Welcome to the world of recreational vehicle travel. Your purchase

of a Jayco

R.V.

allows you to enter this unique world of camping

and leisure in a grand style. Your Jayco

R.V.

has been designed

and engineered to offer you many comforts of home that

will

make

your camping experience as enjoyable as possible.

This owner's manual was prepared to assist you in understanding

the proper use and operation of various containment systems,

servicing and maintenance of component parts, and explanation of

your warranty protection. If you are a newcomer to

R.V.

travel,

you will especially appreciate the suggestions and "shop talk"

information to be found throughout this manual to help you obtain

the most pleasure from the use of your vehicle.

We have made every effort to

make

this manual as accurate as

possible

order to reflect information available at time of

publication. Products are constantly being improved and we

endeavor

upgrade our installations accordingly. You should

carefully read and understand this owner's manual which is a

supplement to various other instructions supplied

the manufac-

turers of separately warranted products.

Keep this owner's manual in your recreational vehicle for handy

reference.

Get

to know your new vehicle and how it operates. You

should carefully read and understand these instructions and

information supplied by manufacturers

separately warranted

products, since they contain important operating, safety, and

maintenance instructions.

Every effort has been

made

to provide you with a safe, dependable

product. Your vehicle complies with applicable requirements of

Federal Motor Vehicle Safety Standards, State Regulations,

Canadian Standards Associations (CSA) where applicable, and

complies with requirements of ANSI Standard A119.2, the

nationally recognized "Standard For Recreational Vehicles

installation

of Plumbing, Heating and Electrical Systems." The

Recreational Vehicle Industry Association (RVIA) and Canadian

Standards Association (CSA) periodically inspect our production

line and assist us in maintaining strict cornpIiance with installation

and safety standards for those systems. Your follow-up with

periodic safety inspections and a program of preventive mainten-

ance is important

for

the continuation of safe

and

trouble-free

operation.

Happy

Camping!

SAFETY

CONSIDERATIONS

SAFETY

IN USING

L.P.

GAS

You should check for leaks at the connections on the L.P.-gas

system soon after purchase and initial filling of E.P.-tanks, and

continued periodic checks of the system are recommended. Your

vehicle was manufactured to provide you with full access to

all

gas line connections. Leaks can be found with a soapy water

solution applied to the outside of the gas piping connections: the

soap will bubble at the leak.

DO NOT USE

FLAMIE:

LIGHTED

TCHES

TEST

FOR

LEAKS.

Usually tightening of

connections will

leaks.

not, ask your authorized dealer

service department to make the necessary repairs.

EVEN

THOUGH

THE

MANUFACTURER

AND

DEALER HAVE

ALREADY

MADE TESTS

FOR

LEAKAGE, THIS

CHECK

ADVlSABLE

BECAUSE

THE

VIBRATION

ENCOUNTERED

DURING

TRAVEL.

E.P.-gas is heavier than air. Leaking

gas

tends to flow to low

places.

will

sometimes pocket in

low area. L.P.-gas can

usually be detected by an identifiable odor similar

onions or

garlic. Never light

match or allow any open

flame

in the

presence

leaking gas.

very important to have L.P.-gas shut off during refueling of

tow

vehicles. Some states prohibit gas appliances to be operated

during

travel, especially in any underground tunnels.

Never allow gas containers to be filled above the liquid capacity

indicated on the container.

a container is overfilled, liquid gas

may flow through the regulator causing it to freeze and/or

introduce a dangerous excessive gas pressure into the lines. In

addition, an overfilled container placed in hot sunlight

may

expel

excess gas through the relief valve and be susceptible to ignition

any nearby open flame.

ELECTRICAL

SYSTEM

SAFETY

Circuit breakers and fuses are installed to protect electrical circuits

from overloading. Do not make unauthorized changes to circuitry

add

on fixed appliance yourself.

you wish changes, consult

your dealer

and

he will assist you

obtaining a safe installation.

An approved power supply cord has been supplied with the

vehicle. Always use this cord for hook-up to the 120-volt source.

Note that the cord has

three pin plug, which provides proper

grounding through the third (round)pin,

Grounding is your personal protection from electrical shock. Do

not use any adapter, cheater, or extension cord that will break the

continuity of the grounding circuit connected to that third pin.

NEVER

remove the grounding pin

for

convenience

being able to

connectto

non-ground (only2-prong) receptacle.

Check

the

polarity

your power source.

SAFETY

WHEN

EMERGENCY

STOPPING

Always carry road flares and/or reflective triangular highway

warning devices to be displayed when necessary. Pull

off

the

roadway as far as possible when changing fiats or for other

emergency situations. Turn on your vehicular hazard warning

flashers when parked alongside a roadway, if only

for

a minute or

two.

