Jensen FOX 1000I Manual de usuario
When setting up the FOX 1000i you can use either
remote control or know/button on top of FOX 1000i.
Navigating menues
1
Connect the enclosed power supply and pull the antenna to
its full length. Put batteries (enclosed) in the remote control and
turn on the FOX1000i using the remote control on/off button.
ON / OFF button
Select / OK
Keys for navigating menues.
When entering the wireless
network password click the
right button to move to next
character.
Keys for entering wireless
network password.
CAUTION
USB
5V 1A
AC IN~
2
Home
Select language / network
The first time you use the FOX1000i you will see a wizard that helps you connecting to the wireless network.
Use the arrow keys on the remote control to select language and setup wireless network.
Enable «Check
network when
power on»?
Yes No
Would you like to
configure network
now?
Yes Yes(WPS) No
1. Select language 2. Select Yes 3. Select Yes
INSTALLATION GUIDE
ENGLISH
Connecting
Connect to wireless network
Click HOME on the remote control and select Internett-radio using the remote control keys and click OK.
4Internet radio
Manual setup (Country)
Manual setup (city)
=Auto detect
My Favorite
Radio station/music
Local radio
History
¯
Norge/DAB
Norge/Top10
Norge/All
Norge/Alternative
NRK P13
NRK P2
NRK P3
NRK P3 Radioresepsjonen
iRadio
NRK P3
Connect to the radio channel you want to save a favorite.
1. Press and hold PRESET button on remote control for 3 seconds.
2. Select an avalable preset position using remote control.
3. Click OK to store preset.
Note! There are separate PRESET lists for DAB, FM and internet radio
Store a favorite channel
1. Press PRESET on remote control.
2. Select radio channel and click OK
Listen to a favorit channel
Select Radio station/music Select Auto detect Select Norway/All
Select radio channel
NOTE! If you want to choose another country please select Manual setup
NRK P13
NRK P2
NRK P3
NRK P3 Radioresepsjonen
To select a different channel,
click left arror key on the remote
control.
Selected radio channel plays
1. Select your wireless network from the
list of available wireless networks.
AirLinkB568DE
AirLink76201A
AirLink7000AC
LYNX3729ad
2. Enter the wireless network
password using the nummeric
keys on the remote control.
3. Scroll trough the different characters
(a,b,c., A, B, C..) by pressing several times
on the same key. Click the right arrow key
before you enter the next character.
bokstav/tall.
OK
3
3
Back Next character
OK
With the free AirMuic Control app you can control most of the functions of the FOX 1000i.
Please note that your smart phone must be connected to the same wireless network as the FOX 1000i.
AirMusic Control is available from both the App store and Google Play.
Scan the QR code or search manualy for «AirMusic Control»
6AirMusic Control app
Android iOS / Apple
AirMusic Control
1. Click home on the remote control
and select DAB/DAB+ and click OK.
5DAB radio
14:55
DABDAB
NRK P1
NRK P2
NRK P3
NRK mP3
21/44
iRadio
List
DABDAB 14:55
NRK P3
3. Select radio channel from
the list using remote control and
click OK.
DAB/DAB+
DAB
FM
14:55 14:55
Scanning...
44
DABDAB
2. FOX 1000i will do a scan for
available DAN/DAB+ channels
the first time you use it.
Selected radio channel plays
14:55
DABDAB
NRK P1
NRK P2
NRK P3
NRK mP3
21/44
To select a different channel,
click left arror key on the remote
control.
Connect to the radio channel you want to save a favorite.
1. Press and hold PRESET button on remote control for 3 seconds.
2. Select an avalable preset position using remote control.
3. Click OK to store preset.
Note! There are separate PRESET lists for DAB, FM and internet radio
Store a favorite channel
1. Press PRESET on remote control.
2. Select radio channel and click OK
Listen to a favorit channel
1. Click home button using
the remote control. Select
Bluetooth and click OK.
7Bluetooth
2. Search for available bluetooth
devices with your smart phone / tablet
and connect to the device: FOX 1000i
14:55
Bluetooth
DAB/DAB+
14:55
3. When FOX 1000i is connected
you will see this symbol
