Intel®Desktop Board

D865PCD

Specification Update

Release Date: December 2004

Order Number: C74009-005

The Intel®Desktop Board D865PCD may contain design defects or errors known as errata, which

may cause the product to deviate from published specifications. Current characterized errata are

documented in this Specification Update.

INFORMATION IN THIS DOCUMENT IS PROVIDED IN CONNECTION WITH INTEL®PRODUCTS. NO LICENSE,

EXPRESS OR IMPLIED, BY ESTOPPEL OR OTHERWISE, TO ANY INTELLECTUAL PROPERTY RIGHTS IS GRANTED

BY THIS DOCUMENT. EXCEPT AS PROVIDED IN INTEL’S TERMS AND CONDITIONS OF SALE FOR SUCH PRODUCTS,

INTEL ASSUMES NO LIABILITY WHATSOEVER, AND INTEL DISCLAIMS ANY EXPRESS OR IMPLIED WARRANTY,

RELATING TO SALE AND/OR USE OF INTEL PRODUCTS INCLUDING LIABILITY OR WARRANTIES RELATING TO

FITNESS FOR A PARTICULAR PURPOSE, MERCHANTABILITY, OR INFRINGEMENT OF ANY PATENT, COPYRIGHT OR

OTHER INTELLECTUAL PROPERTY RIGHT. INTEL PRODUCTS ARE NOT INTENDED FOR USE IN MEDICAL, LIFE

SAVING, LIFE SUSTAINING APPLICATIONS.

Intel may make changes to specifications and product descriptions at any time, without notice.

Designers must not rely on the absence or characteristics of any features or instructions marked “reserved” or “undefined”.

Intel reserves these for future definition and shall have no responsibility whatsoever for conflicts or incompatibilities arising from

future changes to them.

The Intel®desktop board D865PCD may contain design defects or errors known as errata which may cause the product to

deviate from published specifications. Current characterized errata are available on request.

Contact your local Intel sales office or your distributor to obtain the latest specifications before placing your product order.

Copies of documents which have an ordering number and are referenced in this document, or other Intel literature, may be

obtained from:

Intel Corporation

P.O. Box 5937

Denver, CO 80217-9808

or call in North America 1-800-548-4725, Europe 44-0-1793-431-155, France 44-0-1793-421-777,

Germany 44-0-1793-421-333, other Countries 708-296-9333

Intel, Pentium, Celeron, and the Intel logo are trademarks or registered trademarks of Intel Corporation or its subsidiaries in the

United States and other countries.

* Other names and brands may be claimed as the property of others.

CONTENTS

REVISION HISTORY ................................................................................................................................... v

PREFACE................................................................................................................................................... vi

Specification Update for the Intel®Desktop Board D865PCD

GENERAL INFORMATION ..........................................................................................................................3

ERRATA ......................................................................................................................................................5

SPECIFICATION CLARIFICATIONS ...........................................................................................................6

DOCUMENTATION CHANGES ...................................................................................................................7

Intel®Desktop Board D865PCD Specification Update

REVISION HISTORY

Date of Revision Version Description

May 2004 -001 This document is the first Specification Update for the

Intel®Desktop Board D865PCD.

July 2004 -002 Added Specification Clarification 1.

August 2004 -003 Added Erratum 1.

November 2004 -004 Added Erratum 2.

December 2004 -005 Added Documentation Change 1.

Intel®Desktop Board D865PCD Specification Update

PREFACE

This document is an update to the specifications contained in the

Intel

Desktop Board D865PCD Technical

Product Specification

(Order number C73314). It is intended for hardware system manufacturers and

software developers of applications, operating systems, or tools. It will contain Specification Changes, Errata,

Specification Clarifications, and Documentation Changes.

Refer to the

Intel

Pentium

4 Processor Specification Update

(Order number 249199) for specification

updates concerning the Intel Pentium 4 processor and that may apply to the desktop board D865PCD.

Unless otherwise noted in this document, it should be assumed that any processor errata for a given stepping

are applicable to the Altered Assembly (AA) revision(s) associated with that stepping.

