JLBIOS661

Built-in oven

Instruction manual

Safety information

It is most important that this instruction book should be retained with

the appliance for future reference. Should the appliance be sold or

transferred to another owner, or should you move house and leave the

appliance, always ensure that the book is supplied with the appliance in

order that the new owner can get to know the functioning of the appliance

and the relevant warnings.

These warnings have been provided in the interest of safety. You MUST

read them carefully before installing or using the appliance. If you are

unsure of the meanings of these warnings contact the John Lewis branch

from which you purchased the appliance.

Installation

• This oven must be installed by qualified and

competent personnel to the relevant

National Standards.

• Refer to Installation information chapter

before installation.

• This oven is heavy. Take care when moving

it.

• Remove all packaging, both inside and

outside the oven, before using the oven.

• Do not attempt to modify the oven in any

way.

People Safety

• This oven is designed to be operated by

adults. Do not allow children to play near

or with the oven.

• The oven gets hot when it is in use. Children

should be kept away until it has cooled.

• This appliance is not intended for use by

children or other persons whose physical,

sensory or mental capabilities or lack of

experience and knowledge prevents them

from using the appliance safely without

supervision or instruction by a responsible

person to ensure that they can use the

appliance safely.

Use

• This oven is intended for domestic cooking

only. It is not designed for commercial or

industrial purposes.

• Appliances become very hot with use, and

retain their heat for long periods after use.

Care should be taken to avoid touching

heating elements inside the oven.

• Always stand back from the oven when

opening the oven door during cooking or

at the end of it to allow any build up of

steam or heat to release.

• Never line any part of the oven with

aluminium foil.

• Do not allow heatproof cooking material,

e.g. roasting bags, to come into contact

with oven elements.

• Never place plastic or any other material

which may melt in or on the oven.

• Do not place sealed cans or aerosols inside

the oven. They may explode if they are

heated.

• Do not hang towels, dishcloths or clothes

from the oven or its handle.

• Do not use this oven if it is in contact with

water and never operate it with wet hands.

• Take great care when heating fats and oils

as they will ignite if they become too hot.

• Always use oven gloves to remove and

replace food in the oven.

• Ensure that all control knobs are in the OFF

position when not in use.

• Do not leave cookware containing

foodstuffs, e.g. fat or oil in or on the oven

in case it is inadvertently switched ON.

• When using other electrical appliances,

ensure the cable does not come into

contact with the hot surfaces of the oven.

Maintenance and

Cleaning

• Only clean this oven in accordance with the

instructions.

• The oven should be kept clean at all times.

A build-up of fats or other foodstuffs could

result in a fire, especially in the grill pan.

• Never use steam or high pressure steam

cleaners to clean the appliance.

• Always allow the oven to cool down and

switch off the electrical supply before

carrying out any cleaning or maintenance

work.

• Do not use abrasive cleaners or sharp metal

scrapers. These can scratch the glass in the

oven door, which may result in the

shattering of the glass.

Service

• This oven should only be repaired or

serviced by an authorised Service Engineer

and only genuine approved spare parts

should be used.

Contents

For the user

Safety information

Description of the appliance

General overview 5

Oven accessories 6

The Control Panel 6

Controls 6

Before using for the first time

Using the oven

The timer 8

Setting the clock 8

Cooking Duration function 9

End of cooking 10

Cooking duration and End of cooking time

combined 10

Minute minder 10

Use, Tips and Tables

The Safety Thermostat 12

The Cooling Fan 12

The Fan Oven 13

Cooking chart - Fan Oven 14

Grilling 18

Defrosting 18

Care and cleaning

Cleaning the oven door 20

Oven Shelves and Shelf Supports 21

Something not working

Disposal

Packaging material 24

Old appliance 24

For the installer

Electrical Connections

Building In

Technical data

Guide to use the

instruction manual

The following symbols will be found in the text

to guide you throughout the instructions:

Safety instructions

Hints and tips

Environmental information

Description of the appliance

General overview

1Control panel

2Grill

3Oven light

4Rating plate

5Fan

Oven accessories

Shelf

1Removable handle

2Grill Pan Grid

3Grill / Roasting pan

The Control Panel

1 2 3 4 5

1Thermostat Control Light

2Thermostat Control Knob

3Electronic Programmer

4Oven Function Control Knob

5Mains on Light

Controls

Push-Pull control knobs

The appliance is provided with push-pull

control knobs. These knobs can be

completely sunken inside the control panel

when the oven is not working.

