Jabra Brage Manual de usuario

Brage.com

User Manual

BRAGE

Brage

CONTENTS

1. WELCOME........................................3

2. OVERVIEW ...................................... 4

3. HOW TO WEAR................................5

3.1 HEIGHT ADJUSTMENT 5

3.2 FOLDABLE HINGES 6

4. HOW TO CHARGE............................7

4.1 BATTERY STATUS 7

5. HOW TO CONNECT......................... 8

5.1 CONNECT TO A BLUETOOTH DEVICE 8

5.2 CONNECT TO AN NFC DEVICE 9

5.3 CONNECT TO 3.5 MM JACK CONNECTOR 10

5.4 CONNECT TO USB 11

6. HOW TO USE ................................12

6.1 TURN HEADSET ON/OFF 15

6.2 MULTIPLE CALL HANDLING 15

6.3 VOICE GUIDANCE 16

7. SUPPORT.......................................17

7.1 FAQ 17

7.2 HOW TO CARE FOR YOUR HEADSET 18

8. TECHNICAL SPECIFICATIONS ........19

Brage

1. WELCOME

Thank you for purchasing the Brage. We hope you

will enjoy it!

BRAGE FEATURES

High definition Dolby®Digital Plus enhanced

sound via exclusive Brage Sound App.

Optimized sound excellence with portable

devices.

Turntable Touch Control for easy music and call

management.

Life proof - tough, shatterproof and constructed

for ultimate portability.

Premium comfort for extended wear: memory

foam ear cups and padded headband.

Foldable design for quick and compact storage.

Superior call quality – Noise Blackout™ with dual

mic technology.

NFC for easy pairing.

Detachable corded option for when you need to

be wired.

Connects with all Bluetooth®ready devices –

phones, computers, tablets and more.

Brage

2. OVERVIEW

OFF

Adjustable

Headband

Brage Sound APP

button

3.5mm Jack

Connector

3.5mm audio cable Micro-USB cable

Foldable Hinges

On/Off/Pairing

switch

Turntable Touch

Controls

Multi-function

button

Battery and

Connection status

lights

Multi-function

button

NFC zone

Micro-USB Port

Brage

3. HOW TO WEAR

3.1 HEIGHT ADJUSTMENT

Get the perfect fit by adjusting the headband, as

illustrated.

Brage

3.2 FOLDABLE HINGES

The headset can be folded when not in use.

Brage

4. HOW TO CHARGE

Plug the headset into any available USB port on

your PC using the micro-USB cable.

4.1 BATTERY STATUS

Tap the Multi-function button when not on a call to

see the battery status. It takes 2-4 hours to fully

charge the headset.

LED COLOR BATTERY LEVEL

Green Medium/High

Red Low

Flashing red Critically low

Brage

5. HOW TO CONNECT

5.1 CONNECT TO A BLUETOOTH DEVICE

1. Hold the On/Off/Pairing switch in the Pairing

position for 3 secs.

2. Pairing mode will be announced in the

headphones, and the Bluetooth light will flash

blue.

3. Follow the voice-guided pairing instructions to

pair to your Bluetooth device.

Brage

5.2 CONNECT TO AN NFC DEVICE

1. Turn the on (set the On/Off/Pairing switch to

the On position).

2. Hold an NFC device against the NFC zone of the

headphones (left earcup).

NFC zone

NOTE: Different NFC devices have NFC implemented in

different ways. The size and sensitivity of the NFC zone

may vary between devices.

Brage

5.3 CONNECT TO 3.5 MM JACK CONNECTOR

Connect the headset to a 3.5 mm jack connector on

your mobile device or PC using the supplied music

cable.

NOTE: Bluetooth and headset connections are disabled

when connected to the 3.5 mm Jack Connector.
