Getting Started InterwriteTM Pad
GETTING STARTED
for Windows and the Mac
InterwriteTM Pad
2InterwriteTM Pad Getting Started
We at Interwrite LearningTM are proud of our family of Inter-
write products. We strive to continue to bring you the best
the technology has to offer. We urge you to visit our Web
site, where we will post the latest information regarding any
updates and changes we have made that would impact the
instructions in this Getting Started document.
www.InterwriteLearning.com
Click on any of the Interwrite Learning products to access
product information, software downloads, documentation,
and training information.
Please recycle
3
Getting Started InterwriteTM Pad
Table of Contents
Interwrite Pads
About This Guide 5
Product Overview 5
Interwrite Pen 5
Bluetooth Technology 5
Workspace Software 5
Installation Overview
1. Unpack Your Interwrite Pad 6
2. Set Up Your Interwrite Pad and Interactive Pen 6
3. Install the Interwrite Workspace Software 6
4. Connect Your Interwrite Pad 6
Setting Up Your Interwrite Pad
Charging the Interwrite Pad and Interactive Pen 8
Attaching the Tether to the Pad and the Pen 8
The Electronic Interwrite Interactive Pen 9
Install the Interwrite Workspace Software
Installing the Interwrite Workspace Software on Windows 10
Installing the Interwrite Workspace Software on the Mac 11
Connect Your Interwrite Pad
BluetoothTM Wireless Installation 12
About Bluetooth and Workspace 12
Bluetooth Requirements 13
Bluetooth Communications 13
Installing the USB Adapter 14
Keeping Track of the Bluetooth Adapter 14
Moving the Bluetooth Adapter 14
4InterwriteTM Pad Getting Started
Connect the Interwrite Devices
Connecting a Wireless Device on Windows 15
Connecting a Wireless Device on the Mac 17
Operating the Interwrite Pad
Operating the Interwrite Pad 19
Operating the Buttons 20
The Sleep/Wake Button 20
The Connect Button 20
The Disconnect Button 21
Light and Tone Indicators 21
The Status Lights 21
The Power Status Light 21
The Connection Status Light 21
The Pad Battery Status Light 21
The Pen Battery Charging Status Light 22
Tone Indicators 22
Replacing the Battery Pack
Replacing the Interwrite Pad Battery Pack 23
Getting Started with Interwrite Workspace
Begin an Interwrite Workspace Session 26
The Interwrite Workspace Toolbar 27
Using the Pen Tool 28
Presentation Files 29
Distributing Presentation Files 30
Additional Interwrite Learning Resources 30
What is PRS? 30
Regulatory Statements and Warranty
Regulatory Statements 31
Warranty 39
5
Getting Started InterwriteTM Pad
Product Overview
The Interwrite Pad is a tablet system featuring the patented digitizer and pen-
input technology. Used with the Interwrite Workspace software on a PC or a
Mac, Interwrite Pads allow you control the computer by running applications,
opening and editing files, and annotating screen images and presentation files
from anywhere in the room. When used with an InterwriteTM Board, Interwrite
Pads provide the ultimate collaborative system for the interactive class room
or the interactive meeting room.
Interwrite Pen
The electronic Interwrite Pen, when positioned just above (in prox of) or
touching the surface of a powered-on, connected Pad, controls the move-
ments of the mouse on the computer. The Pen becomes a writing and
drawing instrument when one of the many Workspace Annotation Tools is
selected from the projected Toolbar. When in Annotation Mode, a user can
make notes on a PowerPoint Slide Show, highlight areas of interest on a
spreadsheet, or edit a document using a wide range of pen attributes.
Bluetooth Technology
The Interwrite Workspace system uses the BluetoothTM wireless technology
to establish communication between the Pad and the computer. The Inter-
write Pads come with the Bluetooth module built into the Pad, so the only
installation required is the Bluetooth USB Adapter on the computer.
