[email protected]1 General
These operating instructions describe the safe and
proper way to work with the device. The safety
information and instructions given as well as the local
accident prevention regulations and general safety
regulations valid in the area of application must be
complied with. These instructions are a constituent part
of the instrument and need to be kept in the immediate
vicinity of the device accessible to personnel at all times.
Before starting any work, the operating instructions
should be read in full.
2 Use
The SL..THERM heaters are manufactured according to
Directive INMETRO No. 115, of March 21st, 2022 and
are licensed for direct heating through flange-mounting
(conduction) or for room heating (convection) in Ex-zone
1 and Zone 2 for instrument categories G/ D in
temperature classes T3 to T6. You will find the
temperature class for your device on the label. See
Technical Data [}Page4] section.
The areas of application are:
• Frost protection
• Condensation protection
• Maintaining temperature
As an option, thermostats can be integrated in the
connecting cable. If a TAE is used, the respective
operating instructions must be complied with.
Product approval NCC 17.0104 X with appendices and
supplements, as well as IEC Scheme Certificate IECEX
PTB 07.0055X.
See http://www.intertec.info
3 Special conditions for safe use
1. The heater may only be installed and operated in
enclosures whose absolute heat transfer coefficient
is not less (not better) than 0,5 W/K.
2. The connecting cable must have a fixed installation
and must be protected mechanically.
3. If connection is made in the potentially explosive
area, the connecting lead shall be connected by
means of an enclosure that meets the requirements
of a type of protection specified in ABNT NBR IEC
60079-0.
4. Installation shall be made with due regard to the
maximum permissible temperatures of neighbouring
components, the minimum clearances and, where
required, the mounting position.
5. Additional conditions for alternate use of thermostats
see concerning test certificate. They have to be
separately certified to the same standards.
6. Special conditions for some connecting cables have
to be included in the operating manual and have to
be noticed by the installer.
7. lf used in dust-ex-areas the concerning requirements
of ABNT NBR IEC 60079-14, of ABNT NBR IEC
60079-17 and ABNT NBR IEC 60079-19 have to be
considered.
4 Explanation of symbols for warnings
and signal words
The safety information warns the user about risks and
provide information on how risks can be avoided.
Safety information can be found at the start of the
chapter before the instructions which may lead to a
hazardous situation. Additional safety information can be
found at the beginning of this manual.
Safety instructions which must be adhered to are
highlighted as follows:
DANGER
DANGER
This sign is warning about an extremely hazardous
situation which, if not heeded, will lead to death or
serious irreversible injury.
WARNING
WARNING
This sign is warning about a hazardous situation which,
if not heeded, may lead to death or serious irreversible
injury.
CAUTION
NOTICE
This sign is warning about a hazardous situation which,
if not heeded, may lead to slight, reversible injury.
