JDS Uniphase OLS-34 Manual de usuario
800.887 .5065
"
OLS-34/-35/-36
Optical Laser Sources
BN 2303/98.11
2010.10
English
BN 2303/01
BN 2303/02
BN 2303/03
BN 2303/04
BN 2303/11
BN 2303/12
BN 2303/13
BN 2303/15
BN 2303/21
BN 2303/22
BN 2303/23
BN 2303/25
Operating Manual
Please direct all enquiries to your local
JDSU sales company.
The addresses can be found at:
http://www.jdsu.com/test
The description of additional features of the
device can be found at:
http://www.jdsu.com/tm
Copyrights
This product or parts of this product are based on
the Recommendations and/or Standards issued by
the Standardization Sector of the International
Telecommunication Union - ITU-T and/or the
European Telecommunications Standards Institute
- ETSI. These Recommendations and Standards
are copyright to these organizations. ITU-T
Recommendations or ETSI Standards may not be
copied and/or made available to third parties in
whole or in part without the written agreement of
ITU-T and/or ETSI.
© Copyright 2010 JDSU Deutschland GmbH
All rights reserved.
JDSU and JDSU logo are trademarks of JDS
Uniphase Corporation. Other trademarks are the property
of their respective holders.
JDSU Deutschland GmbH
Mühleweg 5, 72800 Eningen u. A.
Note: Changes may be made to specifications,
descriptions and delivery information.
Printed in Germany
Order no.: BN 2303/98.11
Version: 2010.10
Previous Version: 2010.08
JDSU OLS-34/-35/-36 I
CONTENTS
1INTRODUCTION . . . . . . . . . . . . . . . . . . . . . . . 1
OLS-34/-35/-36 Optical Laser Sources . . . . . . . . . 1
Operating manual update . . . . . . . . . . . . . . . . . . . 3
Symbols used in this operating manual . . . . . . . . 4
2SAFETY INFORMATION. . . . . . . . . . . . . . . . . . 6
Warning symbols on the unit. . . . . . . . . . . . . . . . . 6
Proper usage. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Laser safety. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Battery operation. . . . . . . . . . . . . . . . . . . . . . . . . . 8
Ventilation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
3GETTING STARTED . . . . . . . . . . . . . . . . . . . . 9
Unpacking the device . . . . . . . . . . . . . . . . . . . . . . 9
Device overview OLS-34/35 . . . . . . . . . . . . . . . . 10
Device overview OLS-36. . . . . . . . . . . . . . . . . . . 12
Power supply. . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
4OPERATION . . . . . . . . . . . . . . . . . . . . . . . . 17
Switching the device on/off . . . . . . . . . . . . . . . . . 17
Display elements. . . . . . . . . . . . . . . . . . . . . . . . . 18
Selecting a wavelength . . . . . . . . . . . . . . . . . . . . 20
Changing the port . . . . . . . . . . . . . . . . . . . . . . . . 20
Enabling signal modulation . . . . . . . . . . . . . . . . . 20
Auto-Lambda mode. . . . . . . . . . . . . . . . . . . . . . . 21
Multi-Lambda mode . . . . . . . . . . . . . . . . . . . . . . 21
5MAINTENANCE . . . . . . . . . . . . . . . . . . . . . . 22
Cleaning the test port . . . . . . . . . . . . . . . . . . . . . 22
Cleaning the instrument . . . . . . . . . . . . . . . . . . . 23
CONTENT
II OLS-34/-35/-36 JDSU
6SPECIFICATIONS . . . . . . . . . . . . . . . . . . . . . 24
OLS-34 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
OLS-35 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
OLS-36 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
General specifications . . . . . . . . . . . . . . . . . . . . . 27
7ORDERING INFORMATION . . . . . . . . . . . . . . 28
Devices . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
Accessories . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
JDSU OLS-34/-35/-36 1
1INTRODUCTION
OLS-34/-35/-36
Optical Laser Sources
The Test Sets are specially designed for high
performance testing of all systems, i.e. broadband,
PONs, and Gigabit Ethernet.