Workspace Software
The operation of your Interwrite Pad is facilitated by the Interwrite Work-
space software. The software is installed as part of the process of establish-
ing communication between the Pad and the computer and is covered in
this guide. The Workspace software has three operational modes: White-
board Mode,Interactive Mode and Office Mode (Windows only).
About This Guide
This Getting Started guide describes how to set up your Interwrite Pad and
Interactive Pen, install the Interwrite Workspace software, and establish a
communication connection with the PC or the Mac. It ends with an overview
of the Interwrite Workspace software.
InterwriteTM Pad
6InterwriteTM Pad Getting Started
Interactive Mode, the operational mode used by both Interwrite Pads and
Interwrite Boards, allows you to take advantage of the power and features
of the Workspace software. An Interwrite Pad, acting as an input device to
the computer, remotely controls the computer from anywhere in the room.
When the Interwrite Board and a video projector are added, the computer’s
desktop image projects onto the Interwrite Board’s surface, and the board,
communicates as an input device to the computer.
In this environment, both the person at the Interwrite Board and users with
Pads seated around the room can interact with the presentation. Office
Mode makes it possible to interact directly with Microsoft’s Office suite of
products, PowerPoint, Word and Excel on the PC. Annotations, notes and
calculations can be added directly to the native application files when in this
operational Mode.
Installation Overview
This section describes what you will be doing and the order in which you will
be doing it, to facilitate the setup of your Interwrite Pad and its preparation for
use.
1. Unpack Your Interwrite Pad
The package includes the Interwrite Pad and the rechargeable Interwrite
Interactive Pen, a Pen tether, a Pad Charger, and an Interwrite LearningTM CD
and a Bluetooth USB Adapter.
2. Charge Your Interwrite Pad and Interactive Pen
Your Pad and Pen must be charged before you can use them. Place the
Interactive Pen in the Pad’s Pen Tray and plug the Pad Charger into the
Charger Jack located at the top of the Pad and the other end into a standard
wall socket. The Pad is charged when the Pad Battery Status Light goes off.
3. Install the Interwrite Workspace Software
4. Connect Your Interwrite Pad
Your Interwrite Pad must be able to communicate with the Interwrite Work-
space software on your computer. This communication link is established
wirelessly between two Bluetooth communication modules—one built into
the Pad and the other connected to the computer. The wireless Bluetooth
Pad must then be “connected” to Workspace by the Device Manager, one
of the Interwrite Workspace software applications.
7
Getting Started InterwriteTM Pad
Setting Up Your Interwrite Pad
The Interwrite Pad communicates with the computer using BluetoothTM
wireless technology. The Bluetooth communications module is built into the
Interwrite Pad. The Pad communicates through its built-in Bluetooth module
with another Bluetooth module installed on the computer. The Interwrite Pad
runs on Nickel Metal Hydride batteries, which provide about 40 hours of
wireless operation before they have to be recharged.
InterwriteTM Pad
Charger
Power
Jack
On/Off
Power
Switch
Pen Battery Charging Status Light
Connection Status Light
Power Status Light
Pad Battery Status Light
Sleep/Wake Button
Connect Button
Disconnect Button
Pen Tray
Workspace
8InterwriteTM Pad Getting Started
Charging the Interwrite Pad and
Interactive Pen
Before you use your Interwrite Pad and Interactive Pen for the first time, they
should be charged for about three hours, or until the Pad Battery Status Light
goes off. Whenever the Pad battery is low and needs to be recharged, the Pad
Battery Status Light will flash slowly.
1Place the Interactive Pen in the Pen Tray with the Rocker Button and
Tether Loop facing up.
2Connect the Pad Charger’s cable to the Charger Power Jack at the top of
the Pad.
3Plug the Charger into an AC power outlet.
The Interwrite Pad can be used while it is charging.
4When the Pad and Pen are charged and the Pad Battery Status Light goes
out, unplug the Charger from the Interwrite Pad.