Refer to the

Intel

865PE/P Chipset Specification Update

(Order Number 252524) for specification updates

concerning the 82865P MCH Controller and that may apply to the desktop board D865PCD. Unless

otherwise noted in this document, it should be assumed that any MCH errata for a given stepping are

applicable to the Altered Assembly (AA) revision(s) associated with that stepping.

Refer to the

Intel

82801EB I/O Controller Hub 5 (ICH5) Specification Update

(Order Number 252517) for

specification updates concerning the 82801ER I/O Controller Hub and that may apply to the desktop board

D865PCD. Unless otherwise noted in this document, it should be assumed that any ICH 5 errata for a given

stepping are applicable to the Altered Assembly (AA) revision(s) associated with that stepping.

Nomenclature

Specification Changes are modifications to the current published specifications. These changes will be

incorporated in the next release of the specifications.

Errata are design defects or errors. Characterized errata may cause the desktop board D865PCD’s behavior

to deviate from published specifications. Hardware and software designed to be used with any given Altered

Assembly (AA) and BIOS revision level must assume that all errata documented for that AA and BIOS

revision level are present on all desktop boards.

Specification Clarifications describe a specification in greater detail or further highlight a specification’s

impact to a complex design situation. These clarifications will be incorporated in the next release of the

specifications.

Documentation Changes include typos, errors, or omissions from the current published specifications.

These changes will be incorporated in the next release of the specifications.

Specification Update for the

Intel®Desktop Board D865PCD

Intel®Desktop Board D865PCD Specification Update

GENERAL INFORMATION

Basic Desktop Board D865PCD Identification Information

AA Revision

BIOS Revision

Notes

C69211-401 RC86510A.86A.0034.P13 1-5

C69211-402 RC86510A.86A.0037.P15 1-5

C69211-403 RC86510A.86A.0037.P15 1-5

C69211-404 RC86510A.86A.0037.P15 1-5

C69863-400 RC86510A.86A.0034.P13 1-5

C69863-401 RC86510A.86A.0037.P15 1-5

C69863-402 RC86510A.86A.0037.P15 1-5

NOTES:

1. The AA number is found on a small label on the component side of the board.

2. The 82865P Chipset kit used on this AA revision consists of two components as follows:

Device Stepping S-Spec Numbers

82865P HT MCH A2 SL6UY

82801EB ICH A3 SL73Z

3. Refer to the

Intel

Pentium

4 Processor Specification Update

(Order Number 249199) for errata related to the Pentium 4

processor and that may apply to the desktop board D865PCD.

4. Refer to the

Intel

865PE/P Specification Update

(Order Number 252524) for errata related to the 82865P MCH

that may

apply to the desktop board D865PCD.

5. Refer to the

Intel

82801EB I/O Controller Hub 5 (ICH5) Specification Update

(Order Number 252517) for errata related to

the 82801ER I/O Controller Hub that may apply to the desktop board D865PCD.

Intel®Desktop Board D865PCD Specification Update

Summary Table of Changes

The following table indicates the Specification Changes, Errata, Specification Clarifications, or Documentation

Changes that apply to the Intel®Desktop Board D865PCD. Intel intends to fix some of the errata in a future

revision of the desktop board, and to account for the other outstanding issues through documentation or

specification changes as noted. This table uses the following notations:

CODES USED IN SUMMARY TABLE

Doc: Document change or update that will be implemented.

Plan Fix: This erratum may be fixed in a future revision of the desktop board, driver, or

BIOS.

Fixed: This erratum has been previously fixed.

No Fix: There are no plans to fix this erratum.

Shaded: This erratum is either new or modified from the previous version of the document.

NO. PLANS ERRATA

1 Plan Fix Some systems may hang if the mouse is moved when entering standby mode

2 Plan Fix System may intermittently hang at POST code 75 with SATA hard disk drives attached

NO. PLANS SPECIFICATION CLARIFICATIONS

1 Doc Change to description of Table 17, Front Panel Audio Connector

NO. PLANS DOCUMENTATION CHANGES

1 Doc Change to Section 2.8.2.2, Table 17, Front Panel Audio Connector
