Jacobsen LDEA130 Manual de usuario

Mastiff 91

RJ 100 / 02 2005

24481G-NL (rev.3)

Series:BY & CJ - Engine type: Honda GH 280

Product codes: LDEA130 & LDEA140

WAARSCHUWING: Bij verkeerd gebruik kan deze machine

ernstiglichamelijkletselveroorzaken.Degenendiedemachine

gebruiken en onderhouden moeten worden getraind in het

juiste gebruik ervan, worden gewaarschuwd voor de

gevaren ervan en behoren de volledige handleiding

aandachtig te lezen alvorens de machine bedrijfs-klaar te

maken, te bedienen, af te stellen en/of te onderhouden.

WARNING:If incorrectly usedthis machine cancause severe

injury. Those who use and maintain this machine should be

trained in its proper use, warned of its dangers and should

read the entire manual before attempting to set up, operate,

adjust or service the machine.

Safety and Operation / Maintenance and Parts Manual

Veiligheids-, Bedienings-, Onderhouds- en Onderdelenhandleiding

GB-1

RANSOMES MASTIFF 91

SAFETY, OPERATORS, MAINTENANCE AND PARTS MANUA

Contents

CONTENTS PAGE

IMPORTANT 2

SPARES STOCKING GUIDE 3

PRODUCT IDENTIFICATION 4

HOW TO USE THE PARTS MANUAL 5

SAFETY INSTRUCTIONS 6

SPECIFICATIONS 9

EC DECLARATION OF CONFORMITY 10

CONTROLS 12

OPERATION OF THE MACHINE 14

LUBRICATION 18

MAINTENANCE 21

ADJUSTMENTS 23

ACCESSORIES 27

STORAGE 28

GENERAL ADVICE 28

CORRECTION OF MINOR FAULTS 29

ELECTRICAL SYSTEM 30

GUARANTEE 32

GB-2

RANSOMES MASTIFF 91

SAFETY, OPERATORS, MAINTENANCE AND PARTS MANUA

IMPORTANT

IMPORTANT: This is a precision machine and the service obtained from it depends on the way it is

operated and maintained.

This operators manual should be regarded as part of the machine. Suppliers of both new and

second-hand machines are advised to retain documentary evidence that this manual was provided

with the machine.

This machine is designed solely for use in customary grass cutting operations. Use in any other

way is considered as contrary to the intended use. Compliance with and strict adherence to the

conditions of operation, service and repair as specified by the manufacturer, also constitute

essential elements of the intended use.

Before attempting to operate this machine, ALL operators MUST read through this manual and

make themselves thoroughly conversant with Safety Instructions, controls, lubrication and

maintenance.

Accident prevention regulations, all other generally recognized regulations on safety and

occupational medicine, and all road traffic regulations shall be observed at all times.

Any arbitrary modifications carried out on this machine may relieve the manufacturer of liability for

any resulting damage or injury.

Use of other than original or authorised Textron Turf Care & Specialty Products Spare Parts &

Accessories will void the warranty.

GB-3

RANSOMES MASTIFF 91

SAFETY, OPERATORS, MAINTENANCE AND PARTS MANUA

straPecivreS

airetaMtroppuSecivreS

rebmuNtraPnoitpircseDrebmuNtraPnoitpircseD

06134-45421renaelCriAA/N straPenignE launaM

D9562BBMk6rednilyCgnittuC1-1198-1512E srenwOenignE koobdnaH

8822FBMk9rednilyCgnittuC01900-79879 pohSkroWenignE launaM

A0107ABMedalBmottoB

SPARES STOCKING GUIDE

To keep your equipment fully operational and productive, Ransomes suggests you maintain a stock of the

more commonly used maintenance items. We have included part numbers for the additional support

materials and training aids.