5Turn on the Power Switch when the Interwrite Pad is charged.
The buttons and status lights are described in more detail in the Operating the
Interwrite Pad section beginning on page 20.
Attaching the Tether to the Pad and the Pen
The tether has a loop at each end. One end has a metal ring attached to the
loop – that’s the Pen loop. The other end is the Pad loop.
1Thread the Pad loop up through the hole above the Pen Tray. Thread the
Pen loop through the Pad loop. Pull to tighten.
2Thread the metal ring through the Tether Loop eyelet on the Pen.
The first thing you should do when you unpack your
new Interwrite Pad and Interactive Pen is charge them.
The Pen can be charged only when it is placed in the Pen Tray on the
Pad, and only when the Pad is being charged. A Pen charge lasts over 40
hours. You should always charge the Pen when the Pad is being charged.
9
Getting Started InterwriteTM Pad
The Electronic Interwrite Interactive Pen
The Interactive Pen is an input device to the computer. You will use it to write
and draw in Annotation Mode and to control mouse movements in Mouse
Mode by moving the tip of the Pen just above (in prox of) or touching the
Pad’s workspace surface. When the Pen Tip is in prox or touching the Pad’s
workspace, it simulates the same effects you would get using the left mouse
button both in Windows and on the Mac.
Using the Pen
When the Pen is in prox, press the left end of the Rocker Button to simulate a
left mouse button double-click in Windows and on the Mac. Press the right
end of the Rocker Button to simulate a right mouse button click in Windows
and a Ctrl-click on the Mac. In Windows, hold down the left Rocker Button
and touch the Pen Tip to the Pad’s workspace to erase. On the Mac, with the
Pen Tip touching the Pad’s surface, hold down the left Rocker Button to erase.
Sleep Mode
The Pen goes into Sleep Mode after about two minutes of inactivity to con-
serve power. Touching the Pen to a surface, or clicking one of its Rocker
Buttons, wakes up the Pen. When the Pen is in prox, the Power Status Light
on the Pad will go from flashing to solid green. It goes back to flashing green
when the Pen is out of prox.
Tether
Loop
Pen Tip – Up or Down
Same as Left Mouse Button on Windows and Mac
Rocker
Button
Left – Double-Click Mouse Button with Pen Up
Windows and Mac
Right – Right Mouse Button (Windows)
Ctrl-Click (Mac)
10 InterwriteTM Pad Getting Started
1Log in as Administrator. Insert the Interwrite Learning CD into the
CD drive on your PC. The installer will autoload. If it doesn’t, click
on the Start button on the Windows Task Bar and select Run from
the menu. Type X:\setup.exe (Xrepresents the CD drive letter).
2Select the Install Interwrite Workspace Software menu option.
3Follow the onscreen instructions for the software installation. You
will know Interwrite Workspace has installed successfully by the
appearance of the Interwrite Workspace icon in the System Tray on
the Windows Task Bar. If the icon does not appear, restart your
computer.
Installing the Interwrite Workspace
Software on Windows
The Interwrite Workspace icon on the Task
Bar indicates that the Interwrite Device Man-
ager is now running on your PC. Click on the
Workspace icon to display the options on the
Device Manager Menu shown here. Device
Manager, in addition to managing the Interwrite
hardware devices, provides direct access to the
three operational modes of the Interwrite
Workspace software.
Click the Interwrite Workspace icon in the System Tray of the
Windows Task Bar to display the Device Manager Menu. Select the
Check for Updates
option. If a new version of Workspace is available,
download it now. You should periodically check for updates.
The Interwrite Workspace software must be installed on Windows
by a user with Administrator privileges. Interwrite Workspace is
compatible with Windows 2000, XP, and Vista.
If you are using Windows 98/Me/NT, you must use Interwrite
Workspace version 5.0. For more information, contact Technical
Support to order an installation CD.
Tabla de contenidos
