Intermec IP3 Intellitag Manual de usuario

IP3/IP4 Lightpipe Kit Instructions

The Lightpipe improves the IrDA communication reliability and

speed between your reader and the mobile device. This kit

includes the following contents:

• IP3/IP4 Reader Lightpipe with pre-applied adhesive

• IP3/IP4 Reader Lightpipe Instructions

Reader and Mobile Device Surface Preparation

1Remove the existing gold reflector tape from your Reader. It is

recommended that you use rubbing alcohol to remove any

remaining reflector tape residue. However, do not use any sol-

vent remover that will harm the Reader plastic.

2Remove the existing IR Reflector label on your mobile device

(if applicable). Ensure all label residue is removed from that

location.

Reader gold

reflector tape

Mobile device

reflector label

Lightpipe Installation

1Remove the backing from the adhesive on the Lightpipe

assembly.

2Position the lower end of the Lightpipe into the angled recess

of the Reader.

3Align the upper end with the molded feature in the Reader so

that the edge of the Lightpipe fits squarely across the edge of

the molded feature.

4Press firmly into place and hold for a few seconds to allow the

adhesive to set.

Note: It is very important that the new Lightpipe is

positioned exactly as shown in the following illustra-

tion. This helps ensure proper reflecting of the Infrared

signals between your mobile device and your reader.

Adhesive backing

Lightpipe in proper

position

Molded feature

8PSMEXJEF)FBERVBSUFST

UI"WFOVF8FTU

&WFSFUU8BTIJOHUPO64"

UFM 

XXXJOUFSNFDDPN

ª*OUFSNFD5FDIOPMPHJFT

$PSQPSBUJPO"MMSJHIUTSFTFSWFE

*1*13FBEFS-JHIUQJQF*OTUSVDUJPOT



1/












