SB Series AIR Beam

Detectors Installation

Manual

EN SB Series AIR Beam Detectors Installation Manual

DE Für eine deutsche Anleitung siehe

www.utcfssecurityproducts.eu/manuals/NT299-ML_RevA_SB_Series.pdf

ES Para manual en Español consultar

www.utcfssecurityproducts.eu/manuals/NT299-ML_RevA_SB_Series.pdf

FR Pour le manuel en Français voir

www.utcfssecurityproducts.eu/manuals/NT299-ML_RevA_SB_Series.pdf

IT Per il manuale in italiano vedere

www.utcfssecurityproducts.eu/manuals/NT299-ML_RevA_SB_Series.pdf

NL Voor de Nederlandse handleiding, gebruik deze link:

www.utcfssecurityproducts.eu/manuals/NT299-ML_RevA_SB_Series.pdf

PT Para Português ver www.utcfssecurityproducts.eu/manuals/NT299-

ML_RevA_SB_Series.pdf

P/N NT299-EN • REV A • ISS 03JUL12

Trademarks and

patents

Interlogix, the SB Series AIR Beam Detectors name and logo are

trademarks of UTC Fire & Security.

Other trade names used in this document may be trademarks or

registered trademarks of the manufacturers or vendors of the

respective products.

Manufacture

UTC Fire & Security Americas Corporation, Inc.

1275 Red Fox Rd., Arden Hills, MN 55112-6943, USA

Authorized EU manufacturing representative:

UTC Fire & Security B.V.

Kelvinstraat 7, 6003 DH Weert, Netherlands

Certification

European Union

directives

1999/5/EC (R&TTE directive): Hereby, UTC Fire & Security

declares that this device is in compliance with the essential

requirements and other relevant provisions of Directive 1999/5/EC.

2002/96/EC (WEEE directive): Products marked with this symbol

cannot be disposed of as unsorted municipal waste in the European

Union. For proper recycling, return this product to your local supplier

upon the purchase of equivalent new equipment, or dispose of it at

designated collection points. For more information see:

www.recyclethis.info.

Contact information www.utcfireandsecurity.comor www.interlogix.com

Customer support www.interlogix.com/customer-support.

Content

Introduction 1

General features 2

Detector layout 3

Accessories supplied 3

Installation 4

General guidelines 4

Detector mounting 4

Removing the infrared cover 5

Wiring 6

DIP switch settings 7

Cable length 8

Alarm and disqualification relay 8

Connecting the tamper detection contact 9

Configuration 10

Channel selection 10

Operating modes 11

Single module alignment and settings 12

Installing modules in columns 15

Connections 15

Setting “Slave” mode 17

Module numbering 17

“Master” module selection 18

“Master” module channel selection 19

Detection mode selection 19

Mono-detection of the bottom beam (optional) 20

Column alignment 22

Response time 23

Replacing the infrared cover 24

Final tests 25

Maintenance 26

Troubleshooting 27

Specifications 29

Default configuration 30

Dimensions 30

Accessories and spare parts 31

SB Series AIR Beam Detectors Installation Manual i

ii SB Series AIR Beam Detectors Installation Manual

Introduction

The SB250-N / SB2100-N two-beam detectors and the SB450-N / SB4100-N /

SB4200-N four-beam detectors generate an alarm when 1 or 2 beams are

interrupted, ignoring birds, small animals, dead leaves etc.

They consist of two identical detector modules equipped with detector cells

integrating both transmission and reception functions. These modules are

installed facing each other over the distance to be protected providing a non-

physical invisible detection zone.

Detectors are based on a system of pulsed infrared beams, and operate on four

user-selectable frequencies (channels), which allow avoiding any risk of

interference between detectors.

The SB450-N and SB4100-N barriers have 2 operating modes suitable for

different types of installation (see “Operating modes” on page 11):

• “AND” mode: Simultaneous obstruction of two adjacent cells

• “OR” mode: Obstruction of one of the cells

Refer to “Installing modules in columns” on page 14 for detailed information on

infrared barriers functionality in columns.

