D30
Gas/DSI/Phase 7 Non-Coin with S.A.F.E.
Installation Manual
WARNING: For your safety the information in
this manual must be followed to minimize the
risk of fire or explosion or to prevent property
damage, personal injury or death.
—Do not store or use gasoline or other flammable
vapors and liquids in the vicinity of this or any
other appliance.
—WHAT TO DO IF YOU SMELL GAS:
•Do not try to light any appliance.
•Do not touch any electrical switch; do not
use any phone in your building.
•Clear the room, building or area of all
occupants.
•Immediately call your gas supplier from a
neighbor’s phone. Follow the gas supplier’s
instructions.
•If you cannot reach your gas supplier, call
the fire department.
—Installation and service must be performed by a
qualified installer, service agency or the gas
supplier.
AVERTISSEMENT: Assurez-vous de bien
suivre les instructions données dans cette notice
pour réduire au minimum le risque d’incendie
ou d’explosion ou pour éviter tout dommage
matériel, toute blessure ou la mort.
—Ne pas entreposer ni utiliser d’essence ni
d’autres vapeurs ou liquides inflammables à
proximité de cet appareil ou de tout autre
appareil.
—QUEFAIRESIVOUSSENTEZUNEODEUR
DE GAZ:
•Ne pas tenter d’allumer d’appareils.
•Ne touchez à aucun interrupteur. Ne pas
vous servir des téléphones se trouvant dans
le bâtiment.
•Évacuez la pièce, le bâtiment ou la zone.
•Appelez immédiatement votre fournisseur
de gaz depuis un voisin. Suivez les
instructions du fournisseur.
•Si vous ne pouvez rejoindre le fournisseur
de gaz, appelez le service des incendies.
—L’installation et l’entretien doivent être assurés par
un installateur ou un service d’entretien qualifié
ou par le fournisseur de gaz.
031402JEV/mcronan Part No. 113369
“IMPORTANT NOTE TO PURCHASER”
Information must beobtained from your local gas supplier on the instructions
to be followed if the user smells gas. These instructions must be posted in a
prominent location near the dryer.
FOR YOUR SAFETY
Do not store or use gasoline or
other flammable vapors and
liquids in the vicinity of this or
any other appliance.
POUR VOTRE SÉCURITÉ
Ne pas entreposer ni utiliser d’essence
ni d’autres vapeurs ou liquides
inflammables à proximité de cet
appareil ou de tout autre appareil.
We have tried to make this manual as complete as possible and hope you will find it useful. Manufacturerreserves the right
to make changes from time to time, without notice or obligation, in prices, specifications, colors, and material, and to change
or discontinue models. The illustrations includedin this manual may not depict your particular dryer exactly.
Important
For your convenience, log the following information:
DATE OF PURCHASE________________________________ MODELNO. __________________________________________
DISTRIBUTOR’S NAME ____________________________________________________________________________________
Serial Number(s) ________________________________________________________________________________________
________________________________________________________________________________________
________________________________________________________________________________________
Replacement parts can be obtained from your distributor orJLA. When ordering replacement parts from JLA, youcan FAX
your order to JLA at 01422 824390 or telephone your order directly to the JLA Parts Department at01422 822282. Please
specify the dryer model number and serial number in addition to the description and part number, so that your order is
processed accurately and promptly.
D30 Phase 7 Non-Coin
Retain This Manual In A Safe Place For Future Reference
This product embodies advanced concepts in engineering, design, and safety. If this product is properly maintained, it will
provide many years of safe, efficient, and trouble free operation.
ONLY qualified technicians should service this equipment.
OBSERVEALLSAFETYPRECAUTIONS displayed on the equipment or specified in the installation manual included with
the dryer.
The following “FOR YOUR SAFETY” caution must be posted near the dryer in a prominent location.
IMPORTANT
YOUMUSTDISCONNECTANDLOCKOUTTHEELECTRICSUPPLYANDTHEGAS
SUPPLY OR THE STEAM SUPPLY BEFORE ANY COVERS OR GUARDS ARE
REMOVED FROM THE MACHINE TO ALLOW ACCESS FOR CLEANING,
ADJUSTING, INSTALLATION, OR TESTING OF ANY EQUIPMENT PER OSHA
(Occupational Safety and Health Administration)STANDARDS.
WARNING
CHILDREN SHOULD NOTBEALLOWED TO PLAY ON OR NEAR THE DRYER(S).
