Jabra Evolve 65 Hoja de especificaciones

81-03922 B

GET STARTED IN UNDER

NEED MORE HELP?

For all support go to jabra.com/support

jabra.com/evolve65

QUICK START

DOWNLOADS

CONTACT SUPPORTTROUBLESHOOTING

FAQ

VIDEOS

1-2-3

jabra.com/evolve65

JABRA EVOLVE 65

GET STARTED IN UNDER

MINUTES

www.jabra.com

reserved. Jabra®is a registered trademark of GN Netcom A/S. All other

trademarks included herein are the property of their respective owners.

The Bluetooth®word mark and logos are owned by the Bluetooth SIG, Inc.

and any use of such marks by GN Netcom A/S is under license. (Design

and specifications subject to change without notice).

MADE IN CHINA

MODEL: HSC018W

FCC ID: BCE-HSC018W

IC: 2386C-HSC018W

ENGLISH..................................... 1

简体中文.................................... 5

繁體中文.................................... 9

ČESKY........................................13

DANSK/SVENSKA..................17

NEDERLANDS.........................21

FRANÇAIS................................25

FRANÇAIS................................29

DEUTSCH.................................33

ITALIANO .................................37

日本語 .......................................41

한국어.......................................45

POLSKI ......................................49

PORTUGUÊS ...........................53

PORTUGUÊS ...........................57

РУССКИЙ.................................61

ESPAÑOL..................................65

ESPAÑOL..................................69

TÜRKÇE.....................................73

1 HOW TO CONNECT

CONNECT TO PC (USING JABRA LINK 360)

Plug the Jabra Link 360 dongle into a USB

port on your PC. The headset and the

Jabra Link 360 are already pre-paired.

CONNECT TO MOBILE DEVICE (USING

BLUETOOTH)

Hold (3 secs) the On/o/pairing switch in

the pairing position until the Bluetooth

indicator ashes blue and you hear the

voice-guided pairing instructions.

CONNECT TO PC (USING USB CABLE)

Plug the headset into any USB port on

the PC using the supplied USB cable, and

ensure the headset is switched on.

ENGLISH

2 HOW TO WEAR

POSITION THE MICROPHONE

It is recommended to position the

microphone boom-arm close to your

mouth. The microphone boom-arm is

bendable for personal preference.

OUTDOOR USE

When listening to music or when

outdoors, the microphone boom-arm

can be stored in the headband groove.

3 HOW TO USE

DID YOU KNOW?

You can download the full user manual from jabra.com/evolve65

Busylight indicator

Battery

indicator

Bluetooth

indicator USB/charging port

On/o/pairing

switch

Microphone

boom-arm

Volume up

Volume down

Answer/end button

FUNCTION ACTION

Headset on/o Slide the On/o/pairing switch

Headset pairing

mode

Hold (3 secs) the On/o/pairing

switch in the pairing position

Answer/end call Tap the Answer/end button

Reject call Double-tap the Answer/end button

Adjust speaker

volume

Tap the Volume up or Volume down

button

Busylight on/o Simultaneously tap the Volume up

and Volume down button

Mute/unmute call

Swivel the microphone boom-arm

all the way up (mute) or all the way

down (un-mute)

CHARGING THE HEADSET

The headset will charge when connected to a PC, or when using any USB

wall charger supplied with your mobile device.

It takes approx. 3 hours to charge.

1 如何连接

连接到电脑（通过 JABRA LINK 360）

将Jabra Link 360 适配器插入电脑上的

USB 端口。耳机和 Jabra Link 360 已经预

先配对。

连接到移动设备（通过蓝牙功能）

按住配对位置的开启/关闭/配对开关 3 秒

钟，直至蓝牙指示器闪烁蓝色并且听到语

音配对指示。

连接到电脑（通过 USB 线缆）

使用随附的 USB 线缆将耳机插入任何可用

的USB 端口，并确保耳机打开。

简体中文

2 如何佩戴

放置麦克风

建议将麦克风话筒臂置于靠近口部的

位置。麦克风话筒臂可根据个人偏

好折叠。

户外使用

听音乐或在户外使用时，麦克风话筒

臂可以收在头带凹槽中。