GB-4

RANSOMES MASTIFF 91

SAFETY, OPERATORS, MAINTENANCE AND PARTS MANUA

A Machine Name

B Serial Number

C Year of Manufacture

D Machine Weight

E Engine Power

Fig.1

PRODUCT IDENTIFICATION

GB-5

RANSOMES MASTIFF 91

SAFETY, OPERATORS, MAINTENANCE AND PARTS MANUA

HOW TO USE THE PARTS MANUAL

ITEM NUMBER

Each part which is identified in the illustrations has an item number. Parts which do not have an item number may not be

readily identified in the illustration but are usually closely associated with the immediately adjacent part.

ASSEMBLIES

A complete assembly, e.g. a wheel motor or hydraulic motor or roll assembly, is listed as a complete item with subsequent

individual components listed separately.

The assembly is listed under it's part number with component parts being listed offset to the right, e.g:-

ITEM RANSOMES DESCRIPTION QTY REMARKS

PART NO.

4295 MBG2504 BRACKET 1

4296 MBG3848 LATCH 2

4298 450865 SCREW, M8 x 20, SCKT CSK HD 2

4300 450378 NUT, M8 NYLOC 2

4301 Wl001 Set Of Wheels 1

4301.1 008162130 • Wheel & Hub Assy 1 (Rear)

4301.2 008170390 • • Tyre 1

4301.3 008161830 • • Rim 1

4301.4 008169140 • • Hub Assy. 1

4301.5 008169150 • • Cap 1

4301.6 002993010 • • Lubricator 1

4301.7 008161990 • Wheel & Tyre 2 (Front)

4301.8 008170780 • • Tyre 2

4301.9 008161250 • • Rim 2

4302 001341110 Wheel Nut 12

It may not be possible to illustrate every item. With certain items purchased from outside suppliers some component parts

may not be available from Ransomes and may need to be specially ordered from the supplier.

QUANTITIES

Quantities shown are for one assembly or sub-assembly.

USING THE PARTS LIST

Determine the function and application of the part required. Turn to the main index page and select the appropriate

section. Locate the part on the illustration and parts list and read off the quantity from the appropriate MODEL column.

NUMERICAL INDEX

This is a summary of all part numbers used in the manual arranged in numerical sequence and showing the page and

item number under which the parts appear.

ORDERING OF SPARE PARTS

When ordering replacement parts, it is most important to quote the SERIAL NUMBER of the machine, PART NUMBER,

DESCRIPTION and QUANTITY required.

Any arbitrary modifications carried out on this machine may relieve the manufacturer of liability for any

resulting damage or injury.

Use of other than original or authorised Textron Turf Care & Specialty Products Spare Parts will void

the warranty.

ABBREVIATIONS

N/A Not Available

AR As Required

GB-6

RANSOMES MASTIFF 91

SAFETY, OPERATORS, MAINTENANCE AND PARTS MANUA

This safety symbol indicates important safety

messages in this manual. When you see this

symbol, be alert to the possibility of injury, carefully

read the message that follows, and inform other

operators.

SAFETY INSTRUCTIONS

OPERATING INSTRUCTIONS

Ensure that the instructions in this book are read

and fully understood.

No person should be allowed to operate this

machine unless they are fully acquainted with all

the controls and the safety procedures.

Never allow children or people unfamiliar with

these instructions to use this machine. Local

regulations may restrict the age of the operator.

SAFETY SIGNS

It is essential all safety labels are kept legible, if

they are missing or illegible they must be replaced.

If any part of the machine is replaced and it

originally carried a safety label, a new label must

be affixed to the replacement part. New safety

labels are obtainable from Ransomes dealers.

STARTING THE ENGINE

Before starting the engine check that the drives

are in neutral, guards are in position and intact,

and bystanders are clear of the machine. Do not

run the engine in a building without adequate

ventilation.

DRIVING THE MACHINE

Before moving the machine, check to ensure that

all parts are in good working order, paying

particular attention to the security of cutting blades.

Replace faulty silencers. Mow only in daylight or

good artificial light.

Always observe the Highway Code both on and off

the roads. Keep alert and aware at all times.

Remember that some people are deaf or blind and

that children and animals can be unpredictable.