Oven Function Control

Knob

Oven

Light

The oven light will be on

without any cooking

function.

Defrost

Setting

This setting is intended to

assist in thawing of frozen

food.

Fan

cooking

This allows you to roast or

roast and bake

simoultaneously using any

shelf, without flavour

transference.

Grill The heat comes from the

top element only.

Thermostat Control

Knob

Turn the thermostat control knob clockwise

to select temperatures between 50°C and

MAX (250°C).

Thermostat Control

Light

The thermostat control light will come on

when the thermostat control knob is turned.

The light will remain on until the correct

temperature is reached. It will then cycle on

and off to show the temperature is being

maintained.

Mains on Light

The mains on light will come on when the

oven function control knob is set.

Before using for the first time

Warning! Remove all packaging,

both inside and outside the oven

including the advertising labels and any

protective film, before using the oven.

Before first use, the oven should be heated

without food.

The oven will work only if the time of

day has been set.

1. Set the time of day with the electronic

programmer (refer to "The timer").

2. Switch the oven function control knob to

fan cooking .

3. Set the thermostat control knob to MAX.

4. Open a window for ventilation.

5. Allow the oven to run empty for

approximately 45 minutes.

This procedure should be repeated with the

grill function for approximately 5-10

minutes.

During this time, an unpleasant odour

may be emitted. This is absolutely

normal, and is caused by residues of

manufacturing.

Once this operation is carried out, let the

oven cool down, then clean the oven cavity

with a soft cloth soaked in warm water to

which a little mild washing-up liquid has been

added.

Before cooking for the first time,

carefully wash the shelves and the

baking tray.

Warning! To open the oven door,

always hold the handle in the centre.

Using the oven

The timer

1 3

1Push button for selecting a function

2Decreasing control button " -"

3Increasing control button " +"

4Display

5“Cooking Duration” pilot lamp

6“End of cooking” pilot lamp

7“Minute minder” pilot lamp

8“Time of day” pilot lamp

The oven will only work if the time of

day has been set. However, the oven

can also be operated without any

programme.

In the event of a power failure, all the

settings (time of day, programme

setting or programme in operation)

will be cancelled. When the power is

restored, the numbers in the display

will flash, and the clock/timer has to

be reset.

Setting the clock

When the power is switched on or if a power

failure occurs, the “Clock” pilot lamp will

flash in the display.

To set the clock:

1. Press the button “ ” or “ ”.

2. Then wait 5 seconds: the “Clock” pilot

lamp will go out and the display will show

the set time. The appliance is now ready

for use.

To reset the correct clock time:

1. Press the button repeatedly to select

the “Clock” function. The relevant pilot

lamp will start flashing. Then proceed as

described above.

The clock time can only be reset if no

automatic function (cooking time or

end of cooking time ) has been set.

Cooking Duration

function

This function allows the oven to automatically

switch off at the end of a programmed cooking

duration time. Place food in the oven, select a

cooking function and adjust the cooking

temperature. Press button repeatedly to

select the “Cooking Duration” function. The

relevant pilot lamp will start flashing. Then,

proceed as follows:

To set the duration time

1. Press button " +" or " -".

2. After the setting is carried out, wait for 5

seconds: the "Cooking Duration" pilot

lamp will come on and the display will

revert to the time of day.

3. When cooking time is over, the oven will

be switched off automatically and an

acoustic alarm will be heard, while the

pilot lamp will start flashing. Turn the oven

function and the thermostat control knob

to zero.

To switch off the acoustic alarm, press any

button.

Turning the acoustic alarm off will reset the

oven to manual, and if the oven function and

the thermostat knobs are not set to zero the

oven will start to heat again.

To cancel the duration time

1. Press button repeatedly to select the

“Cooking Duration” function. The

relevant pilot lamp will flash and the

display will show the remaining cooking

time.

2. Press button " -" until the display shows

“0:00”. After 5 seconds the pilot lamp will

go out and the display will revert to the

time of day.

End of cooking

With this function, you can set the oven to

switch off automatically when a programmed

end of cooking time is over. Place food in the

oven, select a cooking function and adjust the

cooking temperature. Press button

repeatedly to select the “End of cooking”

function. The relevant pilot lamp will start

flashing.

