INTRODUCTION

MB960 User’s Manual 1

Introduction

Product Description

The MB960F ATX motherboard is based on the latest Intel@Q67 chipset.

The platform supports 2nd generation Intel@Core processor family with

LGA1155 packing and features an integrated dual-channel DDR3

memory controller as well as a graphics core.

The latest Intel@processors provide advanced performance in both

computing and graphics quality. This meets the requirement of

customers in the gaming, POS, digital signage and server market

segment.

The Q67 platform is made with 32 nanometer technology that supports

Intel’s first processor architecture to unite the CPU and the graphics core

on the transistor level. The MB960FATX board utilizes the dramatic

increase in performance provided this Intel’s latest cutting-edge

technology. Measuring 305mm x 244mm, the MB960F offers fast

6Gbps SATA support (2 ports), USB3.0 (2 ports) and interfaces for

DVI-D, DVI-I and HDMI displays. MB960AF features IntelActive

Management Technology 7.0.

MB960F FEATURES:

 Supports Intel@2nd Generation Core i7/i5/i3 QC/DC desktop

processors

 Four DDR3 DIMM, 1066/1333MHz, Max. 16GB memory

 Dual Intel@ PCI-Express Gigabit LAN

 Integrated Graphics for DVI-I, DVI-D/HDMI displays

 4x SATA 2.0, 2x SATA 3.0, 14x USB 2.0, USB 3.0 (2 ports),

4x COM, Watchdog timer

 1x PCI-E (x16), 1x PCI-E (x4), 4x PCI, 1x ISA

 Optional AMT (MB960AF only)

INTRODUCTION

MB960 User’s Manual

Checklist

Your MB960 package should include the items listed below.

 The MB960 Mini-ITX motherboard

 This User’s Manual

 1 CD containing chipset drivers and flash memory utility

 Serial ATA cable

INTRODUCTION

MB960 User’s Manual 3

MB960 Specifications

Product Name MB960AF/MB960F

Form Factor ATX

CPU Type - Intel®Sandy Bridge 32nm QC/DC DT processor w/ IMC & Gfx

- LGA package[37.5 mm x 37.5mm](TDP: QC= 95W/65W ; DC = 65W)

**Sandy Bridge-DT is NOT socket compatible with Clarkdale/Lynnfield

CPU Speed Up to 3.1GHz

Cache Up to 8MB

CPU Socket LGA1155 (Socket H2)

Chipset Intel®Q67 PCH

27 x 27 mm package size

BIOS AMI BIOS, support ACPI Function

Memory Intel®2nd generation CoreTM i7/i5/i3 QC/DC mobile processor integrated

controller

DDRIII 1067/1333 MHz

- DIMM x 4 (w/o ECC), Max.16GB

VGA - Intel®2nd generation CoreTM i7/i5/i3 mobile processor integrated Gfx

 DVI-I X 1 (thru Level shifter ASM1442)

 DVI-D X 1 (thru Level shifter ASM1442)

 HDMI X 1 (thru Level shifter ASM1442)

LAN 1. Intel® Lewisville 82579LM GbE PHY[MI960AF only]

or 82579VGbE PHY [MI960F only]

2. Intel®82583V as 2nd GbE

USB USB 2.0 host controller, supports 14 ports w/ two EHCI

- 4 ports in the rear panel

- Others reserved for onboard pin header ( 10 ports , 2.54mm pitch)

USB 3.0 host controller [ASMedia # ASM1042], support 2 ports

- 2 ports in the rear panel

Serial ATA Intel®Q67 PCH built-in SATA controller, supports total 6 ports

2 x SATA (3.0) 6Gbps+ 4 x SATA (2.0) 3Gbps ports (2 FIS based Port

Multiplier)

Audio Intel®Q67 PCH built-in High Definition Audio controller+ ALC892 w/ 7.1 CH

LPC I/O Fintek F81865-I (Ver. C)

COM1 (RS232/422/485), COM2/COM3/COM4 (RS232), Hardware

Monitor (2 thermal inputs,4 voltage monitor inputs & 2 Fan headers)

COM1/2 with pin-9 with power for 2 ports (500 mA for each port)

Digital IO 4 in & 4 out

IAMT(7.0) Intel®Q67 PCH built-in (MI960AF only)

- Intel®Active Management Technology ver. 7.0

TPM 1.2 Winbond WPCT210A (MB960AF only)

PCI to ISA ITE IT8888G x 1 for high ISA bus

PATA JMicron JMB368 (PCI-e to PATA) x1 for 1 PATA channel

- CF x1 ( Horizontal type)

Expansion Slots - PCI-Express (16x) x1 [PEG]; PCI-Express (4x) x1; PCI x4; ISA x1

Edge

Connectors DVI-D + DVI-I stack connector; Dual DB9 stack connector for COM #1, #2

Dual USB(3.0) dual stack connector; HDMI stack connector

Gbit LAN RJ-45 + dual USB(2.0) stack connector x2

RCA Jack 3 x 1 for HD Audio

Onboard

Header/

Connector

2 ports x SATA III [Blue color]; 4 ports x SATA II

2x5 pin-header x5 for 10 ports USB; 2x5 pin-header for front panel audio

2x10 pin-header for COM3 (RS232) & COM4 (RS232)

2x5 pin-header for Digital IO

Watchdog Timer Yes (256 segments, 0, 1, 2…255 sec/min)

System

Voltage ATX

Others LAN Wakeup , EuP feature (Fintek F75160) ,UL 60950-1 2nd Edition

compatible

INTRODUCTION

MB960 User’s Manual

Board Size 305mm x 244mm

INTRODUCTION

MB960 User’s Manual 5

[

Board Dimensions

INSTALLATIONS

MB960 User’s Manual

Installations

This section provides information on how to use the jumpers and

connectors on the MB960 in order to set up a workable system. The

topics covered are:

Installing the CPU..................................................................................7

Installing the Memory............................................................................8

Setting the Jumpers................................................................................9

Connectors on MB960.........................................................................13
