iTOOLco REAL PALLET JACK Manual de usuario
User’s Guide
1325 CARDEN FARM DRIVE | CLINTON, TN 37716 | 865.670.3713 | ITOOLCO.COM
© 2021 PROPERTY OF ITOOLCO
ITOOLCO RPJ10K USER’S GUIDE
2012RPJ10KUG
Page | 2
BEFORE OPERATION OF THIS PRODUCT, READ
AND UNDERSTAND ALL OF THE INSTRUCTIONS
AND SAFETY INFORMATION IN THIS MANUAL
Contents
SAFETY FIRST .............................................................................................................................. 3
SAFETY ALERT SYMBOLS ........................................................................................................ 3
IMPORTANT SAFETY INFORMATION FOR ITOOLCO’S REAL PALLET JACK ............... 4
DESCRIPTION AND IDENTIFICATION .................................................................................... 6
SET-UP AND OPERATION ........................................................................................................ 11
LIMITED WARRANTY: ITOOLCO REAL PALLET JACK ..................................................... 13
ITOOLCO RPJ10K USER’S GUIDE
2012RPJ10KUG
Page | 3
SAFETY FIRST
Safety is essential in the use and maintenance of this product. This instruction manual and any
markings on the product provide information for avoiding hazards and unsafe practices related
to the use of this product. Observe all of the safety information provided.
SAFETY ALERT SYMBOLS
This symbol is used to call your attention to hazards or unsafe practices that could result in
injury or property damage. The three signal words, defined below, indicate the severity of the
hazard. The message after the signal word provides the information for preventing or avoiding
the hazard.
DANGER
Immediate hazards that, if not avoided, WILL result in severe
injury or death.
WARNING
Hazards that, if not avoided, COULD result in severe injury or
death.
CAUTION
Hazards or unsafe practices that, if not avoided, MAY result in
injury or property damage.
ITOOLCO RPJ10K USER’S GUIDE
2012RPJ10KUG
Page | 4
IMPORTANT SAFETY INFORMATION FOR ITOOLCO’S REAL PALLET JACK
WARNING
DO NOT EXCEED LOAD LIMITS.
Read and understand all instructions and safety information in this
manual before operating or servicing this product.
FAILURE TO OBSERVE THESE WARNINGS CAN RESULT IN SEVERE
INJURY OR DEATH
WARNING – PERSONAL SAFETY HAZARDS
Only qualified persons should use iTOOLco’s Real Pallet Jack.
Wear eye protection and hard hat when using this product.
Do not use this product while tired or under the influence of
drugs, alcohol, or medication.
Keep body parts and loose clothing away from moving parts.
Always follow operating procedures.
FAILURE TO OBSERVE THESE WARNINGS CAN RESULT IN SEVERE
INJURY OR DEATH.
WARNING – ENTANGLEMENT HAZARD
Do not operate this product while wearing loose-fitting clothing.
Retain long hair.
Keep hands clear of the Real Pallet Jack at all times.
FAILURE TO OBSERVE THESE WARNINGS CAN RESULT IN SEVERE
INJURY OR DEATH.
WARNING – PRODUCT USE HAZARDS
Use this product for manufacturer’s intended purpose only. Use
other than that which is described in this manual can result in
injury or property damage.
FAILURE TO OBSERVE THESE WARNINGS CAN RESULT IN SEVERE
INJURY OR DEATH.
ITOOLCO RPJ10K USER’S GUIDE
2012RPJ10KUG
Page | 5
WARNING – LIFTING HAZARDS
Use forklift to maneuver spool.
Never get under the spool being lifted.
FAILURE TO OBSERVE THESE WARNINGS CAN RESULT IN SEVERE
INJURY OR DEATH.
WARNING – WORK AREA HAZARDS
Keep work area clean and free of obstructions.
FAILURE TO OBSERVE THESE WARNINGS CAN RESULT IN SEVERE
INJURY OR DEATH.
ITOOLCO RPJ10K USER’S GUIDE
2012RPJ10KUG
Page | 6
DESCRIPTION AND IDENTIFICATION
Deliver and place reels to your final installation point safely and effortlessly. iTOOLco’s Real
Pallet Jack are a portable, heavy-duty solution for transporting spools up to 10,000 lb.
Made with all welded steel construction, loading and unloading the Real Pallet Jack is
easy. Loading from the drum side minimizes the potential of wire damage from forks. The dual
sided gates enable you to load spools from either side of the jack.
Whatever their size, spools automatically center the arbor hole with the spindle– ensuring the
spool is perfectly positioned for a quick, smooth payout every time. Maneuverability on the
jobsite is a snap using a forklift.
Added Bonus: Real Pallet Jacks collapse and stack for easy compact storage.
ITOOLCO RPJ10K USER’S GUIDE
2012RPJ10KUG
Page | 7
ITOOLCO RPJ10K USER’S GUIDE
2012RPJ10KUG
Page | 8
ITOOLCO RPJ10K USER’S GUIDE
2012RPJ10KUG
Page | 9
Step 1: Make sure you have the following - Real Pallet Jack,
two arbors, one axle, and the adjustable stop.
Image 1
Step 2: The jack mechanism will need to be raised from its stored
position to a vertical position to allow jack to snap into position
Images 2.1,2.2,2.3,N.1.
2.1
2.2
2.3
1
ITOOLCO RPJ10K USER’S GUIDE
2012RPJ10KUG
Page | 10
Step 3: Install Bumper Stop for spool placement on Real Pallet Jack as
shown.
Images 3.1,3.2.
3.1
3.2
NOTE: When folding and unfolding the jack, ensure that the orange
plate on the Jack is above the engagement pin as shown.
Image N.1
N.1
