CR67 User Manual
Network Video Recorder
Version 1.0
2
support@ionodes.com | www.ionodes.com | 450-696-1060
CR67 Network Video Recorder
User Manual
©2010-2020, IONODES INC
All Rights reserved.
No part of this documentation may be reproduced or transmitted in any form or by any means,
electronic, photographic or mechanical, except as expressed in the Software License Agreement.
IONODES shall not be liable for technical or editorial errors or omissions contained herein. The
information in this document is subject to change without notice.
The information in this publication is provided “as is” without warranty of any kind. The entire risk arising
out of the use of this information remains with the recipient. In no event shall IONODES be liable for any
direct, consequential, incidental, special, punitive, or other damages whatsoever (including without
limitation, damages for loss of business profits, business interruption or loss of business information),
even if IONODES has been advised of the possibility of such damages and whether in an action or
contract or tort, including negligence.
This software and documentation are copyrighted. All other rights, including ownership of the software,
are reserved to IONODES Inc. Windows is a registered trademarks of Microsoft Corporation. All other
brand and product names are trademarks or registered trademarks of the respective owners.
The following words and symbols mark special messages throughout this guide:
Warning: Text set off in this manner indicates that failure to follow directions could result in damage to persons or
equipment.
Note: Text set off in this manner indicates special instructions which should be paid attention to.
3
support@ionodes.com | www.ionodes.com | 450-696-1060
Contents
1Important Safety Instructions ....................................................................................................................... 5
2Cleaning Instructions ..................................................................................................................................... 6
3Handling Notes............................................................................................................................................... 6
4Moisture and Condensation Notes............................................................................................................... 6
5Product Description ....................................................................................................................................... 8
6CR67 Series Appliance Features.................................................................................................................... 9
6.1What is in the Box ................................................................................................................................... 9
6.2 Front and rear panel controls and LEDs ............................................................................................. 10
6.2.1 Status LED indication..................................................................................................................... 12
6.3 Identifying your model and serial number......................................................................................... 12
6.3.1 Appliance Model Number............................................................................................................. 12
6.3.2 Appliance Serial Number .............................................................................................................. 12
7Getting Started ............................................................................................................................................. 13
7.1 Specifications ........................................................................................................................................ 13
7.2 Hardware Installation ........................................................................................................................... 13
7.3 Keyboard & Mouse Setup .................................................................................................................... 13
7.4 Monitor Setup ....................................................................................................................................... 14
7.5 Network Setup ...................................................................................................................................... 15
7.5.1 Network Connections.................................................................................................................... 15
7.6 External Storage.................................................................................................................................... 16
8Software Environment ................................................................................................................................. 16
8.1 Anti-Virus Software ............................................................................................................................... 17
8.2 Software Updates ................................................................................................................................. 17
8.3 Remote Access ...................................................................................................................................... 17
9Basic Operating Instructions ....................................................................................................................... 17
9.1 Powering on the appliance .................................................................................................................. 17
9.2 Powering off the appliance .................................................................................................................. 18
9.3 Initial Configuration Steps.................................................................................................................... 18
9.3.1 Securing access to your appliance ............................................................................................... 18
10 Troubleshooting ....................................................................................................................................... 20
10.1 The device does not seem to power up.............................................................................................. 20
4
support@ionodes.com | www.ionodes.com | 450-696-1060
10.2 Nothing is displayed on the HDMI / DVI-D / D-Sub (VGA) video output ........................................... 20
10.3 Cannot communicate with your CR67 appliance via the network.................................................... 20
10.4 Your boot drive appears corrupted..................................................................................................... 21
11 Getting Help .............................................................................................................................................. 21
Annex –Statement Limited Warranty ............................................................................................................ 22
5
support@ionodes.com | www.ionodes.com | 450-696-1060
1Important Safety Instructions
WARNING: Read and save these instructions! Follow all warnings and instructions specified within this
document and/or on the equipment.
CAUTION: There is no ON/OFF SWITCH for the power supply. Please make sure to properly
shutdown the device’s operating system prior to removing its power cable.
This CR67 equipment is designed to be installed in a desktop configuration, within indoor conditions only.
It should be installed by qualified personnel only (person having the appropriate technical training and
experience necessary for product installation).
When installing the equipment, please make sure that cables are installed so that accidents cannot occur.
Cables connected to the equipment must not be subject to any mechanical strain.
To reduce the risk of fire, electric shock and/or injury, observe the following:
•Do not position the equipment as such that persons could walk on the connected cables.
