VX7020A

Operating Instructions

VX7020A

“Made for iPod”and “Made for iPhone” means that an electronic accessory has

is not responsible for the operation of this device or its compliance with safety

or regulatory standards. Please note that the use of this accessory with iPod or

Android is a trademark of Google Inc.

The Bluetooth® word mark and logos are registered trademarks owned by

Bluetooth SIG, Inc. and any use of such marks by the ASA Electronics Corporation

is under license. Other trademarks and trade names are those of their respective

owners.

microSD is a trademark or registered trademark of SD-3C, LLC in the United States,

other countries or both.

Pandora is a registered trademark of Pandora Media, Inc.

Sirius, XM and all related marks and logos are registered trademarks of Sirius XM

VX7020A

CONTENTS

FEATURES ...............................................................................................................5

CONTROLS AND INDICATORS ...............................................................................8

REMOTE CONTROL...............................................................................................10

EXTERNAL DEVICES .............................................................................................16

QUICK START GUIDE ............................................................................................18

EQUALIZER CONTROL MENU ..............................................................................21

SYSTEM SETTINGS ...............................................................................................23

DISC OPERATION .................................................................................................32

RADIO TUNER OPERATION..................................................................................44

USB OPERATION...................................................................................................49

iPod®/iPhone® OPERATION .................................................................................54

AV-In1/AV-In2 OPERATION..................................................................................59

BLUETOOTH OPERATION.....................................................................................60

NAVIGATION QUICK START GUIDE .....................................................................68

REAR CAMERA OPERATION.................................................................................71

STEERING WHEEL CONTROLS (SWC) OPERATION .............................................72

PANDORA RADIO OPERATION ............................................................................74

SiriusXM® RADIO OPERATION ............................................................................78

CARE AND MAINTENANCE ..................................................................................95

SPECIFICATIONS ..................................................................................................96

NOTES ...................................................................................................................98

VX7020A

Load Factory - This feature allows the user to“Reset” to restore the factory default

settings (Rating system only).

To reset the password, access the“RATING” menu and enter the current password.

Once the correct password is entered, you can access the “Password” eld and

enter a new one.

Note: Record the password and keep it in a safe place for future reference. The

rating for each disc is marked on the disc, disc package, or documentation. If

the rating is not available on the disc, the parental lock feature is unavailable.

Some discs restrict only portions of the disc, allowing the appropriate content

will play. For details, please refer to the disc description.

Volume Sub-menu Features

The Volume Sub-menu allows the user to increase or decrease the relative volume

of the audio output of each source individually.

Volume Sub-menu Screen 1 Volume Sub-menu Screen 2

Volume Sub-menu Screens

DVD - Touch the DVD icon to enter the setting, then use the por qicons

increase or decrease the relative volume level between -6 to +6.

USB - Touch the USB icon to enter the setting of the connected device, then use

the por qicons to increase or decrease the relative volume level

between -6 to +6.

Radio - Touch the Radio icon to enter the setting, then use the por qicons

increase or decrease the relative volume level between -6 to +6.

Bluetooth - Touch the Bluetooth icon to enter the setting of the connected

device, then use the por qicons to increase or decrease the relative volume

level between -6 to +6.

VX7020A

Thank you for choosing a Jensen product. We hope you will nd the instructions

in this owner’s manual clear and easy to follow. If you take a few minutes to look

through it, you’ll learn how to use all the features of your new Jensen VX7020A

Multimedia Receiver for maximum enjoyment. Please save this manual for future

reference.

We recommend having your Jensen VX7020AMultimedia Receiver installed by a

reputable installation shop.

FEATURES

DVD

• Audio Equalizer

• Next Chapter and Previous Chapter

• Play/Pause

• Track Direct Entry

• Disc Menu

• Selection Repeat / Track Repeat

• Disc Audio

• Disc Language

• Pic Control

CD / MP3 / WMA

• CD-Text Compatible

• ID3 Tag Compatible

• Directory Search (MP3 / WMA Only)

• Burn up to 1500 MP3 and WMA Files onto a DVD+R / RW

• Audible Forward / Reverse Track Search (CD-DA Only)

• Random, Repeat and Intro

• Play, Pause, Stop, Next Track and Previous Track

AM-FM

• USA, China, Japan, Europe, Europe (LW) and Orient (OIRT)

• 30 Station Presets (18 FM / 12 AM)

• Auto Stereo / Mono

• Local / Distance

• Auto Store / Preview Scan

iPod®/iPhone®

• iPod®/ iPhone® via USB

• High Speed Direct Connect Interface to Access iPod® Playlists, Artists, Albums

and Songs. Play music and view video/photo* les from your iPod®. *Video/

photo playback requires jLink-USB iPod® interface cable (sold separately).