CHILDREN SHOULD BESUPERVISED IF NEAR DRYERS IN OPERATION.
CAUTION
DRYERS SHOULD NEVER BE LEFT UNATTENDED WHILE IN OPERATION.
FOR YOUR SAFETY
DO NOTDRY MOP HEADS IN THE DRYER.
DO NOT USE DRYER IN THE PRESENCE OF DRY CLEANING FUMES.
WARNING
UNDER NO CIRCUMSTANCES should the dryer door switch, lint drawer switch, or
the heat safety circuit devices ever be disabled.
“Caution: Label all wires prior to
disconnection when servicing controls. Wiring
errors can cause improper operation.”
«Attention: Au moment de l’entretien des
commandes,étiqueteztouslesfilsavantde
les débrancher. Des erreurs de câblage
peuvent entraîner un fonctionnement
inadéquat et dangereux.»
WARNING
The dryer must never be operated with any of the back guards, outer tops, or service
panels removed. PERSONAL INJURY OR FIRE COULD RESULT.
IMPORTANT
PLEASE OBSERVEALLSAFETYPRECAUTIONSdisplayedonthe equipment and/or
specified in the installation manual included with the dryer.
WARNING
DRYER MUST NEVER BE OPERATED WITHOUT THE LINT FILTER/SCREEN IN
PLACE, EVEN IF AN EXTERNAL LINT COLLECTION SYSTEM IS USED.
Dryer must not beinstalled or stored in an area where itwillbe exposed towateror weather.
The wiring diagram for the dryer is located in the front electrical control box area.
IMPORTANT
Dryer must be installed in a location/environment, which the ambient temperature
remains between 40° F (4.44° C) and 130° F (54.44° C).
SECTION I
IMPORTANT INFORMATION..........................................................................3
A. Receiving and Handling ............................................................................................................... 3
B. Safety Precautions ...................................................................................................................... 4
SECTION II
SPECIFICATIONS ..............................................................................................6
A. Specifications ............................................................................................................................. 6
SECTION III
INSTALLATION PROCEDURES ......................................................................8
A. Unpacking/Setting Up ................................................................................................................. 8
B. Location Requirements ............................................................................................................... 9
C. Dryer Enclosure Requirements .................................................................................................. 10
D. Fresh Air Supply Requirements ..................................................................................................11
E. Exhaust Requirements ............................................................................................................... 12
F. Electrical Information ................................................................................................................ 18
G. Gas Information........................................................................................................................ 24
H. Steam Information .................................................................................................................... 28
I. Preparation For Operation/Start-Up ......................................................................................... 33
J. Preoperational Tests ................................................................................................................. 34
K. Preoperational Instructions ........................................................................................................ 35
L. Shutdown Instructions ............................................................................................................... 38
SECTION IV
SERVICE/PARTS INFORMATION .................................................................39
A. Service ..................................................................................................................................... 39
B. Parts ........................................................................................................................................ 39
SECTION V
WARRANTYINFORMATION .........................................................................40
A. Returning Warranty Cards......................................................................................................... 40
B. Warranty .................................................................................................................................. 40
SECTION VI
ROUTINE MAINTENANCE ............................................................................41
A. Cleaning ................................................................................................................................... 41
B. Adjustments ............................................................................................................................. 42
C. Lubrication ............................................................................................................................... 42
D. Lint Drawer Removal................................................................................................................ 43
Table of Contents
SECTION VII
DATALABELINFORMATION........................................................................44
SECTION VIII
REVERSINGTIMER SPIN/DWELLADJUSTMENTS ..................................46
SECTION IX
PROCEDURE FOR FUNCTIONAL CHECK
OF REPLACEMENT COMPONENTS............................................................47
SECTION X
SENSOR ACTIVATED FIRE EXTINGUISHING (S.A.F.E.) SYSTEM...........49
3
SECTIONI
IMPORTANTINFORMATION
A. RECEIVING AND HANDLING
The dryer is shipped in a protective stretch wrap cover with protective cardboard corners and top cover (or
optional box) as a means of preventing damage in transit. Upon delivery, the dryer and packaging, and wooden
skid should be visually inspected for shipping damage. If any damage whatsoever is noticed, inspect further
before delivering carrier leaves.
