JOMISE T863 Manual de usuario
T863
User Manual
Notice: To avoid product loss caused by improper operation, please read the safety
information of all operating instructions in this manual before using this product.
123
45678
9 10 11 12 13
14 15 16 17
18 19 20 21
Version: V1.0
CONTENT
123
45678
9 10 11 12 13
14 15 16 17
18 19 20 21
PRECAUTIONS 1
SPECIFICATION 2
PACKAGE CONTENTS 3
INSTALLATION 4-11
PRODUCT OVERVIEW 12-13
SETTINGS 14-20
TROUBLE SHOOTING 21
CUSTOMER SUPPORT
PRECAUTIONS
● Please read this manual carefully before operation and
keep it for future reference. It will be helpful should you
encounter any operational problem.
● Improper installation will void the manufacturer's warranty.
The installation instructions do not apply to all types of
vehicles and are written as guidelines to assist in installing the
system.
● Consult an experienced technician if you are not comfort-
able installing the product.
● Please make sure to read and understand call local laws
and regulations regarding cameras and their use in a vehicle.
Laws vary by state.
● Do not obscure the view of the road ahead or impede the
deployment of any airbags in the event of an accident.
● When not in use, please disconnect the car adaptor from
both the12/24V DC outlet in your vehicle and the device itself.
● Only clean the device with a soft dry cloth, for tough dirt,
apply some neutral detergent diluted in 5 to 6 parts water to a
soft cloth.
● Note that alcohol, thinner, benzene, etc could cause
damage to the paint or coatings.
● Avoid making contact with the Lens as damage may be
caused.
● The video recordings made by this Digital Video Recorder
are intended for personal use only.
● Whilst driving, do not adjust the controls of your device as
this is a distraction to driving.
11 2 3
45678
9 10 11 12 13
14 15 16 17
18 19 20 21
SPECIFICATION
123
45678
9 10 11 12 13
14 15 16 17
18 19 20 21
Item Name 12″ Stream Media Mirror Dash Camera
Model JOMISE T863
Screen Size 12″ IPS Touch Screen
Display Resolution 1480 x 320P
Recording Resolution
Front Camera: 1920 x 1080P
In-car Camera: 1920 x 1080P
Lens
Rear Camera: 1920 x 1080P
Front Camera: F1.8 170°
Recording Format MOV
Photo Format JPG
Memory Card Micro SD card 32G~128G U1
Storage Temperature -40℉~176℉
Operating Temperature -4℉~158℉
Product Weight
Item Dimension
3.76 lb
11.4 x 2.8 x 1.2 (in)
Input DC 12V - 24V
DC 5V - 2.5A
In-car Camera: F2.0 140°
Rear Camera: F1.8 150°
Output
PACKAGE CONTENTS
JOMISE T863 Mirror Dash Cam
Rear Camera
Cable (32ft) x 1
T863
GPS Receiver x 1 Fixed Straps x 4 Cleaning Cloth x 1
1 2 3
45678
9 10 11 12 13
14 15 16 17
18 19 20 21
Front Camera x 1 Rear Camera x 1 In-car Camera x 1
Car Charger x 1
3 in 1
Type-C Connector x 1
Front Camera Cable x 1
Mount Bracket x 1
( Outside of vehicle ) Mount Bracket x 1
( Inside of vehicle )
User Manual x 1
INSTALLATION
WARNING
● Please MAKE SURE to connect all cameras and wires BEFORE power
ON the Mirror Screen, otherwise, the camera cannot work properly.
● Please follow the instructions below for the first-time installation of the
Stream Media Mirror Dash Camera. lt is designed to be fitted to the
existing rear-view mirror using the straps.
Insert Micro SD Card
Insert the Micro SD Card into the stream media mirror dash camera,
taking care that the gold contacts are facing towards the backside of the
stream media mirror dash camera. Push the memory card until it clicks
into the slot.
123
45678
9 10 11 12 13
14 15 16 17
18 19 20 21
INSTALLATION
Insert Micro SD Card
● Use the edge of a small coin ( or similar object ) to push the memory
card into slot if required. Take care that the card has clicked into slot, a
second push inwards will release the memory card.
● Do not remove or insert the memory card when the Mirror Dash Cam
is turned on. This may damage the memory card.
● Take care when removing the SD card from the Mirror Dash Cam
when it is installed in the vehicle. Due to the card slot mechanism, the
card will spring from the slot when released.
● Periodically reformat the memory card. Every 2-3 weeks we
recommend that you reformat the memory card. This will wipe any files
from the card and set it up afresh for continued use with your Mirror
Dash Cam.
● Of course, you should only do this after you've downloaded any files
from the SD card that you may want to keep, as formatting the card will
remove all content.
● Format your memory card using the Mirror Dash Cam. This will make
sure that the card is structured specifically for your camera.
● Press to enter into the setting and choose the Format Card option
to follow the on-screen instructions accordingly.
Notice:
123
45 6 7 8
9 10 11 12 13
14 15 16 17
18 19 20 21
INSTALLATION
Mount the Mirror Dash Cam
Step 1: Attach the upper end of the straps to the retaining hooks on the
top of the rear-view mirror.
Step 2: Extend the straps around the back of the rear-view mirror and
attach them to the bottom retaining hooks.
Notice:
● The straps have been designed so they can be cut down to give
further size options, as required.
● The straps should be a tight fit when fitted, thus ensuring the Stream
Media Mirror Dash Camera is securely fitted to the existing rear-view
mirror.
123
4 5 6 7 8
9 10 11 12 13
14 15 16 17
18 19 20 21
▼ Uncover the 3M tape protective film and lens protective film of the
front camera and the in-car camera.
▼ Attach the front camera and the in-car camera to a suitable position
on the front windshield.
INSTALLATION
Front/In-car Camera Installation
123
4567 8
9 10 11 12 13
14 15 16 17
18 19 20 21
INSTALLATION
Rear Camera Installation
Use the provided double-sided tape or screws to fix rear camera. The
angle can be adjusted, so be sure to find a perfect viewing angle for
your camera before fix it.
▼ Install inside the car
Please choose type 1 bracket to mount the rear camera if you'd like to
install it inside your vehicle.
Please choose type 2 bracket to mount the rear camera if you'd like to
install it outside your vehicle
▼ Install outside the vehicle
123
45678
9 10 11 12 13
14 15 16 17
18 19 20 21
