DOOR AND PANEL PARTS

For Models: JDB1275AWF1, JDB1275AWY1

(White) (Black)

6−11 Litho In U.S.A. (cre)(psw) Part No. W10267600 Rev. A

UNDERCOUNTER

DISHWASHER

Illus. Part

No. No. DESCRIPTION Illus. Part

No. No. DESCRIPTION

1 Literature Parts

W10212195

Instructions,

Installation

W10260101

Energy Guide

W10157785

Guide, Use & Care

2 99002693 Insulation, Door

3 99003048 Barrier, Foam

4 Block, Foam

99003046 Left

99003047 Right

5 99003049 Wrap, Foam

6 Bracket, Hinge

W10118638

Left

W10118637

Right

7 99001075 Screw

8 99003433 Support, Inner

Door

9 99003095 Anchor, Panel

Fastener

10 99003093 Pad, Foam

11 Panel, Front

99003090 Black (also order

99003444 Facia)

99003092 White (also order

99003445 Facia)

12 Screw

912366 Black

99001194 White

W10167659

Plate, Handle

Black

14 99003088 Handle, Door

15 99002414 Insulation, Toe

Panel

16 Damper, Toe Panel

99002694 Black

99002698 White

17 Panel, Toe

(Includes Item 16)

99002765 Black

99002766 White

18 Support, Front

99002859 Black

99002860 White

19 6918667 Stud, Handle

20 99003154 Screw

CONTROL PANEL PARTS

For Models: JDB1275AWF1, JDB1275AWY1

(White) (Black)

W10267600

Illus. Part

No. No. DESCRIPTION

1 99002575 Housing, Board

(Top)

W10218836

Board, Control

3 99002576 Housing, Board

W10161783

Panel, Control

5 99002751 Switch, Door

6 99003347 Latch, Assembly

7 99003096 Fastener, Panel

DOOR AND LATCH PARTS

For Models: JDB1275AWF1, JDB1275AWY1

(White) (Black)

W10267600

Illus. Part

No. No. DESCRIPTION Illus. Part

No. No. DESCRIPTION

1 99003308 Harness, Wiring

2 99003045 Seal, Door

(Bottom)

3 99003060 Cap, Rinse Aid

4 99003320 Dispenser, Rinse

Aid

5 Y912620 Screw, Door

W10203664

Inner Door

W/ Damper

7 99002465 Bracket, Dispenser

8 912615 Screw

9 99003044 Insulation, Door

LOWER WASHARM PARTS

For Models: JDB1275AWF1, JDB1275AWY1

(White) (Black)

W10267600

Illus. Part

No. No. DESCRIPTION

1 99003083 Cap, Wash Arm

2 99003144 Wash Arm, Lower

(Includes Item 3)

W10218606

Shield, Radiant

HEATER PARTS

For Models: JDB1275AWF1, JDB1275AWY1

(White) (Black)

W10267600

Illus. Part

No. No. DESCRIPTION

1 99002971 Heater Element

Assembly

W/ Gasket

2 99003033 Nut, Heater

3 99003032 Bracket, Heater

Support

NOTE:

If heater element is

removed, it must be replaced.

FILL AND OVERFILL PARTS

For Models: JDB1275AWF1, JDB1275AWY1

(White) (Black)

W10267600

Illus. Part

No. No. DESCRIPTION

1 99002852 Hose, Inlet

2 911856 Clamp, Spring

3 99002975 Valve, Water

W10205539

Switch, Float

5 99002652 Hose, Drain

W10130099

Float

7 99003028 Inlet, Air/Water

8 99003037 Standpipe, Float

9 99003040 Seal, Standpipe

W10130109

Holder, Float

Switch

TUB AND FRAME PARTS

For Models: JDB1275AWF1, JDB1275AWY1

(White) (Black)

W10267600

TUB AND FRAME PARTS

For Models: JDB1275AWF1, JDB1275AWY1

(White) (Black)

W10267600

Illus. Part

No. No. DESCRIPTION Illus. Part

No. No. DESCRIPTION

W10119337

Strike, Door

2 99002648 Bracket, Cabinet

Mounting

3 6−912799 Screwr

4 99002610 Bracket, Spring

Adjustment

5 99002636 Bracket, Support

6 Trim, Corner Edge

99003039 Right

99003038 Left

7 99003688 Nut

W10173920

Bracket, Cable

9 99002608 Roller, Cable

Bracket

10 99003687 Bolt, Shoulder

11 99003118 Spring, Door

12 99003446 Door Cable Assy.

13 Gap Seal,

Toe Kick

99002701 Black

99002703 White

14 99002849 Insulation, Tub

15 99003337 Seal, Door

16 Tub Assembly

(Not Serviced)

17 99003041 Trim, Tub Edge

(Bottom)

W10167660

Bracket, Support

(Rear)

19 99002633 Thermostat,

Limiting

W10167658

Clip, Thermostat

21 99002692 Screw, Trim

Mounting

22 99002637 Bracket, Junction

Box

W10143258

Leg, Leveling

W10164700

Strip,Trim Left

25 99002638 Cover, Junction

Box

W10164702

Strip,Trim Top

W10164701

Strip,Trim Right

28 Support, Hinge

W10117484

Right

W10117485

Left

29 Backer, Hinge

W10174581

Right

W10174569

Left

30 99003155 Screw

31 99002150 Seal, Air/Water

Inlet

32 6−918397 Grill, Air/Water

Inlet

W10167916

Clamp, Rear

Support

PUMP AND MOTOR PARTS

For Models: JDB1275AWF1, JDB1275AWY1

(White) (Black)

W10267600

PUMP AND MOTOR PARTS

For Models: JDB1275AWF1, JDB1275AWY1

(White) (Black)

W10267600

Illus. Part

No. No. DESCRIPTION

1 99002666 Screw

W10166790

Guard, Filter

3 99002668 Screw

W10212444

Discharge, Housing

Assembly

5 99002659 Wash Impeller

Assembly

W10192800

Filter/Flowplate,

Assembly

7 99003055 Gasket, Motor

Mount

8 99003056 Lever, Motor Mount

9 99003057 Plunger, Motor

Mount

10 99002651 O−Ring, Turbidity

Sensor

W10120019

Sensor, Turbidity

12 99003697 Pivot, Wash Arm

13 99002664 Screw

14 99003427 Chopper

W10118627

Wash Motor Assy.

16 99003309 Flapper, Drain

Pump Inlet

17 99002857 O−Ring, Drain Pump

18 99002740 Screw

W10200518

Drain Pump Assy.

W10167912

Sheild, Capacitor

21 99002665 Capacitor

22 99002601 Screw