To set the End of cooking time

1. Press button " +" or " -".

2. After the setting is carried out, wait for 5

seconds: the “End of cooking” pilot lamp

will come on and the display will revert

to the time of day.

3. When cooking time is over, the oven will

be switched off automatically and an

acoustic alarm will be heard, and the pilot

lamp will start flashing. Turn the oven

function and the thermostat control knob

to zero.

To switch off the acoustic alarm, press any

button.

Turning the acoustic alarm off will reset the

oven to manual, and if the oven function and

the thermostat knobs are not set to zero the

oven will start to heat again.

To cancel the End of cooking time

1. Press button repeatedly to select the

“End of cooking” function. The relevant

pilot lamp will flash and the display will

show the programmed End of cooking

time.

2. Press button " -"until the display shows

the current time of day. The programmer

will beep and the pilot lamp will go out.

Cooking duration and

End of cooking time

combined

The functions “Cooking duration” and “End of

cooking time” can be used simultaneously to

set the oven to switch on and off automatically

at a later time.

1. With the “Cooking duration” function

(carry out the cooking duration setting

as described in the relevant chapter) set

the duration time. Then, press button

and the display will show the programmed

setting.

2. With the “End of cooking time” function

(carry out the End of cooking setting as

described in the relevant chapter) set the

end of cooking time.

The relevant pilot lamps will come on and

the display will show the time of day. The

oven will switch on and off according to

the set programmes.

Minute minder

The minute minder alarm will sound at the end

of a timed period, but the oven will remain on,

if it is in use.

Tabla de contenidos

Otros manuales de Horno de John Lewis

John Lewis

John Lewis JLBIOS611 Manual de usuario

John Lewis

John Lewis JLBIOS609 Manual de operación

John Lewis

John Lewis JLBIDU731X Manual de usuario

John Lewis

John Lewis JLBIOS617 Manual de usuario

John Lewis

John Lewis JLBIOS634 Manual de usuario

John Lewis

John Lewis JLBIOS608 Manual de operación

John Lewis

John Lewis JLBIDOS906 Manual de usuario

John Lewis

John Lewis JLBIOS602 Manual de usuario

John Lewis

John Lewis JLBIDO931X Manual de usuario

John Lewis

John Lewis JLBIOS634 Manual de usuario

John Lewis

John Lewis JLBIOS662 Manual de usuario

John Lewis

John Lewis JLBIOS610 Manual de usuario

John Lewis

John Lewis JLBIDOS904 Manual de usuario

John Lewis

John Lewis JLBIOS622 Manual de usuario

John Lewis

John Lewis JLBIDOS906 Manual de usuario

John Lewis

John Lewis JLBIDO913 Manual de usuario

John Lewis

John Lewis JLBIOS641 Manual de usuario

John Lewis

John Lewis JLBIOS663 Manual de usuario

John Lewis

John Lewis JLBIDO911 Manual de usuario

John Lewis

John Lewis JLBIDU712 Manual de usuario

John Lewis

John Lewis JLBIOS618 Manual de usuario

John Lewis

John Lewis JLBIOS601 Manual de usuario

John Lewis

John Lewis JLBIOS603 Manual de usuario

John Lewis

John Lewis JLBIDO906 Manual de usuario

Manuales populares de Horno de otras marcas

Bosch

Bosch HVA531NS0 Manual de usuario

Electrolux

Electrolux EOF6P46X Manual de usuario

NEFF

NEFF B44S32 5GB Series Manual de usuario

Combi

Combi BLODGETT BC142GDS Manual de usuario

AEG

AEG COMPETENCE 311704300 Manual de usuario

Falcon

Falcon DOMINATOR PLUS G3106 Series Guía del usuario

Rational

Rational SCC WE 61G Manual de usuario

Smeg

Smeg DOSPA38X Manual de instalación y operación

Electrolux

Electrolux air-o-convect 20 GN 2/1 Manual de usuario

Miele

Miele HR 1954-2 Manual de usuario

KHIND

KHIND OT50 Manual de usuario

Henny Penny

Henny Penny Smoker Box Manual de usuario

Lang

Lang ECOD-AP Manual de usuario

AEG

AEG BEK455310M Manual de usuario

Frigidaire

Frigidaire FNGE90JGR Manual de usuario

Hotpoint

Hotpoint FE9 S831 JSH IX Manual de usuario

GE Advantium SCB2000 Manual de usuario

AEG

AEG DE401301DM Manual de usuario
