Introduction
24-bit resolution
3750 Hz update rate
Peak and valley capture
Log to SD card at 1000Hz
USB Port with software
±5V analog output
Rechargeable battery
20 Hour battery life/300 hour standby
Stores up to 6 sensor calibrations
Powers up to 4x 350 ohm sensors
7 digit display
Description
Model 9330 is a bipolar display, logging, amplifier that can be used in portable or desktop
applications. This instrument has an integrated bridge completion for 120 Ohm, 350 Ohm and 1000
Ohm strain gauges as well active sensors with 0…10V output signal. The measuring rate can be set
up to 3750 Hz. Data can be save to an SD Card at a rate of 1000 Hz or directly to the PC and 3750
Hz. This device also stores up to 6 sensor calibrations.
Options
IP65 Environmental Protection
SD Card –Class 10
9330 Operating Manual
Interface Inc. ● 7401 East Butherus Drive, Scottsdale, Arizona 85260 USA ● Phone 480.948.5555 ● Fax 480.948.1924
Document Number 15-216 Rev B Page 3 of 74
Table of Contents
Specifications........................................................................................................................................5
Dimensions...........................................................................................................................................6
Diagram ................................................................................................................................................6
Connection of Bridges...........................................................................................................................7
Pin Assignment.....................................................................................................................................8
Connection and Commissioning ...........................................................................................................8
Menu Options........................................................................................................................................9
Sensor Config. .........................................................................................................................10
Logger Config...........................................................................................................................11
Options.....................................................................................................................................11
Data Acquisition.......................................................................................................................12
Set Scaling...............................................................................................................................12
Save Settings...........................................................................................................................13
Load Settings...........................................................................................................................13
Strain Analysis .........................................................................................................................14
Logger Menu.......................................................................................................................................15
Measuring Amplifier Menu ..................................................................................................................17
Description of Buttons.........................................................................................................................19
Number Setting...................................................................................................................................19
Description of LEDs............................................................................................................................19
Maximum, Minimum, and Mean Value................................................................................................20
Recording Measured Data to File .......................................................................................................20
USB Operation....................................................................................................................................21
Power Supply per USB Connection....................................................................................................22
USB Driver..........................................................................................................................................22
BlueDAQ Software Installation............................................................................................................22
COM Ports..........................................................................................................................................25
Adding a Channel ...............................................................................................................................26
Distance Offset ...................................................................................................................................30
Measurement and Recording..............................................................................................................31
BlueDAQ Menus.................................................................................................................................34
9330 Operating Manual
Interface Inc. ● 7401 East Butherus Drive, Scottsdale, Arizona 85260 USA ● Phone 480.948.5555 ● Fax 480.948.1924
Document Number 15-216 Rev B Page 4 of 74
File ...........................................................................................................................................34
View .........................................................................................................................................39
Action.......................................................................................................................................42
Device......................................................................................................................................43
Channel....................................................................................................................................59
Sensor......................................................................................................................................62
Options.....................................................................................................................................68
Help..........................................................................................................................................70
9330 Operating Manual
Interface Inc. ● 7401 East Butherus Drive, Scottsdale, Arizona 85260 USA ● Phone 480.948.5555 ● Fax 480.948.1924
Document Number 15-216 Rev B Page 5 of 74
9330 Operating Manual
Interface Inc. ● 7401 East Butherus Drive, Scottsdale, Arizona 85260 USA ● Phone 480.948.5555 ● Fax 480.948.1924
Document Number 15-216 Rev B Page 6 of 74
Dimensions
Diagram
9330 Operating Manual
Interface Inc. ● 7401 East Butherus Drive, Scottsdale, Arizona 85260 USA ● Phone 480.948.5555 ● Fax 480.948.1924
Document Number 15-216 Rev B Page 7 of 74
*** Note –Refer to Pin Assignment table ***
Connection of Bridges
9330 Operating Manual
Interface Inc. ● 7401 East Butherus Drive, Scottsdale, Arizona 85260 USA ● Phone 480.948.5555 ● Fax 480.948.1924
Document Number 15-216 Rev B Page 8 of 74
Pin Assignment
Connection and Commissioning
To switch on, press the MODE button until the display is illuminated.
The device contains a battery that is charged by connecting the power adapter supplied.
The “ON” LED flashes while charging.
To switch off, hold the MODE button (outside the menu) down and confirm the following
message “Power off? (OK)“ by pressing the OK button.
Please use SDHC Memory Cards, class 6 or class 10, does not support UHS 2.
