Intel®Desktop Board

D845GBV

Product Supplement

Specification Update

Release Date: November 2003

Order Number: A98274-007

The IntelDesktop Board D845GBV may contain design defects or errors known as errata which

may cause the product to deviate from published specifications. Current characterized errata are

documented in this Specification Update.

INFORMATION IN THIS DOCUMENT IS PROVIDED IN CONNECTION WITH INTEL®PRODUCTS. NO LICENSE,

EXPRESS OR IMPLIED, BY ESTOPPEL OR OTHERWISE, TO ANY INTELLECTUAL PROPERTY RIGHTS IS GRANTED

BY THIS DOCUMENT. EXCEPT AS PROVIDED IN INTEL’S TERMS AND CONDITIONS OF SALE FOR SUCH PRODUCTS,

INTEL ASSUMES NO LIABILITY WHATSOEVER, AND INTEL DISCLAIMS ANY EXPRESS OR IMPLIED WARRANTY,

RELATING TO SALE AND/OR USE OF INTEL PRODUCTS INCLUDING LIABILITY OR WARRANTIES RELATING TO

FITNESS FOR A PARTICULAR PURPOSE, MERCHANTABILITY, OR INFRINGEMENT OF ANY PATENT, COPYRIGHT OR

OTHER INTELLECTUAL PROPERTY RIGHT. INTEL PRODUCTS ARE NOT INTENDED FOR USE IN MEDICAL, LIFE

SAVING, LIFE SUSTAINING APPLICATIONS.

Intel may make changes to specifications and product descriptions at any time, without notice.

Designers must not rely on the absence or characteristics of any features or instructions marked “reserved”or “undefined”.

Intel reserves these for future definition and shall have no responsibility whatsoever for conflicts or incompatibilities arising from

future changes to them.

The Inteldesktop board D845GBV may contain design defects or errors known as errata which may cause the product to

deviate from published specifications. Current characterized errata are available on request.

Contact your local Intel sales office or your distributor to obtain the latest specifications before placing your product order.

Copies of documents which have an ordering number and are referenced in this document, or other Intel literature, may be

obtained from:

Intel Corporation

P.O. Box 5937

Denver, CO 80217-9808

or call in North America 1-800-548-4725, Europe 44-0-1793-431-155, France 44-0-1793-421-777,

Germany 44-0-1793-421-333, other Countries 708-296-9333

Intel, Pentium, Celeron, and the Intel logo are trademarks or registered trademarks of Intel Corporation or its subsidiaries in the

United States and other countries.

* Other names and brands may be claimed as the property of others.

CONTENTS

REVISION HISTORY ...................................................................................................................................v

PREFACE ...................................................................................................................................................vi

Product Supplement Specification Update for the IntelDesktop Board D845GBV

GENERAL INFORMATION ..........................................................................................................................3

SPECIFICATION CHANGES .......................................................................................................................7

DOCUMENTATION CHANGES ...................................................................................................................9

IntelDesktop Board D845GBV Product Supplement Specification Update

REVISION HISTORY

Date of Revision Version Description

June 2002 -001 This document is the first Product Supplement Specification

Update for the IntelDesktop Board D845GBV.

September 2002 -002 Added Erratum 1. Removed Printed Board Assembly (PBA)

information from the document, as this reference is no longer

valid. Updated Legal Disclaimer Section.

October 2002 -003 Added Specification Change 1. Added Erratum 2.

February 2003 -004 Added Errata 3-5. Added Documentation Changes 1-3.

March 2003 -005 Added Errata 6-8. Added Documentation Changes 4, 5.

April 2003 -006 Added Documentation Change 6.

November 2003 -007 Added Specification Clarification 1.

IntelDesktop Board D845GBV Product Supplement Specification Update

PREFACE

This document is an update to the specifications contained in the IntelDesktop Board D845GBV Product

Supplement Document (Order number A85839). It is intended for hardware system manufacturers and

software developers of applications, operating systems, or tools. It will contain Specification Changes,

Errata, Specification Clarifications, and Documentation Changes.

Refer to the IntelPentium4 Processor Specification Update (Order number 249199) for specification

updates concerning the Intel Pentium 4 processor and that may apply to the desktop board D845GBV.

Unless otherwise noted in this document, it should be assumed that any processor errata for a given stepping

are applicable to the Altered Assembly (AA) revision(s) associated with that stepping.

Refer to the Intel845G/845GL Chipset: Intel82845G/82845GL Graphics and Memory Controller Hub

(GMCH) Specification Update (Order Number 298657) for specification updates concerning the 82845G MCH

Controller and that may apply to the desktop board D845GBV. Unless otherwise noted in this document, it

should be assumed that any MCH errata for a given stepping are applicable to the Altered Assembly (AA)

revision(s) associated with that stepping.

