Jensen VX6020 Manual de usuario

VX6020

Operating Instructions

watts peak

40W x 4

Owner’s Manual

VX6020

CONTENTS

FEATURES 5

CONTROLS AND INDICATORS 8

REMOTE CONTROL 10

EXTERNAL DEVICES 14

QUICK START 16

EQUALIZER CONTROLS MENU 20

SYSTEM SETTINGS 22

DISC OPERATION 30

RADIO TUNER OPERATION 40

iPod®/iPhone® OPERATION 46

USB AND SD CARD CONTROLS 50

AV-In1/AV-In2 CONTROLS 55

BLUETOOTH OPERATION 56

NAVIGATION QUICK START GUIDE 64

STEERING WHEEL CONTROL (SWC) OPERATION 68

REAR CAMERA OPERATION 69

TROUBLESHOOTING 70

DISC ERROR MESSAGES 73

CARE AND MAINTENANCE 74

SPECIFICATIONS 76

iPod® Control “iPod” is a trademark of Apple Computer, Inc., registered in

the U.S. and other countries. Bluetooth® is a trade mark of Bluetooth Special

Interest Group (SIG) Inc.

VX6020

FCC Statement

1. This device complies with Part 15 of the FCC Rules.

Operation is subject to the following two conditions:

(1) This device may not cause harmful interference.

(2) This device must accept any interference received, including interference that may

cause undesired operation.

2. Changes or modications not expressly approved by the party responsible for com-

pliance could void the user’s authority to operate the equipment.

NOTE: This equipment has been tested and found to comply with the limits for a Class

B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to pro-

vide reasonable protection against harmful interference in a residential

installation.

This equipment generates uses and can radiate radio frequency energy and, if not

installed and used in accordance with the instructions, may cause harmful interference

to radio communications. However, there is no guarantee that interference will not

occur in a particular installation. If this equipment does cause harmful interference to

radio or television reception, which can be determined by turning the equipment o

and on, the user is encouraged to try to correct the interference by one or more of the

following measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and receiver.

• Connect the equipment into an outlet on a circuit dierent from that to which the

receiver is connected.

• Consult the dealer or an experienced radio/TV technician for help.

FCC Radiation Exposure Statement

This equipment complies with FCC radiation exposure limits set forth for an

uncontrolled environment. This equipment should be installed and operated with

minimum distance of 20 centimeters between the radiator and your body.

VX6020

FEATURES

Congratulations on the purchase of the In-Dash Navigation Radio. Please read

the instruction manual for this product before using. The documentation

provided will allow the user to fully enjoy all the features of your new Jensen

VX6020 Mobile Multimedia Receiver. Please read all of the instructions

before beginning the installation and save this manual for future reference.

We recommend having your Jensen VX6020 installed by a reputable installation shop.

DVD

• Audio Equalizer

• Next Chapter and Previous Chapter

• Play/Pause

• Track Direct Entry

• Disc Menu

• Selection Repeat / Track Repeat

• Disc Audio

• Disc Language

• Pic Control

CD / MP3 / WMA

• CD-Text Compatible

• ID3 Tag Compatible

• Directory Search (MP3 / WMA Only)

• Burn up to 1500 MP3 and WMA Files onto a DVD+R / RW

• Audible Forward / Reverse Track Search (CD-DA Only)

• Random, Repeat and Intro

• Play, Pause, Stop, Next Track and Previous Track

AM-FM

• USA, China, Japan, Europe, Europe (LW) and Orient (OIRT)

• 30 Station Presets (18 FM / 12 AM)

• Auto Stereo / Mono

• Local / Distance

• Auto Store / Preview Scan

iPod®/iPhone®

• iPod®/ iPhone® via USB

• High Speed Direct Connect Interface to Access iPod® Playlists, Artists, Albums

and Songs. Play music and view video/photo* les from your iPod®. *Video/photo

playback requires jLink-USB iPod® interface cable (sold separately).

• Power Management Charges iPod® while Connected

VX6020

Chassis

• 2.0 DIN (Import / ISO-DIN Mountable)

• Fixed Front Panel

• 6.2” High Denition TFT LCD

• 1,152,000 Sub Pixels (800 x 3 X 480)

• Beep Tone Conrmation (ON-OFF Option)

General

• Navigation is built in - iGo primo

• Built-In Bluetooth® providing Hands-Free operation for safety and convenience

and A2DP for streaming music from your smartphone or other Bluetooth®

device.

• One Composite Video Output for Additional Screens

• Front Panel Audio/Video Input

• Ten-Band Tone Equalizer

• Rear Panel Audio/Video RCA Input

• Rear Subwoofer Line Output

• Rear Camera Input

• Touch Screen Calibration Mode

• Rotary Encoder Audio Control

REAR CAMERA

The VX6020 is “camera ready.” Before accessing any camera features, you must

purchase and install a rear video camera.

VX6020

WARNING! Never install this unit where operation and viewing could interfere

with safe driving conditions.

WARNING! To reduce the risk of a trac accident (except when using for rear

view video camera) never use the video display function while driving the vehicle.

This is a violation of federal law.

WARNING! Never disassemble or adjust the unit.

WARNING! To prevent injury from shock or re, never expose this unit to moisture

or water.

WARNING! Never use irregular discs.

WARNING! To prevent damage to the mechanism inside this unit, avoid impact to

the unit’s monitor.

WARNING! Using an improper fuse may cause damage to the unit and result in

re.

VX6020

CONTROLS AND INDICATORS

1. DISC Slot: Accepts DVD/CD/MP3 discs. If the unit is turned on, playback

begins when a disc is inserted.

2. REMOTE SENSOR: Used to receive command signals from the remote

control.

3. LCD Screen and Touch Screen: Touch icons on this screen to access

menus or control functions.

4. INTERFACE COVER: Covers the Micro SD/ SD/ Mini USB slots and AV Input

Connector.

5. MINI USB SLOT: Used to connect iPod / MP3 player connection adapter.

6. AV INPUT CONNECTOR: This connector accepts a 3.5 mm jack through

which signals from various audio/video devices can be applied to the unit.

7. MICRO SD CARD SLOT: Used to insert the Micro SD Card for the Navigation

Map (or rmware updates if required) only, not for music or other les.

8. SD CARD SLOT: Used for inserting SD Cards containing photos, audio and

video for playback.

VX6020

SD CARD

AV INPUT

EJECT

Bluetooth

NAVIGATION

OPEN

AV-

Figure 2. VX6020 Controls and Indicators

VX6020

9. RESET Button: Press this button to reset the system settings (except

password and parental lock settings) and to correct a system halt or

other illegal operation. Use the tip of a pen to press the Reset button.

10. ROTARY KNOB ( ) Power ON/OFF, Volume, and Mute Control: Press

the knob to turn the unit ON. Press and hold the knob for 2 seconds to turn the

unit OFF. Rotate the knob to adjust the volume from 0 to 50. Press the knob

momentarily to mute the audio. Press the knob again to restore the audio.

11. MENU Button: Press this button to access the Main touch screen menu.

Press and hold to switch to Navigation screen.

12. Eject ( ) Button: Press this button to eject a DVD/CD/MP3 disc. Disc play is

stopped, the disc is ejected and the unit will change to radio operation. If the

disc is not removed from the unit and the button is pressed again, the disc will

be re-loaded. If the disc is not removed from the disc slot within 10 seconds

of being ejected, it will be automatically reloaded to prevent it from being

accidentally damaged.

13. MICROPHONE: Used for Bluetooth® communication.

VX6020

REMOTE CONTROL

18 16

Figure 2. VX6020 Remote Control
