Intex Quick-Fill AP639 Manual de usuario

202

(202) AP639 ELECTRIC PUMP ENGLISH 4.875” X 7.25” 05/12/2021

READ AND FOLLOW ALL INSTRUCTIONS BEFORE USING THIS PRODUCT

INTEX®OWNER'S MANUAL

Quick-Fill™ Electric Air Pump

Model AP639 110 – 120Volt ~ 60Hz 0.95A

PARTS DESCRIPTION:

1. PUMP

2. INFLATION CONNECTOR

3. DEFLATION CONNECTOR

4. SWITCH

5. AC LINE CORD

6. NOZZLES

7. VENT HOLES / SLOTS

OPERATING INSTRUCTIONS

General

• This appliance has a polarized plug (one blade is wider than the other). This plug will t in a polarized outlet only one

way. If the plug does not t fully in the outlet, reverse the plug. If it still does not t, contact a qualied electrician to

install the proper outlet. Do not change the plug in any way.

• Return pump and nozzles to package when not in use.

SERVICING OF A DOUBLE-INSULATED PRODUCT:

In a double-insulated product, two systems of insulation are provided instead of grounding. No grounding means is provided

on a double-insulated product, nor should a means for grounding be added to the product. Servicing of a double-insulated

product requires extreme care and knowledge of the system, and should be done only by qualied service personnel.

Replacement parts for a double-insulated product must be identical to those parts in the product.

A double-insulated product is marked with the words "DOUBLE INSULATION" or "DOUBLE INSULATED" and with the

symbol .

NAMES OF PARTS

READ AND SAVE THESE INSTRUCTIONS

Page 1 202-***-R0-2205

• For Indoor Household Use Only.

• Adult use only.

• Do not drop unit into water or expose unit to rain or water.

• Do not direct air stream at face or body.

• Do not operate for more than 10 minutes at a time. Unplug and let cool at least 10 minutes.

• Unplug unit when not in use.

• Do not obstruct vent holes or open source.

• Do not insert objects into the ination or deation connector.

• The AC supply cord cannot be replaced. If the cord is damaged the appliance should be scrapped.

• Do not run cord under carpeting. Do not cover cord with throw rugs, runners, or similar coverings. Do not route cord

under furniture or appliances. Arrange cord away from tra󰀩c area and where it will not be tripped over.

FOLLOW THESE RULES AND ALL INSTRUCTIONS TO AVOID PROPERTY DAMAGE, ELECTRIC SHOCK, BURNS

OR OTHER INJURY.

WARNING

• To reduce the risk of electric shock or injury, use indoors only, do not expose to rain. Store indoors.

CAUTION

NOTE: Drawings for illustration purpose only. Actual product may vary. Not to scale.

202

OPERATING INSTRUCTIONS

INFLATION

1. Attach nozzle to the ination connector if necessary and hold pump against ination valve on item to be inated.

See Fig (1).

NOTE:

On large items like inatable boats and large air mattresses, the pump will t directly into the ination valves and

provide faster ination times. Use the appropriate nozzle on small ination valves as on small air mattresses, etc.

2. Plug in the AC line cord into an AC electrical outlet. See Fig (2).

3. SWITCH ON: Press "I"; SWITCH OFF: Press "0". See Fig (3).

DEFLATION

1. Attach nozzle to the deation connector if necessary and hold pump against ination valve on item to be deated.

See Fig (4).

NOTE: On large items like inatable boats and large air mattresses, the pump will t directly into the ination valves and

provide faster deation times. Use the appropriate nozzle on small ination valves as on small air mattresses, etc.

2. Plug in the AC line cord into an AC electrical outlet. See Fig (2).

3. SWITCH ON: Press "I"; SWITCH OFF: Press "0". See Fig (3).

(202) AP639 ELECTRIC PUMP ENGLISH 4.875” X 7.25” 05/12/2021

READ AND SAVE THESE INSTRUCTIONS

Page 2

FIG (2)

220-240V 110-120V

FIG (3): SWITCH

MAINTENANCE INSTRUCTIONS

No specic air pump maintenance is required. Air pump has no user serviceable parts.

MOVING AND STORAGE INSTRUCTIONS

Move the product, air pump and accessories to the power source location. Make sure the power cord is free of twist, kink

and knot. Fold the power cord loosely, and return pump and nozzles to package when not in use.

FIG (4): ATTACH NOZZLE

FIG (3): SWITCH

FIG (2)

220-240V 110-120V

FIG (1): ATTACH NOZZLE

®™ Trademarks used in some countries of the world under license from/®™ Marques utilisées dans certains pays sous licence de/Marcas

registradas utilizadas en algunos países del mundo bajo licencia de/Warenzeichen verwendet in einigen Ländern der Welt in Lizenz von/

Intex Marketing Ltd. to/à/a/an Intex Development Co. Ltd., Hong Kong & Intex Recreation Corp., P.O. Box 1440, Long Beach,

CA 90801 • Distributed in the European Union by/Distribué dans l’Union Européenne par/Distribuido en la unión Europea por/Vertrieb in

der Europäischen Union durch/Intex Trading B.V., Venneveld 9, 4705 RR Roosendaal – The Netherlands

www.intexcorp.com
