INSTRUCTION BOOK
LS150
Please read this instruction book carefully before
using the device.
What’s inside
Parts Name
How to Manage Power
03
04
06
Getting Started _01
Bluetooth Mode
Wi-Fi Mode
FM Radio Mode
Aux-in Mode
07
10
15
17
Using the Device _02
Safety Precautions
Troubleshooting
Certifications
Copyright
Disclaimers
Registered Trademarks
Specifications
Product Features
18
23
23
24
24
25
25
26
Miscellaneous _03
CONTENTS
Getting Started
03
User Guide
Power Adapter: Supplies power by connecting it to the
speaker.
FM Antenna Cable: Receives signal to listen to FM radio
programming.
Audio Cable: Gets the sound of external devices out to the
speaker by connecting two ends.
Quick Start Guide: Describes basics of using the device.
Warranty Card: Do not misplace this warranty card as it
may be needed when you ask for warranty service.
User Guide: You can download it from
[http://www.iriver.com – SUPPORT – DOWNLOAD].
What’s inside may be changed without prior notice to
improve the performance or quality of the device.
What’s
inside
LS150 Speaker Power Adapter
Audio Cable Quick Start Guide
& Warranty Card
FM Antenna
Cable
Getting Started
04
User Guide
The appearance of the device as well as the printed and
engraved information may vary depending on model.
Parts
Names
NFC Connection
Next Track/Next Channel
Bluetooth Pairing/WPS/FM Scan
Previous Track/Previous Channel
Control VolumeReplay/Pause/Phone Call
Choose Power/Menu
Aux Input Port/FM Antenna Cable Connection Port
USB Output for Recharging
DC Input Port
Getting Started
05
User Guide
Previous Track/Previous Channel
While music is played: Moves to the previous song or to
the start of the same song
While listening to FM radio: Moves to the previous channel
Replay/Pause/Phone Call
While music is played: Play/pause
While listening to FM radio: Mute
While connecting to smartphone through Bluetooth:
Takes/terminates the phone call
Next Track/Next Channel
While music is played: Plays the next song.
While listening to FM radio: Moves to the next channel.
Bluetooth Pairing/WPS/FM Scan
Bluetooth Mode: Pairs with a Bluetooth device.
Wi-Fi Mode: Connects to Wi-Fi.
FM Radio Mode: Saves a radio channel currently on air.
NFC Connection: If you tag an NFC-enabled smartphone
to this part, you can connect with the NFC input mode.
Choose Power/Menu: You can turn on/off power or select
menus by turning the knob.
Control Volume: You can turn the volume wheel to adjust
the volume. USB Output for Recharging: You can recharge
the device by connecting it with the speaker through a
USB charging cable. (DC 5V/1A)
Aux Input Port: Gets the sound of external devices out to
the speaker by connecting through an audio cable.
FM Antenna Cable Connection Port: Connects the antenna cable.
DC Input Port: Supplies power to the device by connecting
a DC 9V/2.5A power adaptor.
Getting Started
06
User Guide
Power
Manage-
ment
Turning the Device On/Off
1. Power is turned on if you select a menu of your choice
by turning the [Power/Menu] wheel of the device.
2. Power is turned off if you turn the [Power/Menu] knob
to [Off].
Standby mode
1.
The device will turn to a standby mode automatically if there
is no input for 15 minutes on a connection standby mode.
2. You can lift the standby mode by pressing any button on
the device.
Connecting Power Supply
1. If you connect the power adaptor's plug to [DC input port]
on the back of the device, power will be turned on.
Recharging mobile device
1. If you connect the device with [USB output for recharging]
on the back of the device, the device will be recharged.
(DC 5V/1A)
Using the Device
07
User Guide
Bluetooth
Mode
Bluetooth Pairing
1. Select [ ] by turning the [Power/Menu] knob.
2. Turn on the Bluetooth button of the device you want to
connect (smartphone, tablet, or PC) after pressing the
[PAIR·WPS·SCAN] button on the upper part of the device.
3. Select [LS150_xxxxxx] from the list of Bluetooth devices.
4. Once pairing is completed, you will hear a sound
[Paired] and you can start replaying music using the
connected device.