Dryers damaged in shipment:
1. ALL dryers should be inspected upon receipt and before they are signed for.
2. If there is suspected damage or actual damage, the trucker’s receipt should be so noted.
3. If the dryer is damaged beyond repair, it should be refused. Those dryers, which were not damaged in a
damaged shipment should be accepted, but the number received and the number refused must be noted
on the receipt.
4. If you determine that the dryer was damaged after the trucker has left your location, you should call the
delivering carrier’s freight terminal immediately and file a claim. The freight company considers this
concealed damage. This type of freight claim is very difficult to get paid and becomes extremely difficult
when more than a day or two passes after the freight was delivered. It is your responsibility to file freight
claims. Dryer/parts damaged in transit cannot be claimed under warranty.
5. Freight claims are the responsibility of the consignee, and ALL claims must be filed at the receiving end.
JLA assumes no responsibility for freight claims or damages.
6. If you need assistance in handling the situation, please contact the JLA Traffic Manager at 01422 822282.
IMPORTANT: The dryermustbetransported and handled in an upright position at ALLtimes.
4
B. SAFETY PRECAUTIONS
WARNING: Foryour safety, the information in this manual mustbefollowedtominimize the riskof
fireor explosionor toprevent propertydamage, personalinjury, or lossof life.
WARNING: The dryer must never beoperated with any of the back guards, outer tops, or
service panels removed.PERSONAL INJURY OR FIRE COULD RESULT.
1. DO NOT store or use gasoline or other flammable vapors and liquids in the vicinity of this or any other
appliance.
2. Purchaser/user should consult the local gas supplier for proper instructions to be followed in the event the
user smells gas. The instructions should be posted in a prominent location.
3. WHAT TO DO IF YOU SMELL GAS...
a. DO NOT try to light any appliance.
b. DO NOT touch any electrical switch.
c. DO NOT use any phone in your building.
d. Clear the room, building, or area of ALL occupants.
e. Immediately call your gas supplier from a neighbor’s phone. Follow the gas supplier’s instructions.
f. If you cannot reach your gas supplier, call the fire department.
4. Installation and service must be performed by a qualified installer, service agency, or gas supplier.
5. Dryer(s) must be exhausted to the outdoors.
6. Although the manufacturer produces a very versatile dryer, there are some articles that, due to fabric
composition or cleaning method, should not be dried in it.
WARNING: Dry only water washed fabrics. DO NOT dry articles spotted or washed in dry
cleaningsolvents, acombustible detergent,or “allpurpose” cleaner.
EXPLOSIONCOULDRESULT.
WARNING: DO NOT dry rags or articles coated or contaminated with gasoline, kerosene, oil, paint,
orwax.
EXPLOSIONCOULDRESULT.
WARNING: DO NOT dry mop heads. Contamination by wax or flammable solvents will create a
firehazard.
WARNING: DONOT use heat for drying articles that contain plastic, foam, sponge rubber, or
similarly textured rubber materials. Drying in a heated basket (tumbler) may damage
plastics or rubber and may be a fire hazard.
5
7. A program should be established for the inspection and cleaning of lint in the burner area, exhaust ductwork,
and area around the back of the dryer. The frequency of inspection and cleaning can best be determined
from experience at each location.
WARNING: Thecollection of lint in the burner areaand exhaustductwork cancreate a potential fire
hazard.
8. For personal safety, the dryer must be electrically grounded in accordance with local codes and/or the
National Electrical Code ANSI/NFPA NO. 70-LATEST EDITION or in Canada, the Canadian Electrical
Codes Parts 1 & 2 CSA C22.1-1990 or LATEST EDITION.
NOTE: Failure to do so will VOIDTHEWARRANTY.
9. UNDER NO CIRCUMSTANCES should the dryer door switch, lint drawer switch, or the heat safety
circuit devices ever be disabled.
WARNING: PERSONAL INJURY OR FIRE COULD RESULT.
10. This dryer is not to be used in the presence of dry cleaning solvents or fumes.
11. Remove articles from the dryer as soon as the drying cycle has been completed.
WARNING: Articlesleft in the dryer after the dryingand coolingcycles havebeen completed can
create a fire hazard.
12. READ AND FOLLOW ALL CAUTION AND DIRECTION LABELS ATTACHED TO THE
DRYER.
13. For safety, proper operation, and optimum performance, the dryer must not be operated with a load less
than sixty-six percent (66%), 16 lbs (7 kg) of its rated capacity.