SB Series AIR Beam Detectors Installation Manual 1

General features

• Maximum outdoor range:

- SB250-N : 50 m

- SB2100-N : 100 m

- SB450-N : 50 m

- SB4100-N : 100 m

- SB4200-N : 200 m

The range of an infrared detector depends directly on visual range.

Maximum range of an infrared cell according to visibility:

- When visibility is 200 m, the range is 200 m.

- When visibility is 60 m (dense fog), the range is 100 m.

• Four user-selectable frequencies (channels) for distinguishing between

different detectors.

• SB250-N and SB2100-N detectors are equipped with one cell.

• SB450-N, SB4100-N and SB4200-N type detectors are equipped with two

cells dual-beam.

• 2 operating modes for SB450-N and SB4100-N: “AND” and “OR”.

• SB250-N, SB2100-N and SB4200-N have only 1 operating mode: “AND”.

2 SB Series AIR Beam Detectors Installation Manual

Detector layout

Figure 1: Detector layout

(1) 2 cells module, type SB450-N / SB4100-N

/ SB4200-N

(2) 1 cell module, type SB250-N / SB2100-N

(3) Top plate

(4) Infrared cover

(5) Dual-beam cell

(6) Adjustable support

(7) Terminal block

(8) Horizontal direction locking screw

(9) Chassis

(10) Vertical cell alignment

(11) Cover removal tampers

(12) Fixing staple for infrared cover

Accessories supplied

• 8X Ø3.9x13 screws for fixing to column

• 1X Installation manual

SB Series AIR Beam Detectors Installation Manual 3

Installation

General guidelines

See Figure 2 below.

To install the detectors correctly, certain rules must be followed.

• Do not place the detector on an unstable support (such as a mesh or a poorly

fixed post). See item 1.

• Do not position the module facing direct sunlight (item 2).

• Make sure that no vegetation interrupt the cells (item 3).

Figure 2: Potential causes of instability

Detector mounting

To attach the detectors to a metallic support, drill 4 holes measuring 3 mm and

use the sheet metal screws provided.

To fix the detectors to a wall, use appropriate screws and wall plugs for the type

of wall (we recommend at least Ø5 x 30 screws).

• Drill 4 holes and insert wall plugs.

• Position the holes in the adjustable support over the wall plugs.

Note: Rotate the module to be able to reach the screw holes in the adjustable

support (see Figure 3 on page 5).

4 SB Series AIR Beam Detectors Installation Manual

Figure 3: Wall mounting

(1) 4 screws (2) Rear view of the adjustable bracket

Removing the infrared cover

See Figure 4 below.

1. Remove the screw attaching the infrared cover, taking care not to lose the

staple (item 1).

2. Slide the cover upwards until it is stopped by the top plate (item 2).

3. Pull the cover outwards from the grooves in the chassis to remove it (item 3).

Figure 4: Removing the infrared cover

SB Series AIR Beam Detectors Installation Manual 5

Wiring

We recommend that different power supplies are used for the module and

heating.

Note: When using guillotine connectors, put the wire in the connector, and then

pull it out slightly so that it tightens.

Figure 5: Terminals and controls

Item Description Note

(1) Top cell

(2) Bottom cell

(3) DIP switches Channel selection (1 and 2)

Operating mode selection (3 to 5)

(4) Delay adjustment

n adjustment of the response time of the intrusion alarm (50 to

800 ms)

(5) Selection button Select alignment mode

Select cells in alignment mode

(6) Alarm LED Intrusion alarm / disqualification (blinking)

Level of the signal in alignment

Table 1: Terminals

Terminal Description

1 “+” Power

2 “−” Power

3 “+” Heating

6 SB Series AIR Beam Detectors Installation Manual
