ION Slam Jam Manual de usuario

Slam Jam

Quickstart Guide English ( 2 – 9 )

Guía de inicio rápido Español ( 10 – 17 )

Appendix English ( 18 – 19 )

Quickstart Guide (English)

Introduction

Thank you for purchasing the Slam Jam. At ION, your entertainment is as

important to us as it is to you. That’s why we design our products with one thing in

mind—to make your life more fun and more convenient.

Box Contents

Slam Jam

Micro-USB Charging Cable

1/8” (3.5mm) to 1/8” (3.5mm) Cable

Quickstart Guide

Safety & Warranty Manual

Support

For the latest information about this product (documentation, technical

specifications, system requirements, compatibility information, etc.) and product

registration, visit ionaudio.com.

For additional product support, visit ionaudio.com/support.

Outdoor Use and Care

Certified to IPX7 standards, Slam Jam is waterproof and submersible up to 3 ft. (1

m) for up to 30 minutes. Please review the tips below to get the best performance

from Slam Jam:

•Bring Slam Jam indoors during extreme weather.

•Please do not connect the power cable to Slam Jam in a wet environment.

Make sure the micro USB input, micro USB cable and power outlet are al

lcompletely dry before making any connections.

•WARNING: Keep any non-water-resistant devices (phones, music players,

etc.) in a dry place where they will not be affected by water and cause a risk

of electric shock.

Features

Top Panel

1253

1. Bluetooth Button: Press and hold this button to disconnect a paired Bluetooth

device. When Bluetooth is disconnected, briefly press this button to reconnect to

Bluetooth, or press and hold this button to enter stereo linking mode to link to

another Slam Jam.

2. Play/Pause / Call Receive / Call End: Press to play or pause a track from a

connected Bluetooth device. When Bluetooth-paired, press and release this button

to answer a phone call. The phone’s ringtone will be heard through Slam Jam’s

speaker until the call is answered. When the call has been disconnected, Slam Jam

will resume playing music. To reject an incoming call, press and hold this button.

3. Power On/Off Switch: Press and hold this button to turn Slam Jam on/off. While

Slam Jam is connected to a power source, it does not need to be powered on to

charge the battery.

4. Battery/Charging Indicator: These 4 LEDs will indicate the current battery level.

When all 4 LEDs are lit, Slam Jam has 70-100% battery life. When the first LED is

blinking slowly, Slam Jam is at low battery, less than 10%. Connect the included

USB cable from the Micro USB Port to a computer or phone charger to recharge

the battery. The first LED will flash quickly when charging. All 4 LEDs will be

become lit when Slam Jam is fully charged.

5. Volume Down/Previous: Press this to decrease the speaker volume on Slam Jam.

Press and hold this to go to the beginning of the track or the previous track.

6. Volume Up/Next: Press this to increase the speaker volume on Slam Jam. Press

and hold this to skip to the next Bluetooth track.

Note: Press the Volume Up and Volume Down buttons at the same time to

enable the drum sounds and cycle through the 3 banks of sounds.

Note: With some apps, pressing the Previous Track button or Next Track button

may go to another playlist or music genre.

Rear Panel

Open the cover to access the following controls:

1. Auxiliary Input: This stereo 3.5 mm (1/8”) input can be

used to connect a CD player, MP3 player, or other

audio source.

2. Lights Button: Press this button to turn the lights on and off.

3. Micro USB Port: Use the included USB cable to connect this to a USB port on

your computer or phone charger to recharge Slam Jam's battery.

Note: When the bottom cover is open, the unit will not be water resistant. Make sure

Slam Jam and connections are dry before charging. Never charge when the unit is wet.

Operation

Drum Sounds

To activate the drum sounds, press and hold the Volume – and + buttons until the

lights blink red 3 times.

Press the Volume – and + buttons at the same time again to cycle through the 3 banks

of drum sounds.

Tap Slam Jam on its top, front or sides to trigger a drum sound (the rear panel with the

port door will not trigger drum sounds). The type and volume of the sounds can vary

depending on where and how hard you tap Slam Jam (soft or hard)

Pairing or Disconnecting a Bluetooth Device

1. Turn on your Bluetooth device.

2. Power on Slam Jam and it will automatically go into pairing mode to search for

Bluetooth devices. You will know you are in pairing mode when the lights are

slowly flashing.