Battery operation from two AA batteries and the robust,
shock-proof design provide long operating time in the
field even under tough conditions. AC line operation via
a separate AC adapter and the USB interface ensure
ease of use in the laboratory or production environment.
Differences between the devices
The OLS-34/-35/-36 family covers all the modes,
wavelengths and fiber types needed. The table below
lists the differences between the devices:
OLS-34
Model
BN...
Fiber
type
Wave-
lengths
Connector
type
2303/01 MM 50/125 850/1300 nm Interchange.
adapter
BN 2150/00.xx
2303/02 MM 50/125 850/1300 nm FC/PC
2303/03 MM 50/125 850/1300 nm SC/PC
2303/04 MM 50/125 850/1300 nm ST
2 OLS-34/-35/-36 JDSU
1 INTRODUCTION
OLS-35
OLS-36
Test adapters
The OLS-34/-35/-36 is looped into the test configuration
using test adapters which are available for all common
connector systems (e.g. FC, ST).
Model
BN...
Fiber
type
Wave-
lengths
Connector
type
2303/11 SM 9/125 1310/1550 nm Interchange.
adapter
BN 2150/00.xx
2303/12 SM 9/125 1310/1550 nm FC/PC
2303/13 SM 9/125 1310/1550 nm SC/PC
2303/15 SM 9/125 1310/1550 nm LC/PC
Model
BN...
Fiber
type
Wave-
lengths
Connector
type
2303/21 MM 50/125
SM 9/125
850/1300 nm
1310/1550 nm
Interchange.
adapter
BN 2150/00.xx
2303/22 MM 50/125
SM 9/125
850/1300 nm
1310/1550 nm
FC/PC
2303/23 MM 50/125
SM 9/125
850/1300 nm
1310/1550 nm
SC/PC
2303/25 MM 50/125
SM 9/125
850/1300 nm
1310/1550 nm
LC/PC
JDSU OLS-34/-35/-36 3
1 INTRODUCTION
Operating manual update
If the operating instructions about features provided by
your device are missing, please visit the JDSU web site
to check if additional information is available.
To download the latest operating instructions:
1. Visit the JDSU web site at www.jdsu.com/test.
2. Select your model from the product line or use the
search function.
3. Open the download area and download the operating
instructions if available.
4 OLS-34/-35/-36 JDSU
1 INTRODUCTION
Symbols used in this
operating manual
The following symbols, warnings and character formats
are used in this operating manual:
CAUTION
Follow the instructions carefully to
avoid damage to the device.
WARNING
Follow the instructions carefully to
avoid damage to the device or injury
to the person.
DANGER
Follow the instructions carefully to
avoid damage to the device or severe
injury to the person.
High Voltage
Follow the instructions carefully to
avoid damage to the device or severe
injury to the person.
This safety instruction is given if the
danger is due to high voltage.
Laser
Follow the instructions carefully to
avoid damage to the device or severe
injury to the person.
This safety instruction is given if the
danger is due to laser radiation.
Information specifying the laser class
is also given.
!Very important instruction
Follow this instruction carefully; e.g.
!Make sure you protect yourself and
others from exposure to laser light.
JDSU OLS-34/-35/-36 5
1 INTRODUCTION
✔Requirement
This requirement must be met first;
e.g.
✔The system is switched on
⇒
1.
2.
Instruction
Follow the instructions given (the
numbers indicate the order in which
the instructions should be followed);
e.g.
⇒Select mode.
Italics Result
Indicates the result of following an
instruction; e.g.
The page opens.
Bold type
face Pages, controls, and display
elements
Screen pages, controls, and display
elements are indicated in bold type.
[Store] Instrument keys
Instrument keys are indicated within
square brackets.