Bluetooth pairing through NFC
1. Select [ ] by turning the [Power/Menu] knob.
2. Turn on the NFC function on the device you want to
connect (smartphone, tablet, or PC).
3. If you put the device close to [ ] on the upper part of
the device for more than 2 seconds, you will see a pop-
up window indicating the device has been connected.
4. If you press [Yes], pairing would be completed with a
recorded sound [Paired].
5. You can replay music with the device.
Disconnecting Bluetooth pairing
1. When Bluetooth is connected, you can lift pairing if you
press the [PAIR·WPS·SCAN] button.
You can enjoy music wirelessly by using Bluetooth-
enabled devices.
Using the Device
08
User Guide
If you put the device close to [ ] on the upper part of the
device again, pairing would be lifted.
If the device is in a metallic casing, please remove it before
attempting pairing.
Some NFC devices may not be available for pairing.
Bluetooth Support Specifications
Profile: A2DP, AVRCP
Device performance may be affected during Hi-Fi playback
(recommended specs below 48 kHz).
When connecting with an unauthorized device on Bluetooth
SIG, compatibility may not be guaranteed.
Please do not turn off the power of speaker or device while
Bluetooth is being connected.
When Bluetooth is not working, please try again after turning
off the power of speaker or device.
Pairing methods may differ for each individual Bluetooth
device. Always refer to respective instruction manuals for
details.
When connecting the product to a Bluetooth device, the
distance between the two must be within 20 cm.
Audio quality will degrade with longer distances, and
pairing may disconnect at a distance of 2 m (6.5 ft) or more
(Distances may vary depending on device and environment).
Crosstalk may be heard while using Bluetooth.
Malfunction, noise, and other undesirable effects may
occur due to environmental factors.
In case signal interference affects data transmission
(e.g., holding the device with a hand while wearing a
Bluetooth device, holding the device while holding
another electronic device, etc.)
In case the device or Bluetooth headset's radio transmitter
is touching parts of the body.
If the transmission strength is affected by walls, corners,
partitions, etc.
If devices using the same frequency bandwidth cause
interference (e.g., medical devices, microwave ovens,
Wi-Fi, etc.)
In places where signals are weak or there are many
interferences such as inside the elevator or underground,
NFC pairing will show no LS150 connection option with
connection info only.
Using the Device
09
User Guide
Listening to Music
Adjust the volume by turning the [Volume] knob of the
device.
If you press the [ ] button on the upper side of the
device while replaying, it will pause. If you press it again,
it will replay.
If you press the [ / ] button on the upper side of
the device while replaying, it will play the previous/next
song.
Taking Incoming Phone Calls
To take an incoming call while replaying music, you can
press the [ ] button on the upper side of the device.
LED: Incoming phone call
If you press the [ ] button on the upper side of the
device while talking, the phone call will be terminated.
LED: Hanging up the phone call
1. Select [Wi-Fi] by turning the [Power/Menu] knob in
front of the device.
2. Select [LS150_xxxxxx] on the Wi-Fi connection list of
the device.
3. Once you enter [10.10.10.254] in the browser’s address
bar, [LS150 Web Setup Menu] will appear.
4. If you select the [Wi-Fi] tab, you will see a list of APs to
which you can connect.
5. Select a desired [AP] to connect to the wireless network.
Additional information such as key index and network
key may be required depending on AP settings.
6. You can change AP settings after selecting [Revise
Network] by pressing the connected AP for a few seconds.
Using the Device
10
User Guide
Wi-Fi
Mode
Downloading IRIVER Live Stream
1.
Please install the [IRIVER Live Stream] app by downloading
it from the device's app store.
Using features such as [IRIVER Live Stream/AirPlay/DLNA/
Multi-room/Windows 10 Cast Media to Device], you can
replay a variety of streaming services in addition to local
music by connecting to Wi-Fi network.
Connecting wireless network manually
Connecting automatically using WPS
1. Select [Wi-Fi] by turning the [Power/Menu] knob in
front of the device.
2. Select [Wi-Fi Setup Wizard] after executing [IRIVER
Live Stream].
