JBL PLAYLIST 150 Manual de usuario

What’s in the box

2Buttons

Quick Start Guide

Guide de démarrage rapide

PLAYLIST 150

3Wi-Fi Setup

Step 1: Download the JBL Wireless Setup app., scan QR code needed for both iOS App

Store and Google Play Store downloading

Step 2: Power on the speaker, then press and hold the “Play” to enter Wi-Fi

Step 3: Find Stream in the app, and follow the guide

Step 4: Select network and input password, till the indication of Wi-Fi

connected shown

Quick Start Guide

Guide de démarrage rapide

PLAYLIST 150

4Google Cast play music procedure

Step 2: Play musicStep 1: Open Google Cast supported app

Step 3: Tap the cast icon and select “JBL GC150”

** Google Cast support app - refer to link - https://www.google.com/cast/apps/

5Spotify play music procedure

Step 1: Open Spotify app Step 2: Play music

Step 3: Tap the Spotify connect icon and select “JBL GC150”

Quick Start Guide

Guide de démarrage rapide

PLAYLIST 150

6Bluetooth

1. Bluetooth connection setup process

PLAYLIST 150

2. Music control process

x1 x2

Quick Start Guide

Guide de démarrage rapide

PLAYLIST 150

8LED behavior

9Warning

Standby Power on Bluetooth

Pairing

Speaker

Connecting

Speaker

Connected NA NA

Bluetooth

Connected

(White) (White) (Blue) (Blue)

Care on Passive radiator

Quick Start Guide

Guide de démarrage rapide

PLAYLIST 150

7Connections

Reset

• Bluetooth version: 4.1

• Support: A2DP V1.2, AVRCP V1.0

• Transducer: 2 x 50mm

• Rated Power: 2 x 15W

•Frequency Response: 60 – 20KHz

• Maximum SPL: 92dB

• Power supply: 19VDC, 2.0A

• Power consumption in sleep mode: <2.0 Watts

• Dimension: 316 x 131 x 147 mm

• Weight: 1200g

• Bluetooth transmitter power: <4 dBm

• Bluetooth transmitter frequency range: 2.402 – 2.480 GHz

• Bluetooth transmitter modulation: GFSK, π/4 DQPSK, 8DPSK

• 2.4G Wi-Fi Transmitter frequency range: 2.412 – 2.472 GHz

(2.4GHz ISM band, USA 11 channels, Europe and others 13 channels)

• 2.4G Wi-Fi transmitter power: <20dBm (EIRP)

• 2.4G Wi-Fi modulation: OFDM, DSSS, DBPSK, DQPSK, CCK,

16QAM, 64QAM

• 2.4G Wi-Fi network compatibility: IEEE 802.11 b/g/n

• 5G Wi-Fi Transmitter frequency range: 5.15 - 5.35GHz,

5.470 - 5.725GHz, 5.725 - 5.825GHz

• 5G Wi-Fi transmitter power: <20dBm (EIRP)

• 5G Wi-Fi modulation: OFDM, BPSK, QPSK, 16QAM,

64QAM, 256QAM

• 5G Wi-Fi network compatibility: IEEE 802.11 n/ac

Quick Start Guide

Guide de démarrage rapide

PLAYLIST 150

• Bluetooth version: 4.1

• Support: A2DP V1.2, AVRCP V1.0

• Transducer: 2 x 50mm

• Rated Power: 2 x 15W

•Frequency Response: 60 – 20KHz

• Maximum SPL: 92dB

• Power supply: 19VDC, 2.0A

• Power consumption in sleep mode: <2.0 Watts

• Dimension: 316 x 131 x 147 mm

• Weight: 1200g

• Bluetooth transmitter power: <4 dBm

• Bluetooth transmitter frequency range: 2.402 – 2.480 GHz

• Bluetooth transmitter modulation: GFSK, π/4 DQPSK, 8DPSK

• 2.4G Wi-Fi Transmitter frequency range: 2.412 – 2.472 GHz

(2.4GHz ISM band, USA 11 channels, Europe and others 13 channels)

• Weight: 16.3kg

• 2.4G Wi-Fi transmitter power: <20dBm (EIRP)

• 2.4G Wi-Fi modulation: OFDM, DSSS, DBPSK, DQPSK, CCK,

16QAM, 64QAM

• 2.4G Wi-Fi network compatibility: IEEE 802.11 b/g/n

• 5G Wi-Fi Transmitter frequency range: 5.15 - 5.35GHz,

5.470 - 5.725GHz, 5.725 - 5.825GHz

• 5G Wi-Fi transmitter power: <20dBm (EIRP)

