Intel DQ43AP Manual de usuario

Intel® Desktop Board

DQ43AP

Specification Update

July 2010

Order Number: E69398-005US

The Intel®Desktop Board DQ43AP may contain design defects or errors known as errata, which may cause the product to deviate

from published specifications. Current characterized errata are documented in this Specification Update.

2 Intel Desktop Board DQ43AP Specification Update

Revision History

Revision Revision History Date

-001 This document is the first Specification Update for the Intel®Desktop

Board DQ43AP May 2009

-002 Update to the Documentation Changes Section August 2009

-003 Update to the General Information Section December 2009

-004 Update to the General Information Section April 2010

-005 Update to the General Information Section July 2010

INFORMATION IN THIS DOCUMENT IS PROVIDED IN CONNECTION WITH INTEL®PRODUCTS. NO LICENSE,

EXPRESS OR IMPLIED, BY ESTOPPEL OR OTHERWISE, TO ANY INTELLECTUAL PROPERTY RIGHTS IS

GRANTED BY THIS DOCUMENT. EXCEPT AS PROVIDED IN INTEL’S TERMS AND CONDITIONS OF SALE FOR

SUCH PRODUCTS, INTEL ASSUMES NO LIABILITY WHATSOEVER, AND INTEL DISCLAIMS ANY EXPRESS OR

IMPLIED WARRANTY, RELATING TO SALE AND/OR USE OF INTEL PRODUCTS INCLUDING LIABILITY OR

WARRANTIES RELATING TO FITNESS FOR A PARTICULAR PURPOSE, MERCHANTABILITY, OR INFRINGEMENT

OF ANY PATENT, COPYRIGHT OR OTHER INTELLECTUAL PROPERTY RIGHT. INTEL PRODUCTS ARE NOT

INTENDED FOR USE IN MEDICAL, LIFE SAVING, LIFE SUSTAINING APPLICATIONS.

Intel may make changes to specifications and product descriptions at any time, without notice.

Designers must not rely on the absence or characteristics of any features or instructions marked “reserved”

or “undefined”. Intel reserves these for future definition and shall have no responsibility whatsoever for

conflicts or incompatibilities arising from future changes to them.

The Intel®Desktop Board DQ43AP may contain design defects or errors known as errata which may cause

the product to deviate from published specifications. Current characterized errata are available on request.

Contact your local Intel sales office or your distributor to obtain the latest specifications before placing your

product order.

Copies of documents which have an ordering number and are referenced in this document, or other Intel

literature, may be obtained from:

Intel Corporation

P.O. Box 5937

Denver, CO 80217-9808

or call in North America 1-800-548-4725, Europe 44-0-1793-431-155, France 44-0-1793-421-777,

Germany 44-0-1793-421-333, other Countries 708-296-9333

Intel, the Intel logo, Pentium, Intel Core and Celeron are registered trademarks of Intel Corporation in the

U.S. and other countries.

* Other names and brands may be claimed as the property of others.

Intel Desktop Board DQ43AP Specification Update 3

Contents

Specification Update for the Intel®Desktop Board DQ43AP

Terminology ............................................................................................ 5

General Information .................................................................................5

Summary of Changes ............................................................................... 6

4 Intel Desktop Board DQ43AP Specification Update

Specification Update for the

Intel®Desktop Board DQ43AP

This document is an update to the specifications contained in the Intel®Desktop Board

DQ43AP Technical Product Specification (Order Number: E64768). It is intended for

hardware system manufacturers and software developers of applications, operating

systems, or tools. It will contain Specification Changes, Errata, Specification

Clarifications, and Documentation Changes.

