ISOtunes PLUS Manual de usuario

Heavy-Duty Noise Blocking Earbuds

Table of Contents

English (EN)

Location of Controls � � � � � � � � � � � � � � � � � � � � � �3

LED Light Indicator � � � � � � � � � � � � � � � � � � � � � � �4

Charging � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � �5

Power On/O� � � � � � � � � � � � � � � � � � � � � � � � � � � �6

Bluetooth Pairing� � � � � � � � � � � � � � � � � � � � � � � � �7

Dual Connect Mode � � � � � � � � � � � � � � � � � � � � � �8

Music� � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � �9

Phone Calls � � � � � � � � � � � � � � � � � � � � � � � � � � � �10

Legalities � � � � � � � � � � � � � � � � � � � � � � � � � � � � � �11

Español (ES)

Localización de los controles � � � � � � � � � � � � � �15

Indicador de luz LED � � � � � � � � � � � � � � � � � � � � �16

Carga � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � �17

Encendido/apagado � � � � � � � � � � � � � � � � � � � � �18

Conexión Bluetooth� � � � � � � � � � � � � � � � � � � � � �19

Modo de conexión doble � � � � � � � � � � � � � � � � �20

Música� � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � �21

Llamadas telefónicas� � � � � � � � � � � � � � � � � � � � �22

Legalidades � � � � � � � � � � � � � � � � � � � � � � � � � � � �23

Table of Contents

EN |3

Location of Controls

1� Volume Up

2� Multi-Function Button (MFB)

3� Volume Down

4� LED Indicator Light

5� Bluetooth Mic

6� Charging Port

English (EN)

EN |4

LED Light Indicator

Product Operation LED Indicator Light Voice Prompt Tone Flashing Pattern

Charging l----- Solid

Charged l----- Solid

Power OFF l“Power O” Flash

Power ON l“Power On” Flash

Pairing ll“Bluetooth Pairing Mode” Alternate

Dual Connect Mode ll“Bluetooth Pairing Mode” Alternate

ISOtunes PLUS

EN |5

Charging

The earplugs are charged with a micro-USB charger and hold up to 10 hours of music

and talk time between charges.

Please charge with the included micro-USB

cable by plugging it into the Charging Port (6)(6)�

*Charging voltage should not exceed 5v.

1 2

While the cable is plugged into the Charging

Port (6)(6), the LED Indicator Light (4)(4) will let you

know if the battery is charging or f ully charged�

LED Indicator Light (4)

Solid Red = Charging (Cable Plugged In)

Solid Blue = Fully Charged (Cable Plugged In)

Please refer to the LED Indictor Light page for more information.

EN |6

Power On/O

Power On: Press and hold MFB (2)(2) for 3 seconds�

(you will hear “Power On”)

Power O: Press and hold MFB (2)(2) for 3 seconds�

(you will hear “Power O”)

LED Indicator Light (4)(4)

Blue Flash = Power ON

Red Flash = Power OFF

Please refer to the LED Indictor Light page for more information.

EN |7

Bluetooth Pairing

Open your Bluetooth settings on your

device�

1 2

Search “ISOtunes PLUS.”

Pair and connect�

Once connected you will hear

“Bluetooth Connected.”

After powering on, the headphones will automatically enter Pairing Mode.

You will hear “Bluetooth Pairing Mode” and the LED Indicator Light (4)(4) will ash,

alternating Blue and Red�

EN |8

Dual Connect Mode

This product can connect to two devices at the same time such as your phone and

your computer.

1. Pair and Connect to your rst device as

described in Bluetooth Pairing�

This will be device A�

2� Press and Hold the MFB (2)(2) for 7 seconds

until you hear “Bluetooth Pairing Mode”

(you will hear Power O, keep holding the

button until you hear “Bluetooth Pairing

Mode”).

3� Pair and Connect to the 2nd device as

described in Bluetooth Pairing�

This will be device B�

4� On Device A, go to the Bluetooth menu and

manually connect to ISOtunes PLUS�

5� Both devices are now connected�

Pairing Reset

If you have issues connecting to any

device, we recommend a Pairing Reset:

1� The headphones need to be powered on�

2� Press and Hold the Volume Up (1) and the

Volume Down (3) for 4 seconds�

3� Continue holding, listen for a double tone

and then release�

LED Indicator Light (4)(4)

Alternating Blue & Red = Pairing Mode

Please refer to the LED Indictor Light page for more information.

EN |9

Music

Play/Pause: Short single press MFB (2)(2)

Next Track: Double press MFB (2)(2)

Previous Track: Triple press MFB (2)(2)

Music Volume Up: Short single press Volume Up (1)(1)

Music Volume Down: Short single press Volume Down (3)(3)

EN |10

Phone Calls

Answer/End Call: Short single press MFB (2)(2)

Reject Call: Press and hold MFB (2)(2) for 1 second

Siri / Google Assistant

Press and hold MFB (2) for 1 second�
