 02 03 04 05 06 07 08 09 #
9.0 9.5 10.0 10.5 11.0 11. 5 12.0 12.5 13.0 13.5
Siren On Time
(S=Seconds, M=Minutes)
0 8 00 01 02 03 04 05 06 07 08 09 #
10S 30S 1M 2M 3M 4M 5M 20M 45M 130M
Siren O Time
(S=Seconds, M=Minutes)
0 9 00 01 02 03 04 05 06 07 08 09 #
10S 1M 2M 5M 10M 20M 30M 40M 50M 60M
Page 8 © JVA Technologies.
Z-Series Quick Start Manual
Command Key1 Key2 Keys 3 and 4 Key5
Siren Cycles 1 0 00 01 02 03 04 05 06 07 08 09 #
0123456789
Input Type 1 1 00 01 #
Normally Open (NO) Normally Closed (NC)
Input 2 Function 1 2 00 01 #
Gate Low Power
Gate Entry/Exit Delay
(S=Seconds, M=Minutes)
1 3 00 01 02 03 04 05 06 07 08 09 #
0S 30S 1M 2M 3M 4M 5M 6M 7M 8M
Chime Mode 1 4 01 02 03 04 05 #
None Door Chime Siren Fence Alarm Gate Beeps
Plus Siren
Combined Options 1
(add up the options you
want. e.g. for Max Power
and Limit output:
2 + 4 = 6 Therefore enter
06 for keys 3 and 4
1 6 +2 +4 +8 +16 +32 #
Maximum
Power at all
times
Limits out-
put to 2.5J
per Zone
Enables IR
Tamper.
Stop slaves
on comms
fail
Stop Ener-
giser send-
ing alarm
memory
Anti Bridging threshold 1 7 Enter in the percentage dierence required to trigger the Anti-Bridging
alarm. e.g. if you require a 10% change in return voltage to trigger the
alarm, enter 10 for keys 3 and 4
#
Z-Series Quick Start Manual Page 9
Command Key1 Key2 Keys 3 and 4 Key5
Combined Options 2
(like Combined Options 1)
1 8 +1 +2 +4 +8 #
Siren Codes
(Chirps 1 for
armed, twice for
disarmed)
Gate Delay Type 4800 baud 9600 baud
Auto Re-arm Time
(S=Seconds, M = Minutes,
D=Disabled
2 0 00 01 02 03 04 05 06 07 08 09 #
0S 30S 1M 2M 3M 4M 5M 6M 7M D
Relay 1 2 1 Options Explained under “1.1.1 Relay Functions” Default is 08 #
Relay 2 2 2 Options Explained under “1.1.1 Relay Functions” Default is 09 #
Relay 3 (if Fitted) 2 3 Options Explained under “1.1.1 Relay Functions” Default is 00 #
Relay 4 (if Fitted) 2 4 Options Explained under “1.1.1 Relay Functions” Default is 02 #
Relay 5 (if Fitted) 2 5 Options Explained under “1.1.1 Relay Functions” Default is 07 #
Group Mode 2 6 00 01 02 etc 15 #
No Group Master Slave 1 Slave 14
Exit Programming Mode * #
Page 10 © JVA Technologies.
Z-Series Quick Start Manual
1.6.1 Relay Funcons
The table below is for use for the relay programming opons menoned in the table on the previous page.
Keys 3
and 4
Funcon Descripon
00 Fence Triggers when Zone 1 is Armed and Return Voltage is below the Threshold Voltage
01 Fence or O Triggers when Zone 1 is Disarmed or Return Voltage is below the Threshold Voltage
02 Armed Zone 1 is Armed
06 Fence Bi-Polar Triggers when energizer is Armed and the fence Return Voltage on either Bi-Polar re-
turn line has fallen below the Threshold Voltage
07 General Triggers on AC Fail, Tamper, Low Baery/Bad Baery, Gate Alarm or Internal error.
Latched (internal errors only)
08 Siren Triggers on Fence Alarm, Gate or Tamper. Will me out aer the Siren Time Out me.
Latched
09 Strobe Triggers on Fence alarm, Gate or Tamper. Only turns o on Energizer Disarm. Latched
10 AC Fail Triggers on AC Fail
11 Low/Bad Battery Triggers on Low or Bad Battery
12 Tamper Triggers when the case has been opened and J3 has been tted (Z14R only)
14 Gate Triggers on Gate Alarm
15 Siren Caused by
Gate
Behaves like siren, only for Gate Alarms
16 Armed - Low
Power Mode
Triggers when Armed in Low Power mode
