JEM ASCT 5 - 40 Guía de configuración
Repair instructions
ASCT 5 - 40
All rights reserved by FEIN, especially in case of industrial rights registration.
Any power of disposition such as copying and right of transfer is situated with FEIN. C-SC_CSSM Page 1/26
05.2012
Repair instructions
Summary
1. Technical data and test data
2. Provisions
4. Disassembly
5
Assembly
5
.
Assembly
6. Tools
All rights reserved by FEIN, especially in case of industrial rights registration.
Any power of disposition such as copying and right of transfer is situated with FEIN. C-SC_CSSM Page 2/26
05.2012
Repair instructions
1. Technical data and test data
The complete technical data can be found in the operating instructions for the model.
Up
-
to
-
date test data for all models can be found on the FEIN Extranet
Up
to
date
test
data
for
all
models
can
be
found
on
the
FEIN
Extranet
.
Lists of spare parts and exploded views are available online at www.fein.com
All rights reserved by FEIN, especially in case of industrial rights registration.
Any power of disposition such as copying and right of transfer is situated with FEIN. C-SC_CSSM Page 3/2605.2012
Repair instructions
2. Provisions
Provisions:
Please note that power tools may only be repaired, maintained and checked by a trained
electrician, as improper repair can result in serious risks to the user.
The provisions set out in DIN VDE 0701-0702 should be observed after repairs.
Only use original FEIN spare parts!
The relevant accident prevention regulations of the employers’ liability insurance
associations are to be observed when commissioning
associations
are
to
be
observed
when
commissioning
.
The German Equipment and Product Safety Act applies for correct use.
Outside Germany, the regulations applicable in the relevant country must be observed!
All rights reserved by FEIN, especially in case of industrial rights registration.
Any power of disposition such as copying and right of transfer is situated with FEIN. C-SC_CSSM Page 4/2605.2012
Repair instructions
3. Disassembly
Remove battery, hook, wrist strap, depth stop sleeve and screwdriver bit
Remove screw on pushbutton and pushbutton
Loosen screws on gearbox housing and remove gearbox housing
Tool
PH 2 cross-tip screwdriver
TX 15 Torx screwdriver
All rights reserved by FEIN, especially in case of industrial rights registration.
Any power of disposition such as copying and right of transfer is situated with FEIN. C-SC_CSSM Page 6/2605.2012
Repair instructions
3. Disassembly
Loosen and remove screws on motor housing
Remove upper section of housing
Loosen switch contacts
Tool
TX 15 Torx screwdriver
All rights reserved by FEIN, especially in case of industrial rights registration.
Any power of disposition such as copying and right of transfer is situated with FEIN. C-SC_CSSM Page 7/2605.2012
Repair instructions
Information about switch connections
Tool
Flat nose pliers
When changing switches, note the coloured connections, as otherwise the tool will not work or only have
limited functionality
All rights reserved by FEIN, especially in case of industrial rights registration.
Any power of disposition such as copying and right of transfer is situated with FEIN. C-SC_CSSM Page 8/2605.2012
Repair instructions
3. Disassembly
Remove switch
Remove motor, electronics and connecting cable from motor housing
Unsolder electronics from motor – warning: note how the cables are laid!!!!!
Tool
TX 15 Torx screwdriver
All rights reserved by FEIN, especially in case of industrial rights registration.
Any power of disposition such as copying and right of transfer is situated with FEIN. C-SC_CSSM Page 9/2605.2012
Repair instructions
3. Disassembly
Unsolder electronics from motor
–
warning: note how the cables are laid!!!!!
Unsolder
electronics
from
motor
warning:
note
how
the
cables
are
laid!!!!!
Remove grease wiper ring and ball bearing
Remove bearing support Tool
TX 15 Torx screwdriver
All rights reserved by FEIN, especially in case of industrial rights registration.
Any power of disposition such as copying and right of transfer is situated with FEIN. C-SC_CSSM Page 10/2605.2012
Repair instructions
Information
Warning
the bearing support can only be fitted in one position
see circles!!!!!!!!!
Warning
–
the
bearing
support
can
only
be
fitted
in
one
position
–
see
circles!!!!!!!!!
The third support must always be on the white terminal strip.
All rights reserved by FEIN, especially in case of industrial rights registration.
Any power of disposition such as copying and right of transfer is situated with FEIN. C-SC_CSSM Page 11/2605.2012