For specification updates concerning the Intel processor that apply to this desktop

board, refer to the following:

•Intel®Core™2 Extreme Processor QX9650 and Intel®Core™2 Quad Processor

Q9000 Series Specification Update (Order Number 318727)

•Intel®Core™2 Extreme Quad-Core Processor QX6000 Sequence and Intel®Core™2

Quad Processor Q6000 Sequence Specification Update (Order Number 315593)

•Intel®Core™2 Duo Processor E8000 and E7000 Series Datasheet (Order Number

318733)

•Intel®Core™2 Extreme Processor X6800 and Intel®Core™2 Duo Desktop

Processor E6000 and E4000 Sequence Specification Update (Order Number

313279)

•Intel®Pentium®Dual-Core Desktop Processor E2000 Sequence Specification

Update (Order Number 316982)

•Intel®Celeron®Dual-Core Processor E1000 Series Specification Update (Order

Number 318925)

•Intel®Xeon®Desktop Processor 3000 Series Datasheet (Order Number 314916)

Unless otherwise noted in this document, it should be assumed that any processor

errata for a given stepping are applicable to the Altered Assembly (AA) revision(s)

associated with that stepping.

Refer to the Intel®4 Series Express Chipset Family Specification Update (Order

Number: 319971) for specification updates concerning the 82Q43 GMCH Controller

and that may apply to the desktop board DQ43AP. Unless otherwise noted in this

document, it should be assumed that any MCH errata for a given stepping are

applicable to the Altered Assembly (AA) revision(s) associated with that stepping.

Refer to the Intel®I/O Controller Hub 10 (ICH10) Family Specification Update (Order

Number: 319974) for specification updates concerning the 82801JD I/O Controller Hub

and that may apply to the desktop board DQ43AP. Unless otherwise noted in this

document, it should be assumed that any ICH10 errata for a given stepping are

applicable to the Altered Assembly (AA) revision(s) associated with that stepping.

Intel Desktop Board DQ43AP Specification Update 5

Terminology

Specification Changes are modifications to the current published specifications.

These changes will be incorporated in the next release of the specifications.

Errata are design defects or errors. Characterized errata may cause the desktop

board behavior to deviate from published specifications. Hardware and software

designed to be used with any given Altered Assembly (AA) and BIOS revision level

must assume that all errata documented for that AA and BIOS revision level are

present on all desktop boards.

Specification Clarifications describe a specification in greater detail or further

highlight a specification’s impact to a complex design situation. These clarifications

will be incorporated in the next release of the specifications.

Documentation Changes include typos, errors, or omissions from the current

published specifications. These changes will be incorporated in the next release of the

specifications.

General Information

Basic Desktop Board DQ43AP Identification Information

AA Revision BIOS Revision Notes

E60578-201 APQ4310H.86A.0024 1,2

E60578-202 APQ4310H.86A.0024 1,2

E60578-203 APQ4310H.86A.0024 1,2

E60578-204 APQ4310H.86A.0028 1,2

E60578-205 APQ4310H.86A.0031 1,2

E60578-206 APQ4310H.86A.0031 1,2

Notes:

1. The AA number is found on a small label on the component side of the board.

2. The 4 Series Chipset kit used on this AA revision consists of two components as follows:

Device Stepping S-Spec Numbers

Q43 A3 SLB88

ICH10D B0 SLG8T

6 Intel Desktop Board DQ43AP Specification Update

Summary of Changes

The following table indicates the Specification Changes, Errata, Specification

Clarifications, or Documentation Changes that apply to the Intel®Desktop Board

DQ43AP. Intel intends to fix some of the errata in a future revision of the desktop

board, and to account for the other outstanding issues through documentation or

specification changes as noted.

The following notations are used in the table:

Doc: Document change or update that will be implemented.

Plan Fix: This erratum may be fixed in a future revision of the desktop board, driver, or BIOS.

Fixed: This erratum has been previously fixed.

No Fix: There are no plans to fix this erratum.

Shaded: This erratum is either new or modified from the previous version of the document.

No. Plans Specification Changes

1 Doc Correction to a table reference in Section 4.2 BIOS Beep Codes.

No. Plans Errata

There is no characterized erratum for this product

Specification Changes

The Documentation Changes listed in this section apply to the Intel®Desktop Board

DA43AP Technical Product Specification (Order Number E64768).

1. Correction to a table reference in Section 4.2 BIOS Beep Codes.

4.2 BIOS Beep Codes

Whenever a recoverable error occurs during POST, the BIOS causes the board’s

speaker to beep an error message describing the problem (see Table 34).