Watch out for traffic when crossing or near

roadways.

Stop the blades rotating before crossing surfaces

other than grass.

Remove or avoid obstructions in the area to be

cut, thus reducing the possibility of injury to

yourself and/or bystanders. When moving the

machine backwards, take special care to ensure

that the area behind is clear of obstructions and/or

bystanders.

After striking a foreign object, inspect the machine

for damage and make repairs before restarting and

operating the equipment. If the machine starts to

vibrate abnormally, check immediately.

DO NOT carry passengers.

Keep in mind that the operator or user is

responsible for accidents or hazards occurring to

other people or their property.

While mowing, always wear substantial footwear

and long trousers. Do not operate the equipment

when barefoot or wearing open sandals.

GB-7

RANSOMES MASTIFF 91

SAFETY, OPERATORS, MAINTENANCE AND PARTS MANUA

TRANSPORTING

Do not transport with cutting mechanism rotating.

Operate the machine with due consideration of

road and surface conditions, inclines and local

undulations.

LEAVING THE OPERATING POSITION

Park the machine on level ground. Before leaving

the operating position, stop the engine and make

sure all moving parts are stationary. Disengage all

drives. When the machine is to be parked, stored

or left unattended, lower the cutting units unless

the transport locks are being used.

SLOPES

TAKE EXTRA CARE WHEN WORKING ON

SLOPES

Local undulations and sinkage will change the

general slope. Avoid ground conditions which can

cause the machine to slide. Keep machine speeds

low on slopes and during tight turns.

Ratchet driven machines free-wheel on downhill

slopes. Remember there is no such thing as a

"safe" slope. Travel on grass slopes requires

particular care, to guard against overturning.

BLOCKED CUTTING CYLINDER

Stop the engine and make sure all moving parts

are stationary. Apply brakes and disengage all

drives.

Release blockages with care. Keep all parts of the

body away from the cutting edge. Beware of

energy in the drive which can cause rotation when

the blockage is released.

Keep other people away from the cutting unit.

ADJUSTMENTS, LUBRICATION AND

MAINTENANCE

Read all the appropriate servicing instructions. Use

only the replacement parts supplied by the original

manufacturer.

When adjusting the cutting cylinders take care not

to get hands and feet trapped when rotating

cylinder. Make sure that other people are not

touching the cutting unit.

To reduce the fire hazard, keep the engine,

silencer and battery free of grass, leaves or

excessive grease. Replace worn or damaged

parts for safety.

When working underneath lifted parts or machines,

make sure adequate support is provided.

Do not dismantle the machine without releasing or

restraining forces which can cause parts to move

suddenly.

Do not alter engine speed above maximum quoted

in Engine Specification. Operating the engine at

excessive speed may increase the hazard of

personal injury.

GB-8

RANSOMES MASTIFF 91

SAFETY, OPERATORS, MAINTENANCE AND PARTS MANUA

When refuelling, STOP THE ENGINE, DO NOT

SMOKE. Refuel outdoors only. Add fuel before

starting the engine, never add fuel while the

engine is running. Use a funnel when pouring fuel

from a can into the tank. Do not spill fuel onto hot

components. If petrol is spilled, do not attempt to

start the engine but move the machine away from

the area of spillage and avoid creating any source

of ignition until petrol vapours have dissipated. If

the fuel tank has to be drained, this should be

done outdoors. DO NOT fill the fuel tank beyond

the bottom of the filler neck. Replace all fuel tank

and container caps securely. Store fuel in

containers specifically designed for this purpose.

When servicing batteries, DO NOT SMOKE, and

keep naked lights away. Do not place any metal

objects across the terminals. Allow the engine to

cool before storing in any enclosure. Never store

equipment with petrol in the tank inside a building

where fumes may reach an open flame or spark.

