10" x 14" VARIABLE SPEED

INDEXING MINI LATHE

STOCK NO. 900492

10M 07/07

©2007 WMH TOOL GROUP, Inc. All Rights Reserved.

The JML-1014VSI is another new addition to our line of JET®Woodturning Lathes. This ½

HP lathe supports stock up to 10" in diameter and 14" in length. This lathe features solid

cast iron construction, the added convenience of a hollow tailstock, a 6" tool rest and

electronic variable speed. The spindle also has a versatile locking /indexing mechanism for

ﬂuting and veining applications.

708375vs.indd 1 7/3/07 6:40:50 AM

jettools.com

10"x 14" VARIABLE SPEED

INDEXING MINI LATHE

•Continously variable speed operation from 500-3900 rpm

•Heavy-duty cast-iron lathe bed adds stability while limiting vibration during operation

•Indexing mechanism which allows for ﬂuting and veining operations

•Self-ejecting tailstock for safe and easy removal of tooling

•Hollow tailstock and removable tip on live center allows for hole boring through stock

•Includes four non-skid rubber feet keep machine stable during use

•3" face plate included

10"x14" VARIABLE SPEED

INDEXING MINI LATHE

STOCK NUMBER 708375VS

Model Number JML-1014VSI

Net Weight (lbs.): 70

Swing Over Bed (in.): 10

Swing Over Tool Rest Base (in.): 7-1/2

Distance Between Centers (in.): 14

Speeds (RPM): Variable from 500-3900

Headstock Taper: MT-2

Spindle Nose (in. x TPI): 1 X 8

Tailstock Taper: MT-2

Hole Through Tailstock (in.): 3/8

Ram Travel (in.): 2

Motor HP: 1/2HP

Motor Phase: 1Ph

Motor Voltage: 115V

1/2HP Motor

Quick

Cam

Locks

2" Ram

Cast-Iron

Construction

6" Tool

Rest

Spindle

with

Indexing

Capability

Chrome

Plated

Handwheel

708375vs.indd 2 7/3/07 6:40:52 AM
