Jabra GN1200 Manual de usuario

Simple connectivity.

Greater convenience.

JABRA GN1200

JABRA®IS A REGISTERED TRADEMARK OF GN NETCOM A/S

WWW.JABRA.CO.UK

The Jabra GN1200 cord is the solution to a common problem

of not being able to connect the headset and telephone.

Even though most things have been standardised, the cord

connecting the phone with the handset or headset is anything

but standard as each telephone manufacturer has its own

wiring code. Now, with the universal “smart” cord, Jabra

GN1200, the cord will work with virtually any phone providing

greater convenience.

Works with most desk phones including IP hard phones

Microphone ampliﬁcation to boost transmit levels when

connecting to low transmit volume phone systems

Simple slide adjustment for easy setup

When hooking up a new headset there is not always a dial

tone. The problem could be the headset or the telephone.

But chances are it is the cord. Even though the headset and

telephone may be plug-compatible, the wiring is determined by

the individual telephone manufacturer.

Jabra GN1200 features eight separate wiring schemes –

including three with built-in microphone ampliﬁcation. Just

connect the Jabra GN1200 and headset through the Quick

Disconnect plug and ﬂick the slider from one position to the

next until a dial tone is heard. It’s as simple as that!

Available in both straight and coiled versions, the Jabra GN1200

ﬁts virtually all telephones featuring a standard RJ9 modular

connection.

DATASHEET

Jabra GN1200

JABRA GN1200

Jabra GN1200

Features BeneFits

Simple 8-position slide adjustment No need for a user manual; simply slide until a dial tone is heard

Standard RJ9 connector Connects to virtually all telephones using a standard modular plug

Standard GN Quick Disconnect plug to headset Works with any GN headset equipped with a Quick Disconnect plug

Straight 80 cm cord or

200cm lightweight coiled cord

Longer than many standard cords, yet at a competitive price

Built-in low-current microphone ampliﬁer Enables perfect operation with telephones that require extra signal gain such as Cisco,

Panasonic, Nortel and Avaya, plus many IP telephones

JaBra Gn1200

switch position

MatchinG telephone systeM Mod pluG wirinG aMpliFied

Microphone

equivalent

Gn caBle

1 Standard (most common) M-, R, R, M+ No 8800-00-01

2 Cisco IP phones 79xx series R, M-, M+, R No 8800-00-37

3 Ascom ofﬁce and Philips phones R, M+, M-, R No 8800-00-03

4 Japanese phones, NEC, Nitsuko M+, R, R, M- No 8800-00-25

5 Plantronics Vista Base R, R, M+, M- No 8800-00-20

6 Panasonic phones with modular plug M+, R, R, M- Yes 8800-00-25A

7 Nortel digital phones and Avaya IP phones M-, R, R, M+ Yes 8800-00-01A

8 Avaya Callmaster V and VI, Cisco IP phones

79xx series

R, M-, M+, R Yes 8800-00-37A

the eiGht switch positions and correspondinG telephone systeMs

dc voltaGe

Maximum Voltage 10v DC

Minimum Voltage 1.6v DC

Nominal Voltage 5v DC

Maximum Current 2.5 mA

Minimum Current 280 uA

electrical speciFications

characteristics

AC Output Voltage 30mV

(preamp on i.e. positions 6-8)

Insertion Gain 11.5dB Nom Min 10.5dB : Max 12.5dB

Bias Voltage : 1.58v DC Nom , Min 1.53v DC : Max 1.76v DC

(preamp output i.e. positions 6-8)

Bias Voltage 1.49v DC Nom, Min 1.38v DC : Max 1.71v DC

(microphone input)

FeatUreS & BeneFitS