WHEN USING ON LOADING

RAMPS OR ON UNDULATING

GROUND ALWAYS ENSURE THAT

THE HANDLE IS ADJUSTED TO

GIVE ADEQUATE CLEARANCE

ABOVE THE LEGS. FAILURE TO

DO THIS COULD RESULT IN A

SITUATION WHERE THE

OPERATORS LEGS COME INTO

CAUTION

BATTERIES PRODUCE

EXPLOSIVE GASES AND

CONTAIN CORROSIVE ACID AND

SUPPLY LEVELS OF ELECTRICAL

WARNING

CALIFORNIA PROPOSITION 65

ENGINE EXHAUST, SOME OF ITS

CONSTITUENTS, AND CERTAIN

VEHICLE COMPONENTS

CONTAIN OR EMIT CHEMICALS

KNOWN TO THE STATE OF

CALIFORNIA TO CAUSE CANCER

AND BIRTH DEFECTS OR OTHER

WARNING

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de Cortacésped de Jacobsen

Jacobsen

Jacobsen Turfcat II DW 224 Instrucciones de instalación y mantenimiento

Jacobsen

Jacobsen Super LF 1880 Fairway 67923 Manual de usuario

Jacobsen

Jacobsen ransomes hr3806 Guía

Jacobsen

Jacobsen 62282 Manual de usuario

Jacobsen

Jacobsen Turfcat II DW 220 Instrucciones de instalación y mantenimiento

Jacobsen

Jacobsen LF 4677 Manual de usuario

Jacobsen

Jacobsen Tri King 67069 Manual de usuario

Jacobsen

Jacobsen 67978 - LF 550 Guía

Jacobsen

Jacobsen R-311 ROPS Manual de usuario

Jacobsen

Jacobsen G-Plex III Guía

Jacobsen

Jacobsen Turfcat 500 T523D 2WD Guía

Jacobsen

Jacobsen Greens King IV Plus Guía

Jacobsen

Jacobsen HR800 Guía

Jacobsen

Jacobsen HR 9016 Turbo 70538 Manual de usuario

Jacobsen

Jacobsen 63281 Manual de usuario

Jacobsen

Jacobsen HF-5 Guía de instalación

Jacobsen

Jacobsen R-311 Manual de usuario

Jacobsen

Jacobsen AR-522 jossa ROPS Manual de usuario

Jacobsen

Jacobsen Greens King IV Plus Manual de usuario

Jacobsen

Jacobsen HR 9016 Turbo Manual de usuario

Jacobsen

Jacobsen ECLIPSE 360 Guía

Jacobsen

Jacobsen T422D Turfcat Manual de usuario

Jacobsen

Jacobsen 67945 Manual de usuario

Jacobsen

Jacobsen E-Walk 62290 Manual de usuario

Manuales populares de Cortacésped de otras marcas

RHINO

RHINO 1958 Manual de usuario

Wolf Garten

Wolf Garten Compact plus 40 B Manual de usuario

Cub Cadet

Cub Cadet LTX 1045 Manual de usuario

Craftsman

Craftsman 917.378461 Manual de usuario

GGP ITALY SPA

GGP ITALY SPA CR/CS 434 SERIES Manual de usuario

Challenge

Challenge CH18V2 Instrucciones de operación

TALEN TOOLS

TALEN TOOLS AVR HGM30 Manual de usuario

DEWEZE

DEWEZE ATM-725 Manual de operación

Weed Eater

Weed Eater 180083 Manual de usuario

Husqvarna

Husqvarna Poulan Pro PP185A42 Manual de usuario

Better Outdoor Products

Better Outdoor Products Quick Series Manual de usuario

Cub Cadet

Cub Cadet 23HP Z-Force 60 Manual de funcionamiento

MTD

MTD 795, 792, 791, 790 Manual de usuario

Toro

Toro Groundsmaster 3505-D Manual de usuario

Dennis

Dennis FT 610 Manual de usuario

AIRFORCE

AIRFORCE F-15 Gen 3 Manual de usuario

MTD

MTD 126-220-000 Manual de usuario

Toro

Toro 74806 Manual de usuario