3. Navigate to your Bluetooth device’s setup screen, find Slam Jam and connect.

Note: If your Bluetooth device prompts for a pairing code, enter 0000.

4. Press and hold the Bluetooth button to disconnect a paired Bluetooth device.

5. To connect to another Bluetooth device, briefly press the Bluetooth button and

repeat step 3.

Note: Maximum range will be achieved when using devices with Bluetooth 4.0.

Using the Phone

Note: You must power on and pair Slam Jam with your Bluetooth device before using it

to listen to music or as a speakerphone.

When you have an incoming call, Slam Jam’s speaker will play a ringtone.

1. To answer the call, press Slam Jam's Play/Pause button.

Note: If you get an incoming call during music playback, the music will pause until

you end the call.

To reject an incoming call, press and hold the Play/Pause button.

2. Speak into the microphone and adjust the call volume using the – and +buttons.

3. To end the call, press and hold the Play/Pause button.

If another incoming call is received while using the phone:

•Press and hold the Play/Pause button to reject the incoming call.

•Briefly press the Play/Pause button to answer the second call and put the first call

on hold.

•Briefly press the Play/Pause button again to hang up the second call.

•Press and hold the Play/Pause button to switch between calls.

Linking Two Speakers Together Wirelessly

1. Power on both Slam Jams.

Note: In order to use stereo linking mode, you cannot have a Bluetooth device

connected. If one speaker is connected to a Bluetooth device, break the connection by

pressing and holding the Bluetooth button.

2. With no Bluetooth device connected, on one Slam Jam press and hold the Bluetooth

button until you hear a short 3-tone melody; repeat this for the second Slam Jam. The

flashing red and blue lights will indicate the Slam Jams are searching for each other to

link.

3. Wait about 10-30 seconds for the Slam Jams to find each other. Now that the two

speakers are “linked,” the lights will glow slowly.

Note: The first speaker will be the "primary" speaker, and play the Left channel. The

second speaker will be the "secondary" speaker, and play the right channel.

4. When the Slam Jams are wirelessly linked to play in stereo, turn on Bluetooth on your

device and connect to Slam Jam.

5. Once your smartphone is paired, you will hear “Bluetooth Connected” (if the voice

prompts are enabled) and audio can now play out of both speakers in stereo.

In stereo linked mode:

•UI Controls on both speakers will be active.

•To disconnect Bluetooth, press and hold the Bluetooth button of the "primary" speaker.

•To reconnect Bluetooth, briefly press the Bluetooth button of the "primary" speaker.

•To exit stereo linked mode, press and hold the Bluetooth button of the "secondary"

speaker until the speaker goes back into pairing mode. The "primary" speaker will

continue to play.

•In stereo linked mode, press Power to turn off both speakers.

Troubleshooting

If the unit is not charging: Make sure the micro USB cable is properly connected to the

power adapter and the power outlet.

If the sound is distorted: Try lowering the volume control of your sound source. Also, try to

reduce the overall volume of Slam Jam.

If there is too much bass: Try adjusting the tone or EQ control on your sound source to lower

the bass level. This will allow you to play the music louder before clipping (distortion) occurs.

If you cannot connect your audio device to Slam Jam via Bluetooth:

•Have your audio device (e.g., smartphone or tablet) and Slam Jam as close together as

possible while trying to connect. Make sure both the audio device and Slam Jam are

unobstructed by walls, furniture, etc.

•Reset the Bluetooth connection on Slam Jam to disconnect Slam Jam from any other

audio device and restart the search process. If this does not work right away, power off

Slam Jam and then power it back on. See Pairing or Disconnecting a Bluetooth

Device for more information.

•Reset the Bluetooth connection on your audio device by turning Bluetooth off and back

on. You can find this under the Bluetooth menu in the Settings for your phone or other

audio device.

If this does not work, and you have connected to Slam Jam before, find Slam Jam in the

list of available or previously connected devices in your audio device's Bluetooth menu,

tap the "gear" or “i” icon located next to it and then select Unpair or Forget. Turn Slam

Jam off and back on and try pairing again once it reappears in your available devices list.

Note: If Slam Jam has been paired to another audio device recently that is still within

range, you may need to repeat this process with that audio device to fully disconnect.
