J.Burrows Suresafe Anchor Manual de usuario
Do not store emergency keys inside your safe!
123
456
789
0
#
*
8
7
6
4
5
4
DIGITAL SAFE
INSTRUCTIONS
6. Red Light
7. Yellow Light
8. Green Light
9. Confirmation button
1. Bolts
2. Reset Button
3. Battery Compartment
4. Knob (Master Key)
5. Emergency Lock Cover
s (included).
PROGRAMMING YOUR SAFE
Batteries
1. Remove the emergency cover and insert the emergency key.
2. Turn emergency key anti clockwise and hold.
3. Turn door handle clockwise and pull the door open.
4. Insert 4 x AA batteries into the battery compartment.
2. Input your new user code (3-8 digits) followed by the “#” key.
- initial entry to the safe.
- a means of access if you forget your user code.
They should not be used for everyday access.
Responsibility will not be taken if the user misplaces the emergency keys.
Store these keys in a safe place but NOT inside the safe!
INSTALLING YOUR SAFE
For installation into concrete surfaces use masonry bolts provided.
1. Install your safe in a location that is secure and sturdy.
2. Drill holes for 12mm masonry bolts in the desired location.
3. Insert the masonry bolts through the holes in the safe and into the concrete.
4. Tighten masonry bolts using a 12mm socket or spanner.
For installation into timber surfaces use coach screw
1. Install your safe in a location that is secure and sturdy.
2. Pre-drill holes in the desired location.
3. Insert the coach screws through the holes in the safe and into the timber.
4. Tighten coach screws using a socket or spanner.
All safes should be bolted down to ensure the best possible security.
OTHER NOTES
- If you wish to clean your safe, use a damp cloth. Do not use liquid or sprayers.
- Never try to dismantle the product by yourself.
- Safe must be installed in an upright position or the warranty shall be void.
Ph (03)9786 0055
Safe
Concrete
Safe
Timber
When replacing batteries in the future, it is best to use heavy duty alkaline AA batteries.
(Note: When you replace the batteries, you will also need to re-program your user code.)
Program User Code
This safe comes programmed with a preset factory code -1 5 9 . For security purposes you
will need to change this to your own personal code by following these steps:
USING YOUR SAFE
You will now be able to unlock and open your safe using your own user code.
Open Safe with User Code
1. Enter your 3-8 digit user code.
If the code is entered correctly,the Confirm Light will turn on.
3. Turn the Door Handle and open the safe.
(If the code is entered incorrectly, the Warning Light will turn on and you wil not be able to
open the safe. If the code is entered incorrectly 3 times consecutively, the safe will
automatically lock for 20 seconds. Another 3 incorrect entries consecutively, the safe will lock
for about 5 minutes.)
Emergency Key
The emergency keys are provided for:
A safe is an aid only in reducing theft, it must form only a part of a range of security
measures used. Sandleford Holdings Pty Ltd (distributor of Karbon Safes) will not
accept or be held responsible for any loss or damage caused in the event of theft or
unauthorised use.
AA AA
AA AA
AA AA
AA AA
1. Press the reset button located behind the battery cover.
A ‘beep’ will sound.
AA AA
AA AA
s (included).
PROGRAMMING YOUR SAFE
Batteries
1. Remove the emergency cover and insert the emergency key.
2. Turn emergency key anti clockwise and hold.
3. Turn door handle clockwise and pull the door open.
4. Insert 4 x AA batteries into the battery compartment.
2. Input your new user code (3-8 digits) followed by the “#” key.
- initial entry to the safe.
- a means of access if you forget your user code.
They should not be used for everyday access.
Responsibility will not be taken if the user misplaces the emergency keys.
Store these keys in a safe place but NOT inside the safe!
INSTALLING YOUR SAFE
For installation into concrete surfaces use masonry bolts provided.
1. Install your safe in a location that is secure and sturdy.
2. Drill holes for 12mm masonry bolts in the desired location.
3. Insert the masonry bolts through the holes in the safe and into the concrete.
4. Tighten masonry bolts using a 12mm socket or spanner.
For installation into timber surfaces use coach screw
1. Install your safe in a location that is secure and sturdy.
2. Pre-drill holes in the desired location.
3. Insert the coach screws through the holes in the safe and into the timber.
4. Tighten coach screws using a socket or spanner.
All safes should be bolted down to ensure the best possible security.
OTHER NOTES
- If you wish to clean your safe, use a damp cloth. Do not use liquid or sprayers.
- Never try to dismantle the product by yourself.
- Safe must be installed in an upright position or the warranty shall be void.
Ph (03)9786 0055
Safe
Concrete
Safe
Timber
When replacing batteries in the future, it is best to use heavy duty alkaline AA batteries.
(Note: When you replace the batteries, you will also need to re-program your user code.)
Program User Code
This safe comes programmed with a preset factory code -1 5 9 . For security purposes you
will need to change this to your own personal code by following these steps:
USING YOUR SAFE
You will now be able to unlock and open your safe using your own user code.
Open Safe with User Code
1. Enter your 3-8 digit user code.
If the code is entered correctly,the Confirm Light will turn on.
3. Turn the Door Handle and open the safe.
(If the code is entered incorrectly, the Warning Light will turn on and you wil not be able to
open the safe. If the code is entered incorrectly 3 times consecutively, the safe will
automatically lock for 20 seconds. Another 3 incorrect entries consecutively, the safe will lock
for about 5 minutes.)
Emergency Key
The emergency keys are provided for:
A safe is an aid only in reducing theft, it must form only a part of a range of security
measures used. Sandleford Holdings Pty Ltd (distributor of Karbon Safes) will not
accept or be held responsible for any loss or damage caused in the event of theft or
unauthorised use.
AA AA
AA AA
AA AA
AA AA
1. Press the reset button located behind the battery cover.
A ‘beep’ will sound.
AA AA
AA AA