•Do not spill any type of liquid substance on or near the equipment.
•Do not touch the equipment and its connected cables during an electrical storm; there may be a
risk of electric shock.
•Do not attempt to connect this equipment to electrical outlets controlled by switches or automatic
timers.
•The equipment should be situated away from heat sources such as radiators, heat registers, stoves,
or other products that generate heat.
•Do not place a heavy object on or step on the product. The object may fall, causing serious personal
injury and serious damage to the product.
6
support@ionodes.com | www.ionodes.com | 450-696-1060
2Cleaning Instructions
To clean the surface of the equipment, carry out the following instructions:
1. Shut down your equipment and unplug the power adapter.
2. Gently wipe the surface with a damp, soft, lint-free cloth.
3. Avoid getting moisture in any openings.
Note: Do not use abrasives, water, thinners, solvents, aerosol cleaners (spray polish), or any
aromatic solvents, etc. that may enter through holes in the equipment and cause damage.
3Handling Notes
When shipping the product, the original shipping carton and packing materials should be used. For
maximum protection, repack the unit as it was originally packed at our factory.
Do not use volatile liquids, such as insect spray, near the unit. Do not leave rubber or plastic products in
contact with the product for long periods of time. They will leave marks on the surface finish.
4Moisture and Condensation Notes
Moisture condensation will damage the product. Read the following notes carefully.
Moisture condensation occurs during the following cases:
•Transferring the product directly from a cold place to a warm place.
•Using the product in a room where you just turned on the heater, or a place where the cold wind
from an air conditioning unit directly hits the unit.
•In the summer, when moving the product to a hot and humid place after leaving an air-conditioned
space.
•Using the product in a humid environment.
Note: Do not use the product when moisture or condensation may occur. If the product is used
in such an environment, it may damage discs and internal parts.
7
support@ionodes.com | www.ionodes.com | 450-696-1060
8
support@ionodes.com | www.ionodes.com | 450-696-1060
5Product Description
The CR67 series of compact IP video appliances deliver enterprise-class video recording and management
solutions to small, medium and large single or multi-site surveillance deployments. These appliances
provide an embedded, high-performance networked video platform capable of recording multiple cameras
with high sustained data throughputs to meet a multitude of requirements. The CR67 series appliances
can host enterprise-class video management (VMS) software solutions commonly used in the market. With
a pre-loaded operating system and your VMS of choice for on premise video recording, IONODES takes the
hassle away from complex set-up and configuration of an IP video management environment.
Combining the CR67 series appliances with your IP cameras and IP video encoders of choice provides a
cost-effective means to convert legacy analog video systems to IP, and build new, state of the art, IP video
surveillance deployments. The CR67 series supports all IP cameras and IP video encoders supported by all
major VMS solutions.
The CR67 Series appliances and VMS software combine to provide innovative configuration options and
tools that significantly decrease the deployment time and the effort needed to deploy your security
solution. Simply connect a USB keyboard, mouse and monitor to the appliance, install your favorite VMS
and you are ready to add your IP cameras and encoders to your video system. Alternatively, remote
configuration is also possible via network web access or VMS client application(s).
To support a wide range of deployment scenarios, while ensuring reliability and high availability, the CR67
Series appliances use industrial grade components and high-performance storage drives designed for 24/7
video recording.
9
support@ionodes.com | www.ionodes.com | 450-696-1060
6CR67 Series Appliance Features
This chapter introduces you to the basic features of your CR67 Series appliance. Read this chapter to learn:
•About unpacking your appliance
•How to identify the features of your appliance
•How to locate your appliance’s model and serial number
•What accessories are available for your appliance
6.1 What is in the Box
Note: Verify that the shipping box contains the following parts and ensure no damage was
sustained during shipment. If there is anything missing or damaged, please contact your sales
representative.
Your appliance should be packed with the following:
1. 1 x CR67 Series appliance
2. 1 x North American power cord
Below are additional items which are not included, but may be required:
1. USB mouse & keyboard
2. Computer monitor
3. Internet access and/or a network switch
4. Power bar with surge protection
5. Region specific power supply cord (can be ordered from IONODES or sourced externally)
10
support@ionodes.com | www.ionodes.com | 450-696-1060
6.2 Front and rear panel controls and LEDs
1
HDD Activity LED
2
Reset button
3
Power button
4
Microphone jack
5
2 x USB 3.0
6
Headphone jack