ADDITIONAL SAFETY CONSIDERATIONS

Sanitize the fresh water supply system periodically (see

saniti~inginstructions).

Keep water connection fittings from coning

contact with the

ground or drain hose to reduce chance of contamination.

Enlist services of

qualified technician to

fix

gas or electrical

appliances.

Al~ayshave a serviceable fire extinguisher placed in an easily

accessible

location.

Piease read carefully the loading section under Chapter

If1

related to your respective trailer.

Insure that tires are in good condition and properly inflated.

Watch inflation especiaily closely

under-inflated tires

wiH

overheat. Overheated tires are

potential hazard as they may

throw rubber and cause a blowout.

Check and tighten wheel lugs regularly (every

miles when

new until

200

miles are reached and then check

lugs

every

500

miles).

Check brakes in a safe area

not while traveling a busy

highway.

Use seat belts (motor homes) at all times.

10.

Disconnect television power cord and antenna lead-in

during

local thunderstorms and lightning activity.

11.

Always solidly block trailer wheels before unhitching.

12.

Before leaving a camp area with a traiier in tow, insure that

the safety pin or locking lever is seated, breakaway wire

attached to tow vehicle,

the

jack

is raised so that

cannot

touch theground, the

dolly

wheel removed,

110-volt

electrical

cord

properly stored, safety

chains

are

connected, andall interior

lights

off.

13.

Observe

the warning labels attached to your vehicle concerning

L.P.-gas,

water, electricity, and loading.

14.

Observe the maintenance

chart

Chapter

related to your

respective unit.

Tabla de contenidos

Otros manuales de Autocaravana de Jayco

Jayco

Jayco WHITE HAWK TOWABLES 2022 Manual de usuario

Jayco

Jayco Cardinal Manual de usuario

Jayco

Jayco Jay Feather 2005 Manual de usuario

Jayco

Jayco MELBOURNE Manual de usuario

Jayco

Jayco SWIFT 2023 Manual de usuario

Jayco

Jayco JAY FLIGHT BUNGALOW Towables 2021 Manual de usuario

Jayco

Jayco SENECA Manual de usuario

Jayco

Jayco JAY FLIGHT BUNGALOW 2010 Manual de usuario

Jayco

Jayco Greyhawk 2015 Manual de usuario

Jayco

Jayco Legacy Fifth Wheel 2009 Manual de usuario

Jayco

Jayco JAY FLIGHT 2023 Manual de usuario

Jayco

Jayco Conventional Travel Trailer 2004 Manual de usuario

Jayco

Jayco Granite Ridge Greyhawk Escapade 2005 Manual de usuario

Jayco

Jayco Cardinal 8 Manual de usuario

Jayco

Jayco 2015 Jay Flight Bungalow Manual de usuario

Jayco

Jayco 2016 Melbourne Manual de usuario

Jayco

Jayco 2011 pinnacle Manual de usuario

Jayco

Jayco 2016 ALANTE Manual de usuario

Jayco

Jayco Melbourne 2011 Manual de usuario

Jayco

Jayco ALANTE 2023 Manual de usuario

Jayco

Jayco 2004 Talon ZX Manual de usuario

Jayco

Jayco JAY FEATHER Towables 2020 Manual de usuario

Jayco

Jayco JAY FLIGHT BUNGALOW 2023 Manual de usuario

Jayco

Jayco Eagle 264 BH Manual de usuario

Manuales populares de Autocaravana de otras marcas

Possl

Possl D-Line 2011 Manual de usuario

Itasca

Itasca spirit Manual de usuario

carado

carado BANFF 2018 Manual de usuario

Airstream

Airstream 1980 Argosy Manual de usuario

GBM

GBM 1994 Pursuit Manual de usuario

Itasca

Itasca Meridian 2005 Manual de usuario

Fleetwood

Fleetwood 1999 Discovery Guía de inicio rápido

Bush Palace

Bush Palace STARCRAFT TOO Manual de usuario

Fleetwood

Fleetwood Jamboree Searcher 1993 Manual de usuario

Winnebago

Winnebago Journey Manual de usuario

Tiffin Motorhomes

Tiffin Motorhomes 2017 Allegro Breeze Manual de usuario

Winnebago

Winnebago 2009 Spirit Manual de usuario

Lunar Caravans

Lunar Caravans Venus Manual de usuario

Triple E

Triple E Free Spirit 2012 Manual de usuario

Winnebago

Winnebago 2014 Adventurer Manual de usuario

NewMar

NewMar Dutch Star 1999 Manual de usuario

Winnebago

Winnebago 1996 Brave Manual de usuario

Taxa Outdoors

Taxa Outdoors Mantis Manual de usuario