Refer to the Intel82801DB I/O Controller Hub 4 (ICH4) Specification Update (Order Number 290745) for

specification updates concerning the 82801DB I/O Controller Hub and that may apply to the desktop board

D845GBV. Unless otherwise noted in this document, it should be assumed that any ICH 4 errata for a given

stepping are applicable to the Altered Assembly (AA) revision(s) associated with that stepping.

Nomenclature

Specification Changes are modifications to the current published specifications. These changes will be

incorporated in the next release of the specifications.

Errata are design defects or errors. Characterized errata may cause the desktop board D845GBV’s behavior

to deviate from published specifications. Hardware and software designed to be used with any given Altered

Assembly (AA) and BIOS revision level must assume that all errata documented for that AA and BIOS

revision level are present on all desktop boards.

Specification Clarifications describe a specification in greater detail or further highlight a specification’s

impact to a complex design situation. These clarifications will be incorporated in the next release of the

specifications.

Documentation Changes include typos, errors, or omissions from the current published specifications.

These changes will be incorporated in the next release of the specifications.

Product Supplement Specification Update for the

Intel®Desktop Board D845GBV

IntelDesktop Board D845GBV Product Supplement Specification Update

GENERAL INFORMATION

Basic Desktop Board D845GBV Identification Information

AA Revision

BIOS Revision

Notes

A84337-203 RG84510A.86A.0006.P01 1-5

A84337-204 RG84510A.86A.0007.P02 1-5

A84337-205 RG84510A.86A.0009.P04 1-5

A84337-300 RG84510A.86A.0009.P04 1-5

A84337-301 RG84510A.86A.0009.P04 1-5

A84337-302 RG84510A.86A.0017.P09 1-5

A84337-303 RG84510A.86A.0028.P15 1-5

A84337-304 RG84510A.86A.0028.P15 1-5

A84339-203 RG84510A.86A.0006.P01 1-5

A84339-204 RG84510A.86A.0007.P02 1-5

A84339-205 RG84510A.86A.0009.P04 1-5

A84339-300 RG84510A.86A.0009.P04 1-5

A84339-301 RG84510A.86A.0009.P04 1-5

A84339-302 RG84510A.86A.0017.P09 1-5

A84339-303 RG84510A.86A.0028.P15 1-5

A84339-304 RG84510A.86A.0028.P15 1-5

A84538-203 RG84510A.86A.0006.P01 1-5

A84538-204 RG84510A.86A.0007.P02 1-5

A84538-205 RG84510A.86A.0009.P04 1-5

A84538-300 RG84510A.86A.0009.P04 1-5

A84538-301 RG84510A.86A.0009.P04 1-5

A84538-302 RG84510A.86A.0017.P09 1-5

A84538-303 RG84510A.86A.0028.P15 1-5

A84538-304 RG84510A.86A.0028.P15 1-5

A84540-201 RG84510A.86A.0006.P01 1-5

A84540-202 RG84510A.86A.0007.P02 1-5

A84540-203 RG84510A.86A.0009.P04 1-5

A84540-300 RG84510A.86A.0009.P04 1-5

A84540-301 RG84510A.86A.0009.P04 1-5

A84540-302 RG84510A.86A.0017.P09 1-5

IntelDesktop Board D845GBV Product Supplement Specification Update

Basic Desktop Board D845GBV Identification Information (cont)

AA Revision

BIOS Revision

Notes

A84540-302 RG84510A.86A.0028.P15 1-5

NOTES:

1. The AA number is found on a small label on the component side of the board.

2. The 82845G Chipset kit used on this AA revision consists of three components as follows:

Device Stepping S-Spec Numbers

RG82845 GMCH A1 SL66F

82801DB ICH A1 SL66K

82802AB FWH A1 SB48

3. Refer to the Intel Pentium4 Processor Specification Update (Order Number 249199) for errata related to the Pentium 4

processor and that may apply to the desktop board D845GBV.

4. Refer to the Intel 845G/845GL Chipset: Intel 82845G/82845GL Graphics and Memory Controller Hub (GMCH)

Specification Update (Order Number 298657) for errata related to the 82845G MCH that may apply to the desktop board

D845GBV.

5. Refer to the Intel 82801DB I/O Controller Hub 4 (ICH4) Specification Update (Order Number 290745) for errata related to

the 82802DB I/O Controller Hub that may apply to the desktop board D845GBV.