• 5G Wi-Fi modulation: OFDM, BPSK, QPSK, 16QAM,

64QAM, 256QAM

• 5G Wi-Fi network compatibility: IEEE 802.11 n/ac

Quick Start Guide

Guide de démarrage rapide

PLAYLIST 150

• Bluetooth version: 4.1

• Support: A2DP V1.2, AVRCP V1.0

• Transducer: 2 x 50mm

• Rated Power: 2 x 15W

•Frequency Response: 60 – 20KHz

• Maximum SPL: 92dB

• Power supply: 19VDC, 2.0A

• Power consumption in sleep mode: <2.0 Watts

• Dimension: 316 x 131 x 147 mm

• Weight: 1200g

• Bluetooth transmitter power: <4 dBm

• Bluetooth transmitter frequency range: 2.402 – 2.480 GHz

• Bluetooth transmitter modulation: GFSK, π/4 DQPSK, 8DPSK

• 2.4G Wi-Fi Transmitter frequency range: 2.412 – 2.472 GHz

(2.4GHz ISM band, USA 11 channels, Europe and others 13 channels)

• Weight: 16.3kg

• 2.4G Wi-Fi transmitter power: <20dBm (EIRP)

• 2.4G Wi-Fi modulation: OFDM, DSSS, DBPSK, DQPSK, CCK,

16QAM, 64QAM

• 2.4G Wi-Fi network compatibility: IEEE 802.11 b/g/n

• 5G Wi-Fi Transmitter frequency range: 5.15 - 5.35GHz,

5.470 - 5.725GHz, 5.725 - 5.825GHz

• 5G Wi-Fi transmitter power: <20dBm (EIRP)

• 5G Wi-Fi modulation: OFDM, BPSK, QPSK, 16QAM,

64QAM, 256QAM

• 5G Wi-Fi network compatibility: IEEE 802.11 n/ac

Quick Start Guide

Guide de démarrage rapide

PLAYLIST 150

• Bluetooth version: 4.1

• Support: A2DP V1.2, AVRCP V1.0

• Transducer: 2 x 50mm

• Rated Power: 2 x 15W

•Frequency Response: 60 – 20KHz

• Maximum SPL: 92dB

• Power supply: 19VDC, 2.0A

• Power consumption in sleep mode: <2.0 Watts

• Dimension: 316 x 131 x 147 mm

• Weight: 1200g

• Bluetooth transmitter power: <4 dBm

• Bluetooth transmitter frequency range: 2.402 – 2.480 GHz

• Bluetooth transmitter modulation: GFSK, π/4 DQPSK, 8DPSK

• 2.4G Wi-Fi Transmitter frequency range: 2.412 – 2.472 GHz

(2.4GHz ISM band, USA 11 channels, Europe and others 13 channels)

• Weight: 16.3kg

• 2.4G Wi-Fi transmitter power: <20dBm (EIRP)

• 2.4G Wi-Fi modulation: OFDM, DSSS, DBPSK, DQPSK, CCK,

16QAM, 64QAM

• 2.4G Wi-Fi network compatibility: IEEE 802.11 b/g/n

• 5G Wi-Fi Transmitter frequency range: 5.15 - 5.35GHz,

5.470 - 5.725GHz, 5.725 - 5.825GHz

• 5G Wi-Fi transmitter power: <20dBm (EIRP)

• 5G Wi-Fi modulation: OFDM, BPSK, QPSK, 16QAM,

64QAM, 256QAM

• 5G Wi-Fi network compatibility: IEEE 802.11 n/ac

Quick Start Guide

Guide de démarrage rapide

PLAYLIST 150

• Bluetooth version: 4.1

• Support: A2DP V1.2, AVRCP V1.0

• Transducer: 2 x 50mm

• Rated Power: 2 x 15W

•Frequency Response: 60 – 20KHz

• Maximum SPL: 92dB

• Power supply: 19VDC, 2.0A

• Power consumption in sleep mode: <2.0 Watts

• Dimension: 316 x 131 x 147 mm

• Weight: 1200g

• Bluetooth transmitter power: <4 dBm

• Bluetooth transmitter frequency range: 2.402 – 2.480 GHz

• Bluetooth transmitter modulation: GFSK, π/4 DQPSK, 8DPSK

• 2.4G Wi-Fi Transmitter frequency range: 2.412 – 2.472 GHz

(2.4GHz ISM band, USA 11 channels, Europe and others 13 channels)

• Weight: 16.3kg

• 2.4G Wi-Fi transmitter power: <20dBm (EIRP)

• 2.4G Wi-Fi modulation: OFDM, DSSS, DBPSK, DQPSK, CCK,

16QAM, 64QAM

• 2.4G Wi-Fi network compatibility: IEEE 802.11 b/g/n

• 5G Wi-Fi Transmitter frequency range: 5.15 - 5.35GHz,

5.470 - 5.725GHz, 5.725 - 5.825GHz

• 5G Wi-Fi transmitter power: <20dBm (EIRP)

• 5G Wi-Fi modulation: OFDM, BPSK, QPSK, 16QAM,

64QAM, 256QAM

• 5G Wi-Fi network compatibility: IEEE 802.11 n/ac

Quick Start Guide

Guide de démarrage rapide

PLAYLIST 150
