IOGear GKM552RB Manual de usuario
GKM552RB
PART NO. Q1641
www.iogear.com
Quick Start Guide
Long Range 2.4 GHz Wireless Keyboard
and Mouse Combo
Guide de demarrage rapide
Clavier et souris sans fil longue portée
2.4 GHz
Guía de Inicio Rápido
Combo de teclado y mouse inalámbricos
de 2.4 GHz de largo alcance
1
System Requirements
Package Contents
• 1 x Wireless Keyboard
• 1 x Wireless Optical Mouse
• 1 x USB Receiver*
• 2 x AAA Battery for Keyboard
• 1 x AA Batteries for Mouse
• 1 x Quick Start Guide
• 1 x Warranty Card
• Windows®10, Windows® 8, Windows® 7
• Mac OS X (10.2.x or later)
• One available USB port
Keryboard - Front View
Keyboard-Front view
1. Red LED:
• When light is on solid it means Numlock is
enabled. The LED will turn off after 5 min.
• To disable Numlock and use Arrow function
press Numlock again, LED will shutoff
• When battery is low the Red LED will blink
Mouse - Front View
1. Left Click
2. Scroll Wheel (third button)
3. Right Click
4. DPI Cycle button
2
Overview
123
4
1
3
Keyboard Battery Installation
1. Open the battery cover on the back of the keyboard
2. Insert two of the included AAA batteries
3. Close the battery cover
Mouse Battery Installation
1. Open the battery cover on the bottom of the mouse
2. Insert the included AA battery
3. Close the battery cover
USB Receiver Installation
USB receiver is located underneath the mouse within battery cover
1. Plug the USB receiver into an available USB port on your computer
2. Your Operating System will start to install the device driver
automatically
3. No additional software is needed. Enjoy your new keyboard and
mouse!
Keyboard and Mouse Re-Pair process
1. Insert USB receiver into your computer. Wait until computer
recognizes the receiver.
2. Make sure batteries are inserted to keyboard (2 AAA) and mouse
(1 AA). Bring both keyboard and mouse within 18 inches of USB
receiver.
3. Press “ESC” key and “K” key together. Keyboard will auto connect
with receiver.
4. Within 30 seconds of step 3, press the mouse middle button and
right button together. Mouse will pair.
Hardware Installation
1. Insert USB receiver into your PC’s USB port, and wait for the PC
recognize the receiver.
2. Install 2-AAA batteries into the keyboard battery slot and 1-AA
battery into the mouse battery slot and turn the power on.
*Keep the keyboard and mouse close to the USB receiver during
this process.
3. Press “ESC” and “K” key together. The keyboard will auto-connect
to receiver.
4. Press the “middle” key and “right button” on the mouse at the same
time, the mouse will auto-connect to receiver as well.
*** Step 3 and 4 need to be completed under 30 seconds.***
Re-pairing process 4
Warranty Information
This product carries a 3 Year Limited Warranty. For the terms and
conditions of this warranty, please go to
https://www.iogear.com/support/warranty
Register online at https://www.iogear.com/register
Important Product Information
Product Model
Serial Number
Limited Warranty
Contact
WE’RE HERE TO HELP YOU!
NEED ASSISTANCE SETTING UP THIS PRODUCT?
Make sure you:
1. Visit www.iogear.com for more product information
2. Visit www.iogear.com/support for live help and product support
IOGEAR
https://iogear.custhelp.com
support@iogear.com
www.iogear.com
www.kalibergaming.com
Compliance Statement
WARNING: This product may expose you to chemicals including
Cadmium which is known to the State of California to cause cancer,
birth defects or other reproductive harm. For more information, go to
www.P65Warnings.ca.gov
Federal Communications Commission Statement (FCC)
Statement
This equipment has been tested and found to comply with the limits
for a Class B digital device, pursuant to Part 15 of the FCC Rules.
These limits are designed to provide reasonable protection against
harmful interference in a residential setting. This product generates,
uses, and can radiate radio frequency energy and, if not installed and
used as directed, it may cause harmful interference to radio communi-
cations. Although this product complies with the limits for a Class B
digital device, there is no guarantee that interference will not occur in
a particular installation.
CE Statement
This device has been tested and found to comply with the following
European Union directivies: Electromagnetic Capability
(2004/108/EC), Low Voltage (2006/95/EC) and R&TTED (1995/5/EC).
1
Contenu de l'emballage
Configuration système requise
• 1 x clavier sans fil
• 1 x souris optique sans fil
• 1 x récepteur USB *
• 2 pile AAA pour clavier
• 1 piles AA pour souris
• 1 x guide de démarrage rapide
• 1 x carte de garantie
• Windows® 10, Windows® 8, Windows® 7
• Mac OS X (10.2.x ou version ultérieure)
• Un port USB disponible
2
Vue avant de la souris
1. Clic gauche
2. Molette de défilement (troisième bouton)
3. Clic droit
4. Bouton de cycle DPI
L’aperçu du produit
Vue avant du clavier
1. LED rouge:
• Lorsque la lumière est allumée, cela signifie que Numlock est activé.
La LED s'éteindra après 5 min.
• Pour désactiver Numlock et utiliser la fonction Flèche, appuyez à
nouveau sur Numlock, la LED s'éteindra
• Lorsque la batterie est faible, la LED rouge clignote
12
3
4
1
