JUKI MO-735 Guía de configuración

MO-735 Overlock

Dealer Training

MO-735 Overlock

2‐ThreadChainStitch

LetsthreadtheMO‐735forthe2‐Thread

ChainStitch.

OpentheClothplateCoverontheleftside

ofthemachine.

TheChainStitchLooperislocated

behindthisdoor.

MO-735 Overlock

2‐ThreadChainStitch

Whilethislooperappearstohave

alotoflittleparts,Icanassureyou

thatitisveryeasytothread.

Thelooperdisengagesforeasy

threading.

Theillustrationbelowshows

thethreadingtobe1‐2‐3andthat

isprettyaccurate.

Let’sclosetheClothplateCover

fornowandstartsettingupthe

machinetocreateachainstitch.

MO-735 Overlock

2‐ThreadChainStitch

IntheaccessoriesfortheMO‐735therearetwoitemswewillneedtosetthemachine

upforthechainstitch.

TheMultipurposeCoverhempresserfoot.

TheCover/ChainStitchExtensionPlate.

Thespoolholderforthechainstitchthread.

MO-735 Overlock

2‐ThreadChainStitch

Let’sremovetheoriginalpresserfoot.

Turnhandwheeltowardsyouuntilneedlesarein

theupposition.Raisethepresserfoot.

Pressthecatchreleaselevertoreleasethepresserfoot.

Removethepresserfoottotheleft.

Lookatthestandardfoot.

Thereisaleveronthebackofthefootthatcanbeadjustedfor

specificmaterials.Whenworkingwithswimwearorsimilar

fabric,flipthelevertothebackandchangethepresserfoot

pressertoL.

MO-735 Overlock

2‐ThreadChainStitch

Thestandardpresserfootisequippedwithabuilt‐intapeguide.

Thisisagreattoolforsewingtapeintotheshoulderorside

seamsofgarmentscreatedfromknitfabrics.Thisishow

theprofessionalskeepthoseseamsfromstretchingoutofshape.

TheSetScrew(A)canbeloosenedandadjustedtosuitthe

widthofthetape.Thetapefitsintotheslotandflows

alongtheguideonthefoot(B).

Lookattheneedleopeningsonthisfoot.

Thereisspacefortheright2needlesandtheleft3needles

tomovethroughthefoot.

Thisfootisalsousedforapplicationssuchasthe5‐thread

safetystitch.

MO-735 Overlock

2‐ThreadChainStitch

Thereisspacefortheright2needlesandtheleft3needles

tomovethroughthefoot.

Thisfootisalsousedforapplicationssuchasthe5‐thread

safetystitchwhereneedlesareplacedinboththeleftfront

andbackrightneedleholders.

MO-735 Overlock

2‐ThreadChainStitch

Let’splacetheCoverStitchPresserfootonthemachine.

Placethefootundertheshaft.

Thegrooveintheshaftshouldlineupexactlywith

thepresserfootpin.

Lowerthepresserfootandthefootshould

engageautomatically.

LookattheCoverStitchFoot.

Theleftandrightsidesofthefootcanadjusttotheheight

ofthefabricindependently.

Lookattheneedleopeningonthefoot.

MO-735 Overlock

2‐ThreadChainStitch

Thereisonlyspaceforthethreeneedlesusedinthe

Leftneedleholder.

ThisfootcanonlybeusedfortheChainStitchand

2or3threadCoverhemstitches.

MO-735 Overlock

2‐ThreadChainStitch

FortheChainStitchandCoverhemstitches,weneedto

removetheKnifeGuardandplacetheChainStitch

ExtensionTableontheloopercover.

Opentheloopercover.

RemovetheKnifeGuardbypullingitgentlytotheleft.