• Power Management Charges iPod® while Connected

VX7020A

SiriusXM-Ready®

• Satellite Channel Name, Artist, Song, and Categories Displayed on Monitor

(Vehicle Tuner and Subscription required and sold separately)

Chassis

• 2.0 DIN (Import / ISO-DIN Mountable)

• Fixed Front Panel

• 6.2” High Denition TFT LCD

• 1,152,000 Sub Pixels (800 x 3 x 480)

General

• Beep Tone Conrmation (ON-OFF Option)

• Built-In Bluetooth® providing Hands-Free operation for safety and convenience

and A2DP for streaming music from your smartphone or other Bluetooth®

device.

• One Composite Video Output for Additional Screens

• Front Panel Audio/Video Input

• Front Panel USB - Playback Music / Video Files via Portable Hard Drives / USB

Sticks

• Ten-Band Tone Equalizer

• Rear Subwoofer Line Output

• Rear Camera Input

• Touch Screen Calibration Mode

• Rotary Encoder Audio Control

Rear Camera

• The VX7020Ais “camera ready.”Before accessing any camera features, you must

purchase and install a rear video camera.

Navigation

• Tele Atlas Map Data

• 11 Million Points of Interest

• External Memory 4GB SD Card

• Latest Map Guarantee (Must be redeemed within 90 days of initial activation)

• 13 Natural Voice Languages for Navigation Guidance

VX7020A

WARNING! Never install this unit where operation and viewing could interfere

with safe driving conditions.

WARNING! To reduce the risk of a trac accident (except when using for rear

view video camera) never use the video display function while driving the vehicle.

This is a violation of federal law.

WARNING! Never disassemble or adjust the unit.

WARNING! To prevent injury from shock or re, never expose this unit to moisture

or water.

WARNING! Never use irregular discs.

WARNING! To prevent damage to the mechanism inside this unit, avoid impact to

the unit’s monitor.

WARNING! Using an improper fuse may cause damage to the unit and result in

re.

VX7020A

CONTROLS AND INDICATORS

VX7020

AV INPUT

EJECT

MUTE

Bluetooth

6VRMS Line Out

OPEN

VX7020AControls and Indicators

1. Disc Slot:

Accepts DVD/CD/MP3 discs. If the unit is turned on, playback begins when a

disc is inserted.

2. LCD Screen and Touch Screen:

Touch icons on this screen to access menus or control functions.

3. Remote Sensor:

Used to receive command signals from the remote control.

4. 3.5mm AV IN Jack:

This connector accepts a 3.5 mm jack through which signals from various

audio/video devices can be applied to the unit.

5. MicroSD Card Slot:

Used to insert microSD cards containing navigation software updates.

VX7020A

6. USB Slot:

Used to connect an iPod®, MP3 player or ash drive connection adapter for

playback of music/video les.

7. Interface Cover:

Covers the AV IN jack, microSD card slot, and USB slot.

8. Reset Button:

Press this button to reset the system settings (except password and parental

lock settings) and to correct a system halt or other illegal operation. Use the

tip of a pen to press the Reset button.

9. Power On/O ( ) Button / Rotary Volume ( ) Knob / Mute Button

Press to turn the unit ON. Press and hold to turn the unit o.

Rotate the knob to adjust the volume from 0 to 50.

Press the knob momentarily to mute the audio. Press the knob again to

restore the audio.

10. Menu Button:

Press this button to access the Main touch screen menu.

11. Eject ( ) Button:

Press this button to eject a DVD/CD/MP3 disc. Disc play is stopped, the disc is

ejected and the unit will change to radio operation. If the disc is not removed

from the unit and the button is pressed again, the disc will be re-loaded. If the

disc is not removed from the disc slot within 10 seconds of being ejected, it

will be automatically reloaded to prevent it from being accidentally damaged.
