Jabra SPEAK 510 Manual de usuario
jabra.com/speak510
User Manual
JABRA SPEAK 510™
© 2013 GN Netcom A/S. All rights reserved. Jabra®is a registered
trademark of GN Netcom A/S. All other trademarks included herein
are the property of their respective owners. The Bluetooth®word
mark and logos are owned by the Bluetooth SIG, Inc. and any use
of such marks by GN Netcom A/S is under license. (Design and
specifications subject to change without notice).
Declaration of Conformity can be found on
www.jabra.com/CP/US/declarations-of-conformity
Made in China
MODEL: JABRA SPEAK 510
3
english
CONTENTS
1. WELCOME.......................................... 4
2. SPEAKER OVERVIEW......................... 5
2.1 TURN ON THE JABRA SPEAK 510
2.2 CHARGING THE JABRA SPEAK 510
3. CONNECTING .................................... 7
3.1 CONNECT TO JABRA LINK 360
3.2 CONNECT TO MOBILE DEVICE BLUETOOTH
3.3 CONNECT TO BLUETOOTH HEADSET
3.4 CONNECT TO CORDED HEADSET
4. HOW TO USE THE JABRA SPEAK
510....................................................12
4.1 MULTIPLE CALL HANDLING
4.2 SWITCH BETWEEN BLUETOOTH DEVICES
4.3 VOICE GUIDANCE ON/OFF
4.4 VOICE GUIDANCE
5. SOFTWARE .......................................16
5.1 JABRA PC SUITE
5.2 UPDATE JABRA SPEAK 510 FIRMWARE
6. SUPPORT..........................................17
6.1 FAQ
6.2 HOW TO CARE FOR YOUR JABRA SPEAK 510
7. TECHNICAL SPECIFICATIONS ...........19
4
english
1. WELCOME
Thank you for purchasing the Jabra Speak 510. We
hope you will enjoy it!
JABRA SPEAK 510 FEATURES
Answer, end, reject and mute calls.
Connect to PC via USB or Jabra Link 360.
Connect wirelessly to mobile device via
Bluetooth.
Portable.
Omni-directional microphone.
Wideband audio for exceptional sound quality.
LED, audio indicators and voice guidance.
5
english
2. SPEAKER OVERVIEW
On/Off
Answer call
Volume
down
Bluetooth
USB cable
Headset port
End/reject call
Volume up
Battery level
Mute microphone
Supplied with
Jabra Speak 510+ only
Jabra Link 360
6
english
2.1 TURN ON THE JABRA SPEAK 510
Plug the Jabra Speak 510 USB cable into any
available USB port on your PC, or
Press and hold (2 secs) the On/Off button to turn
the Jabra Speak 510 on or off.
2.2 CHARGING THE JABRA SPEAK 510
Plug the Jabra Speak 510 USB cable into any
available USB port on your PC to charge the battery.
The battery light is red when charging, and green
for 1 minute when fully charged.
7
english
3. CONNECTING
1. Plug the Jabra Speak 510 USB cable into any
available USB port on your PC.
2. Select the Jabra Speak 510 as the default audio
device in Windows Control Panel sound settings,
and in your softphone audio settings.
8
english
3.1 CONNECT TO JABRA LINK 360
The speakerphone and Jabra Link 360 are pre-
paired and ready to use out of the box (Jabra speak
510+ only).
TO CONNECT THE SPEAKER AND JABRA LINK 360:
1. Press and hold (2 secs) the Bluetooth button on
the Jabra Speak 510 until the Bluetooth light
flashes blue. Release the button when you hear
the connection instructions.
2. Plug the Jabra Link 360 into any available USB
port on your PC.
3. The connection is established when the light
turns solid blue.
NOTE: Ensure that all Bluetooth devices previously connected to
the Jabra Link 360 are switched off.
9
english
3.2 CONNECT TO MOBILE DEVICE
BLUETOOTH
1. Press and hold (2 secs) the Bluetooth button on
the Jabra Speak 510 until the Bluetooth light
flashes blue. Release the button when you hear
the connection instructions.
2. Enable Bluetooth on your mobile device, and
select the Jabra Speak 510 from the list of
available Bluetooth devices. If prompted for a
password enter 0000.
10
english
3.3 CONNECT TO BLUETOOTH HEADSET
For privacy, a bluetooth headset can be connected
to the Jabra Speak 510.
1. Plug the Jabra Speak 510 into any available USB
port on your PC.
2. Put the Bluetooth headset into pairing mode
(refer to your headset manual for instructions).
3. Press and hold (8 secs) the Bluetooth button on
the Jabra Speak 510 until the Bluetooth light
flashes blue and then flashes green. Release the
button when you hear ‘Connect to headset’.
4. The connection is established when the light
turns solid blue.