WARNING: YOUMUSTDISCONNECTANDLOCKOUTTHEELECTRICSUPPLYAND
THEGAS SUPPLYOR THESTEAM SUPPLYBEFOREANYCOVERSOR
GUARDSAREREMOVEDFROMTHEMACHINETOALLOWACCESS
FOR CLEANING,ADJUSTING,INSTALLATION,ORTESTINGOFANY
EQUIPMENT PER OSHA (OccupationalSafetyandHealthAdministration)
STANDARDS.
IMPORTANT: Dryer must be installedina location/environment, which theambient
temperatureremainsbetween40° F (4.44° C) and 130° F (54.44°C).
6
SECTIONII
SPECIFICATIONS
A. SPECIFICATIONS
Shaded areas are stated in metric equivalents 10/8/03
*A reversing dryer is available with 3-phase (3ø) 1/2 hp (0.373 kW) motors standard.
** Size of piping to dryer varies with installation conditions. Contact factory for assistance.
*** Specify air-operated or electromechanical steam damper system. Air-operated steam damper system must be
provided with clean, dry, and regulated 80 psi +/- 10 psi (5.51 bar +/- 0.68 bar) air supply.
NOTE: Manufacturerreserves theright to make changes inspecifications atany timewithout notice or
obligation.
GasElectric
Steam***
BASKET (TUMBLER) DIAMETER 32-3/4” 83.2 cm
BASKET (TUMBLER) DEPTH 19” 48.3 cm
BASKET (TUMBLER) MOTOR 1/2 hp* 0.373 kW
DOOR OPENING (DIAMETER) 21-1/2” 54.61 cm
BASKET (TUMBLER) VOLUME 9.26 cu ft 0.262 cu m
AIRFLOW (60 Hz) 460 cfm 13.02 cmm
AIRFLOW (50 Hz) 386 cfm 10.93 cmm
DRYERS PER 20’/40’ CONTAINER 14/30
DRYERS PER 45’/48’ TRUCK 45/45
S.A.F.E. WATER CONNECTION 3/4” M.N.P.T.
VOLTAGE AVAILABLE 120-460v 1ø - 3ø 3, 4w 50/60 Hz
APPROX. WEIGHT (UNCRATED) 407 lbs 184.6 kg
APPROX. WEIGHT (CRATED) 446 lbs 202.1 kg
HEAT INPUT 78,000 Btu/hr 19,656 kcal/hr
INLET PIPE CONNECTION 1/2” F.B.S.P.T.**
OVEN SIZE
kW Btu/hr
(60 Hz) kcal/hr
(50 Hz)
15 51,194 12,901
20 68,258 17,201
24 81,910 20,641
VOLTAGE AVAILABLE 120-460v 1ø - 3ø 3, 4w 50/60 Hz
APPROX. WEIGHT (UNCRATED) 435 lbs 197.3 kg
APPROX. WEIGHT (CRATED) 474 lbs 214.8 kg
COMPRESSED AIR VOLUME 0.75 cfh 0.02 cmh
STEAM CONSUMPTION 98.8 lbs/hr 44.8 kg/hr
OPERATING PRESSURE 125 psi max 8.6 bar
BOILER HP NORMAL LOAD 2.9
AIR CONNECTION 1/8” F.N.P.T.
SUPPLY CONNECTION 1” F.N.P.T.
RETURN CONNECTION 1” F.N.P.T.
Otros manuales para D3030
1
Este manual sirve para los siguientes modelos
1
Tabla de contenidos
Otros manuales de Secadora de JLA
JLA
JLA ADC D30 Manual de usuario
JLA
JLA Phase 7 D30 Manual de usuario
JLA
JLA /T75 Guía del administrador
JLA
JLA Phase 7 D90 Manual de usuario
JLA
JLA SD35 Guía del administrador
JLA
JLA SD-30x2 Manual de usuario
JLA
JLA D170 Manual de usuario
JLA
JLA D90 Manual de usuario
JLA
JLA D120 Manual de usuario
JLA
JLA D-78 Manual de usuario
Manuales populares de Secadora de otras marcas
Indesit
Indesit IDV 75 Manual de usuario
Infiniton
Infiniton SD-DG85C Manual de usuario
BOMANN
BOMANN WT 5019 Manual de usuario
Alliance Laundry Systems
Alliance Laundry Systems TMB795C Manual de usuario
Asko
Asko T793C Manual de usuario
Kenmore
Kenmore 8041 - 5.8 cu. Ft. Capacity Electric Dryer Manual de usuario
