Iwc 5038 Manual de usuario

www.iwc.com

OPERATING INSTRUCTIONS

使用说明

使用說明

取扱説明書

PETUNJUK PENGGUNAAN

ИНСТРУКЦИЯ ПО ЭКСПЛУАТАЦИИ

КЕРІВНИЦТВО З ВИКОРИСТАННЯ

REFERENCE 5038

REF. 5038

IWE05774/01.16/0.6

BIG PILOT’S WATCH

PERPETUAL CALENDAR

GROSSE FLIEGERUHR PERPETUAL CALENDAR EDITION «LE PETIT PRINCE»

— 3 —

BIG PILOT'S WATCH PERPETUAL CALENDAR

— 5 —

OPERATING INSTRUCTIONS

English

— 21 —

使用说明

简体中文

— 35 —

使用說明

繁體中文

— 49 —

取扱説明書

日本語

— 63 —

PETUNJUK PENGGUNAAN

Bahasa Indonesia

— 79 —

ИНСТРУКЦИЯ ПО ЭКСПЛУАТАЦИИ

Русский

— 95 —

КЕРІВНИЦТВО З ВИКОРИСТАННЯ

Українська

— 5 —

BIG PILOT'S WATCH PERPETUAL CALENDAR

Welcome to the small circle of individuals who, if we are to be abso-

lutely precise, demand slightly more of a watch than absolute precision. Appreciation

of a watch is more than mere appreciation of the correct time. It is enthusiasm for an

ingenious idea. For the interplay between precision and imagination. Between time and

timelessness. Between boundaries and infinity. Between laws to which the entire world

is subject, and taste, which cannot be dictated to anyone. That is why, since 1868,

we have been devoting rather more of our time to watches that must not only run with

absolute precision but which also, with every passing second, exert a fascination with

the great achievements of master craftsmanship: afascination with new inventions of

a technical, material or formal nature, even if they are concealed in minute details that

are perhaps not even visible. You are now the owner of a beautiful new example of this

IWC tradition. We would like to congratulate you on your choice and send you our best

wishes for the time you will spend with your watch, which perhaps cannot be described

with any greater accuracy than it is here.

IWC MANAGEMENT

— 6 —

BIG PILOT'S WATCH PERPETUAL CALENDAR

THE TECHNICAL REFINEMENTS OF THE

BIG PILOT'S WATCH PERPETUAL CALENDAR

Your IWC watch shows you the time in hours, minutes and seconds, the moon phase,

the day, the date, the month and the year in four digits, as well as the remaining

power reserve. The mechanical movement with automatic winding has a power

reserve of approximately 7days (168 hours) when fully wound. Your Big Pilot’s Watch

Perpetual Calendar is protected by a convex sapphire glass of hardness grade 9

on Mohs’ scale. Your watch is water-resistant 6bar. The engraved rotor in 18-carat

gold winds the watch in both directions of rotation via the Pellaton winding system. In

addition to the uniqueness of its functions, it is the display’s legibility and the ease with

which it can be used that distinguishes this watch from other complicated timepieces.

To ensure that this extraordinary watch continues to perform faultlessly in the future, it

is essential to observe a few important operating instructions.

— 7 —

BIG PILOT'S WATCH PERPETUAL CALENDAR

1Hour hand

2Minute hand

3Seconds hand

4Date display

5Day display

Month display 6

Year display 7

Moon phase display 8

Power reserve display 9

Screw-in crown 10

— 8 —

FUNCTIONS OF THE CROWN

X — Normal position (screwed in)

0 — Winding position

1 — Setting the calendar

2 — Time setting

NORMAL POSITION

This watch has a screw-in crown. Screwing the crown in to its normal position (X)

prevents the inadvertent adjustment of the time or perpetual calendar and also acts as a

double seal to prevent water from seeping into the case. To release the crown, unscrew

it by turning it to the left, where it automatically assumes position 0, the winding position.

By depressing the crown into position X and turning it to the right at the same time, it is

screwed down firmly again and secured.

Important: Although the watch is water-resistant in positions 0, 1 and 2, the crown

should always be screwed in again for normal use (position X).

BIG PILOT'S WATCH PERPETUAL CALENDAR

X 0 1 2

— 9 —

BIG PILOT'S WATCH PERPETUAL CALENDAR

WINDING POSITION

With the crown in the winding position (0), you can also wind the automatic movement

by hand. A few revolutions of the crown are enough to start the movement. However, it

is better to wind the watch by turning the crown through approximately 20 revolutions

as this will ensure maximum accuracy. The crown must always be in position X when

you are wearing your watch.

SETTING THE CALENDAR

Release the screw-in crown and pull it out to position 1. You can now set the date

by turning the crown to the left (direct advance). You should not use the rapid-

advance function between 8 p.m. and 2 a.m. because the movement automatically

advances the date during this period.

Please note:

– If the crown is turned too quickly, the display discs might not be positioned correctly

in the display window. Generally, such a default is automatically corrected by the

movement when the calendar advances within the following 24 hours. Should this not

be the case, the movement needs to be reset by an IWC watchmaker.

– You must not move the calendar beyond the correct date. The complicated movement

is mechanically programmed and cannot be moved back in time without making a

professional adjustment to the movement. However, if you do move the date forwards

beyond the correct date, you have two options: You can either pull out the crown to

position 2 to stop the movement until the calendar setting matches the correct date

once again. This makes sense if the date has been set only a few days ahead. Or, you

take your watch to your watchmaker, who will be able to adjust the movement to reset

the calendar. This is recommended in the event of larger maladjustments.

— 10 —

BIG PILOT'S WATCH PERPETUAL CALENDAR

TIME SETTING

Pull out the crown to position 2. This will stop the movement. To set the time accur-

ately to the second, it is best to stop the movement as the seconds hand passes 60.

Now move the minute hand a few minute strokes beyond the time to be set. Then posi-

tion the minute hand by moving it gently backwards until it is exactly above the correct

minute stroke. This ensures that the minute hand begins to move immediately when

you restart the movement. To start the seconds hand, push in the crown to position 0.

Moving the hands forwards past midnight causes the calendar to switch to the following

day. When advancing the calendar, you can follow and observe the automatic switching

sequence.

Important:

– Under no circumstances must the hands be turned back between 8 p.m. and 2 a.m.

as this will result in maladjustment of the calendar.

– The hands must never be turned anticlockwise beyond 2 a.m.

– The crown must be pushed back into the normal position (X) and screwed in before

wearing the watch to avoid unintentional maladjustment of the calendar.
