Jabra SoleMate Mini Hoja de especificaciones

81-03849 B

ASIA PACIFIC

Australia

China

Japan

New Zealand

Singapore

PHONE

1-800-738-521

800-858-0789

03-3242-8722

+64 92806301

+65-62214729

[email protected]

support.cn@jabra.com

[email protected]

NEED MORE HELP?

Why wait? Go to our support page and find all the answers you’re looking

for 24-hours a day. www.jabra.com/solematemini

Contact details to Jabra Support:

jabra.com/solematemini

JABRA SOLEMATE MINI

GET STARTED IN UNDER

MINUTES

Declaration of Conformity can be found on

www.jabra.com/CP/US/declarations-of-conformity

MADE IN CHINA

MODEL: HFS210

rights reserved. Jabra®is a registered trademark of GN Netcom A/S. All

other trademarks included herein are the property of their respective

owners. The Bluetooth®word mark and logos are owned by the Blue-

tooth SIG, Inc. and any use of such marks by GN Netcom A/S is under

license. (Design and specifications subject to change without notice).

外

箱・中箱外箱・袋

MSIP-CMM-

GNM-HFS210

ENGLISH..........................................1

简体中文.........................................5

繁體中文.........................................9

日本語 ............................................13

ภาษาไทย.......................................17

BAHASA MALAYSIA..................21

한국어............................................25

. . .

1 CONNECT

Connect to just about anything on the

planet (no exaggeration).

Bluetooth®

Almost everything has Bluetooth!

1. Press and hold (4 secs) the Answer/End

button until pairing mode is announced,

and the Bluetooth light ashes. Release

the button.

2. Follow the voice-guided pairing

instructions.

3.5 mm Jack Connector

Does your music device or PC have

somewhere to plug in headphones? Good.

Connect quickly and easily to it.

NFC

Connect with a simple touch.

1. Ensure that NFC is enabled on your mobile

device.

2. Locate and gently tap the NFC zone on the

mobile device against the NFC zone on the

Jabra Solemate Mini.

ENGLISH

NFC zone

2 DISCOVER

DID YOU KNOW?

The Solemate Mini's sole keeps it from bouncing around when you blast

your music!

NFC

USB charging

port

Microphone

3.5 mm

jack connector

On/O

NFC zone

Volume up

Volume down

3.5 mm audio cable

(under the sole)

Answer/End

(battery status)

FUNCTION ACTION

Speaker volume Tap the Volume up or Volume down button

Answer/end call Tap the Answer/End button

Reject call Double-tap the Answer/End button

Redial last number Double-tap the Answer/End button

Battery status Tap the Answer/End button when not on a call to

hear the battery status

Mute/un-mute

microphone

Press and hold (1 sec) the Volume up and Volume

down buttons at the same time

To charge: connect the supplied USB cable to your phone's USB charger, or connect

to your PC. It takes approx. 3 hours to fully charge.

. . .

1连接

几乎可连接地球上的任何设备（毫不夸

张）。

蓝牙

几乎所有设备都有蓝牙！

1. 按住接听/挂断按钮 4 秒钟，直至听到

进入配对模式的提示并且蓝牙指示灯闪

烁为止。然后松开按钮。

2. 按语音提示的配对说明操作。

3.5 毫米插孔连接器

您的音乐设备或电脑有耳机孔吗？很好。

快点连接到这个耳机孔吧。

NFC

简体中文

NFC 近场通信

触碰一下便可连接。

1. 确保在您的移动设备上开启 NFC 近场通

信功能。

2. 找到并用移动设备上的 NFC 近场通信感应

区轻轻触碰 Jabra Solemate Mini 捷波朗

魔音盒迷你上的 NFC 近场通信感应区。

NFC 近场通信

感应区
